LP16 5A 8Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal

Name: LP16 5A 8Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 407.0 INR
Availability: InStock

407.0 INR/Piece

Get a Price/Quote

Product Details:

Power Supply Wired
Output 8-pin Solder Terminal
Components Metal Shell, Solder Terminals, Sealing Gasket
Input 8-pin Solder Terminal
Features Waterproof, Dustproof, Corrosion Resistant, Secure Locking Mechanism
Usage Industrial, Outdoor Equipment
Power Source External Power Supply
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP16 5A 8Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal Price And Quantity

Price 407.0 INR/Piece
Minimum Order Quantity 100 Piece

Connector Gender Female
Insulation Resistance 2000M at 500V DC
Cable Diameter Acceptance 4.5mm ~ 7mm
Mounting Type Panel Mount Front/Fix Nut
Contact Material Brass with Gold Plating
Mating Cycle Durability >500 Cycles
Number of Pins 8 pins
Environmental Protection UV Resistant
Protection Method Sealing Gasket and Locknut
Material Zinc Alloy Metal Shell
Flame Retardant Standard UL94-V0
Contact Resistance 5m

LP16 5A 8Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal Product Specifications

Function Panel Mount Power Connection
Current Rating 5A
Power Source External Power Supply
Supply Voltage Up to 500V AC
Application Power and Signal Transmission, Outdoor Installations, LED Lighting
Size 16mm Mounting Diameter
Power Supply Wired
Weight 19g (approx.)
Capacity 5A per pin
Interface 8-Pin Solder
Output 8-pin Solder Terminal
Components Metal Shell, Solder Terminals, Sealing Gasket
Dimension (L*W*H) 32mm x 21mm x 21mm (approx.)
Input 8-pin Solder Terminal
IP Rating IP67
Product Type Female Socket Connector
Color Metallic Silver
Features Waterproof, Dustproof, Corrosion Resistant, Secure Locking Mechanism
Operating Temperature -20C ~ +85C
Usage Industrial, Outdoor Equipment
Rated Voltage 500V AC

Connector Gender Female
Insulation Resistance 2000M at 500V DC
Cable Diameter Acceptance 4.5mm ~ 7mm
Mounting Type Panel Mount Front/Fix Nut
Contact Material Brass with Gold Plating
Mating Cycle Durability >500 Cycles
Number of Pins 8 pins
Environmental Protection UV Resistant
Protection Method Sealing Gasket and Locknut
Material Zinc Alloy Metal Shell
Flame Retardant Standard UL94-V0
Contact Resistance 5m

LP16 5A 8Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:250V
Withstanding Voltage:2500V
Temperature Rise:10A 30C ,12A 40C ,15A 50C
Insertion and Extraction Force:1.2N Max
Mating Cycle:> 1700 times
Working Temperature:-4080C
Connection Mode:Quick plug connection

Durable Waterproof Design

Crafted with a zinc alloy metal shell and rated IP67, the LP16 connector provides excellent protection against water, dust, and corrosion. Its sealing gasket and locknut make it an ideal choice for outdoor and industrial uses where a robust, long-lasting power and signal connection is essential.

Efficient Power and Signal Transmission

Engineered for reliable performance, this 8-pin female socket supports 5A per pin and up to 500V AC, ensuring high-capacity power and signal transfer. The gold-plated brass contacts maintain low resistance and high conductivity, while its versatile cable diameter acceptance accommodates various wiring needs.

FAQ's of LP16 5A 8Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal:

Q: How is the LP16 5A 8Pin Female Socket installed in a panel?

A: Installation is straightforward: the connector is mounted through a 16mm diameter cutout using the front-fix nut and secured with the included sealing gasket and locknut for a waterproof, stable fit.

Q: What makes this connector suitable for outdoor and industrial environments?

A: Its zinc alloy metal shell, IP67 waterproof rating, UV resistance, and flame retardant UL94-V0 standard provide protection against moisture, dust, UV radiation, and high temperatures, making it ideal for harsh environments.

Q: When should I use this connector instead of other types?

A: This connector is best utilized when secure, high-current, multi-pin connections are needed in environments exposed to water, dust, or outdoor conditions, such as LED lighting, machinery, and power distribution panels.

Q: Where can this connector be used?

A: It is suitable for industrial automation, outdoor installations, power equipment, LED lighting systems, control panels, and any application requiring reliable power or signal connections in challenging environments.

Q: What is the process for connecting wires to the LP16 socket?

A: Wires are soldered directly to the 8-pin terminals on the connector. After soldering, insert the connector into the panel opening, fit the sealing gasket, and secure with the locknut for a secure, water-resistant installation.

Q: What are the usage benefits of this connector?

A: Key benefits include reliable waterproof and dustproof performance, corrosion resistance, secure locking, high current and voltage capacity (5A per pin at 500V AC), and durability for over 500 mating cycles.

Tell us about your requirement

Price:

Quantity

Select Unit

50
100
200
250
500
1000+

Additional detail

Mobile number

Other Products in 'Waterproof Power Connector' category

YM24 3A 24Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal Price : 888.0 INR/Piece Minimum Order Quantity : 100 Product Type : Waterproof Power Connector Color : Black Input : 24Pin Male Plug Dimension (L*W*H) : Approx. 75mm x 28mm x 28mm Rated Voltage : 500V AC Usage : Electrical Wiring/Connection Features : Waterproof, Dustproof, Locking Ring, Corrosion Resistant Frequency : 50/60Hz Current Rating : 3A per Pin Function : Power Connector Components : Male Plug, Plastic Shell, Solder Terminals Output : Solder Terminal Capacity : 3A per Pin Power Supply : Electrical Thickness : Shell Thickness 2mm IP Rating : IP67 Operating Temperature : 40C to +85C Size : Connector Diameter 24mm Application : Industrial Automation, Outdoor Equipment Supply Voltage : Up to 500V Weight : Approx. 75g Interface : 24Pin Male Solder Terminal Power Source : Cable/Electrical Connection

Send Inquiry

LP-20 500V 20A 2Pin Male Plug IP67 Waterproof Power Connector Price : 451.0 INR/Piece Minimum Order Quantity : 100 Product Type : Waterproof Power Connector Color : Black Input : Male Plug Dimension (L*W*H) : 91mm x 28mm x 28mm Rated Voltage : 500V Usage : Outdoor/Industrial Power Connector Features : Waterproof, Dustproof, Corrosion Resistant, Quick Lock Frequency : 50/60Hz Current Rating : 20A Function : Power Connection Components : Plug with Pins, Cable Gland, Locking Nut Output : To Female Socket Capacity : 20A Power Supply : AC/DC Thickness : Standard Housing IP Rating : IP67 Operating Temperature : 40C to +80C Size : Standard Size (LP20 Series) Application : Industrial Equipment, Outdoor Power Distribution, LED Lighting Supply Voltage : 500V Max Weight : Approx. 85g Interface : 2 Pin Male Plug Power Source : Mains Power
