25 PIN D SUB CONNECTOR SOLDER LESS

550.0 INR/Piece

Get a Price/Quote

Product Details:

Input Supports up to 25 signal pins
Features Solderless, easy assembly, reliable connection, robust design
Interface DB25 Male/Female
Usage Connecting computer peripherals, industrial equipment interface, and serial communication
Output Supports up to 25 signal pins
Components Plastic housing, metal shell, 25 pin contacts
Power Supply Not applicable (passive component)
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

25 PIN D SUB CONNECTOR SOLDER LESS Price And Quantity

Minimum Order Quantity 10 Piece
Price 550.0 INR/Piece

Contact Plating Gold flash or tin over nickel
Contact Resistance 20 m per contact
Polarity Standard pin layout
Wire Connection Method Screw terminal (no soldering required)
Insulation Resistance >= 1000 M at 500V DC
Connector Gender Available in male (plug) and female (socket)
RoHS Compliance Yes
Construction Material Nickel-plated steel shell, brass/gold-plated or tin contacts, and thermoplastic insulator
Locking Mechanism Thumb screws on both sides for secure locking
Durability > 500 mating cycles
Mounting Panel mount with through holes
Pin Configuration 2 rows (13 pins + 12 pins)

25 PIN D SUB CONNECTOR SOLDER LESS Product Specifications

Components Plastic housing, metal shell, 25 pin contacts
Output Supports up to 25 signal pins
Power Supply Not applicable (passive component)
Function Connector for data and signal transfer between electronic devices
Size Standard DB25 interface
Product Type 25 PIN D SUB CONNECTOR SOLDERIES
Usage Connecting computer peripherals, industrial equipment interface, and serial communication
Rated Voltage 250V AC
IP Rating Not rated
Dimension (L*W*H) Approx. 55 mm x 13 mm x 17 mm
Interface DB25 Male/Female
Application Industrial,Commercial
Weight Approx. 20 grams
Operating Temperature -55C to +105C
Features Solderless, easy assembly, reliable connection, robust design
Color Black & Gray
Supply Voltage Not applicable (signal-level)
Input Supports up to 25 signal pins
Capacity 25 Pins
Warranty 1 Year
Current Rating 5A max per contact
Thickness Standard D-sub thickness; typically around 1.5 mm (shell thickness)

Contact Plating Gold flash or tin over nickel
Contact Resistance 20 m per contact
Polarity Standard pin layout
Wire Connection Method Screw terminal (no soldering required)
Insulation Resistance >= 1000 M at 500V DC
Connector Gender Available in male (plug) and female (socket)
RoHS Compliance Yes
Construction Material Nickel-plated steel shell, brass/gold-plated or tin contacts, and thermoplastic insulator
Locking Mechanism Thumb screws on both sides for secure locking
Durability > 500 mating cycles
Mounting Panel mount with through holes
Pin Configuration 2 rows (13 pins + 12 pins)

25 PIN D SUB CONNECTOR SOLDER LESS Trade Information

Supply Ability 100000 Piece Per Day
Delivery Time 2 Days

Product Description

PRODUCT - 25 PIN M/F CONNECTOR SOLDERLESS
NO OF PINS - 25
PART CODE - CD25PINCONNECTORSOLDERLESS
CURRENT -1A
WIRE RANGE: 20-26AWG
CONNECTOR TYPE: MALE WITH CASEScrews: steel, Cr3+ Zn platedPin header : Brass
color : blackPin header : Brass

Reliable Solderless Connectivity

Engineered for easy and efficient signal connections, this 25 PIN D SUB Connector offers a screw terminal design, eliminating the need for soldering. It supports swift cable assembly while maintaining secure electrical contact and high durability, ideal for applications demanding regular setups or maintenance.

Built for Industrial and Commercial Applications

Constructed with a rugged nickel-plated steel shell and available with gold flash or tin-over-nickel contacts, this connector excels in challenging environments. Its robust structure and reliable contact make it suitable for repetitive mating in industrial, commercial, and interface-intensive operations.

Versatile Compatibility and Mounting

Featuring industry-standard DB25 interface dimensions and polarity, this connector fits seamlessly in panel-mount installations using through holes. Thumbscrew locking on both sides guarantees a stable connection, supporting both male (plug) and female (socket) gender options for diverse installation requirements.

FAQ's of 25 PIN D SUB CONNECTOR SOLDER LESS:

Q: How do I install the 25 PIN D SUB CONNECTOR SOLDER LESS without soldering?

A: The connector uses screw terminals for wire connection. Simply strip your wire ends, insert them into the respective terminals, and tighten the screws-no soldering tools or materials are required. This method ensures a secure, user-friendly installation process.

Q: What materials are used in the construction of this connector?

A: The shell is made from nickel-plated steel for corrosion resistance and mechanical durability. Contacts are crafted from brass and feature either a gold flash or tin plating over nickel. The insulator is constructed from high-grade thermoplastic, ensuring safe and stable signal isolation.

Q: Where can this connector be used effectively?

A: This solderless DB25 connector is ideal for both industrial and commercial settings, including computer peripheral interconnection, industrial machine interfaces, and serial communication links. It's especially suited for environments where reliable, frequent plugging and unplugging is required.

Q: What benefits does the screw terminal (solderless) design offer?

A: The screw terminal design simplifies the assembly process, allowing users to connect and disconnect wires easily without specialized skills or soldering equipment. This feature significantly reduces installation time and maintains strong, consistent connectivity.

Q: Is the connector compatible with both male and female DB25 interfaces?

A: Yes, this product is available in both male (plug) and female (socket) versions, providing flexibility for numerous interface requirements and ensuring compatibility with standard DB25 connections.

Q: What is the operational durability and warranty for the connector?

A: It provides over 500 mating cycles, ensuring long-term use. Additionally, the product is backed by a 1-year warranty, offering quality assurance and reliable support.

Q: How does the locking mechanism work on this connector?

A: The connector is secured using thumbscrews on both sides, which fasten the connector firmly to the panel or mating interface. This prevents accidental disconnection and guarantees stable operation even in vibration-prone environments.
