LP16 Series RJ45 Female Inline Plug IP67 Waterproof Ethernet Connector

298.0 INR/Piece

Get a Price/Quote

Product Details:

Input RJ45 Ethernet
Output RJ45 Ethernet
Usage Outdoor / Industrial Ethernet Applications
Features Waterproof, Dustproof, UV Resistant, Corrosion Resistant
Interface RJ45 8P8C
Power Supply Not Required (Passive Connector)
Components Panel Mount Housing, Gasket, RJ45 Inline Socket
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP16 Series RJ45 Female Inline Plug IP67 Waterproof Ethernet Connector Price And Quantity

Minimum Order Quantity 100 Piece
Price 298.0 INR/Piece

Flame Retardant UL94 V-0
Mounting Type Panel Mount
Shell Material High Performance Engineering Plastic (PA66) & Zinc Alloy
Mating Cycle Durability Greater than 500 Cycles
Contact Material Gold-Plated Bronze Contacts
Cable Compatibility Cat5e / Cat6 Ethernet Cable
Shielding 360 Shielding for EMI/RFI Protection
Connector Gender Female-Female Inline
Sealing Gasket Included Yes
Locking Mechanism Threaded Coupling

LP16 Series RJ45 Female Inline Plug IP67 Waterproof Ethernet Connector Product Specifications

Output RJ45 Ethernet
Usage Outdoor / Industrial Ethernet Applications
Dimension (L*W*H) 58.5 x 22 x 22 mm
Features Waterproof, Dustproof, UV Resistant, Corrosion Resistant
Weight Approx. 35g
Input RJ45 Ethernet
Color Black / Silver (Metallic)
Current Rating 5A Max
Supply Voltage DC 60V Max
Thickness 3.5 mm (Shell thickness)
Frequency Ethernet Standard: 10/100/1000 Mbps
Function Ethernet Connectivity and Protection
Size 16 mm (Panel Cutout Diameter)
Capacity Supports up to Gigabit Ethernet
Operating Temperature -20C to +80C
Product Type Female Inline Plug Ethernet Connector
Rated Voltage AC 250V / DC 60V
Interface RJ45 8P8C
Application Networking, Industrial Communication, Outdoor Cables
Power Supply Not Required (Passive Connector)
IP Rating IP67
Components Panel Mount Housing, Gasket, RJ45 Inline Socket

Flame Retardant UL94 V-0
Mounting Type Panel Mount
Shell Material High Performance Engineering Plastic (PA66) & Zinc Alloy
Mating Cycle Durability Greater than 500 Cycles
Contact Material Gold-Plated Bronze Contacts
Cable Compatibility Cat5e / Cat6 Ethernet Cable
Shielding 360 Shielding for EMI/RFI Protection
Connector Gender Female-Female Inline
Sealing Gasket Included Yes
Locking Mechanism Threaded Coupling

LP16 Series RJ45 Female Inline Plug IP67 Waterproof Ethernet Connector Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Modular Interface:RJ45
Operating voltage:42V
Working temperature:-2585C, 85% RH Max
Insulation Resistance:500Mohm
Contact Resistance:40mohm
Insertion force:22.25N Max
Durability:750 cycles

Ultimate Waterproof Protection

Thanks to its IP67 rating, the LP16 Series connector safeguards Ethernet connections against water, dust, and harsh UV, making it ideal for outdoor and industrial sites. The included gasket and precision engineering ensure dependable performance, even in challenging environments.

Reliable High-Speed Connectivity

Engineered to meet 10/100/1000 Mbps Ethernet standards, the LP16 Series supports Cat5e and Cat6 cables for stable Gigabit speeds. Gold-plated bronze contacts offer excellent conductivity, and comprehensive 360 shielding effectively blocks EMI/RFI interference.

Easy, Secure Mounting and Long-Term Durability

The user-friendly panel-mount design, coupled with a sturdy threaded coupling, ensures straightforward installation and tight locking. Built to endure more than 500 mating cycles, this connector delivers years of trouble-free service for networking professionals and installers.

FAQ's of LP16 Series RJ45 Female Inline Plug IP67 Waterproof Ethernet Connector:

Q: How is the LP16 Series RJ45 Inline Plug installed on a panel?

A: The connector features a panel-mount design with a 16 mm cutout diameter. Simply insert the plug into your panel opening, secure using the threaded coupling, and employ the included sealing gasket to ensure a watertight fit.

Q: What types of Ethernet cables are compatible with this connector?

A: The LP16 Series supports both Cat5e and Cat6 Ethernet cables, enabling versatility across a wide range of commercial and industrial networking applications.

Q: When should I use an IP67 waterproof Ethernet connector?

A: An IP67 connector is recommended anytime network connections may be exposed to moisture, dust, or challenging environmental factors, such as in outdoor installations or industrial workspaces.

Q: Where is this connector most commonly used?

A: It's ideal for outdoor networking, industrial automation, field data communication, and any application requiring reliable Ethernet over exposed or hazardous environments.

Q: What are the benefits of the gold-plated contacts and 360 shielding?

A: Gold-plated bronze contacts enhance electrical conductivity and resist corrosion, while 360 shielding protects the network signal from electromagnetic and radio-frequency interference, resulting in stable and secure data transmission.

Q: Does the LP16 Series require an external power supply for operation?

A: No, the LP16 Series functions as a passive connector and does not require a separate power supply. It transmits Ethernet signals only.

Q: How durable is the LP16 Series connector for repeated use?

A: With a mating cycle durability of over 500 cycles, its construction is tailored for frequent connections and disconnections in demanding environments, ensuring long-term, reliable networking.
