BD24-RJ45 Series RJ45 Male Plug IP67 Plastic Shell Waterproof Ethernet Connector

480.0 INR/Piece

Get a Price/Quote

Product Details:

Output Ethernet signal
Components RJ45 male plug, plastic waterproof shell, sealing ring
IP Rating IP67
Interface RJ45 Male Plug
Input Ethernet signal
Operating Temperature -40C to +85C
Power Supply Not Applicable (data only)
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

BD24-RJ45 Series RJ45 Male Plug IP67 Plastic Shell Waterproof Ethernet Connector Price And Quantity

Price 480.0 INR/Piece
Minimum Order Quantity 100 Piece

Material High-impact plastic (polyamide/enhanced polymer)
Contact Material Gold-plated phosphor bronze contacts
Cable Diameter Compatibility 5.0mm - 8.5mm
Flame Class UL94 V-0
Environmental Suitability Outdoor, Industrial, Harsh Environments
Corrosion Resistance Excellent (polymer is salt/spray resistant)
Mating Cycles Over 500 cycles
Sealing Method Threaded coupling & circular gasket
Clamping Range Cable gland supports 5.0 mm to 8.5 mm cables
UV Resistance Yes
Connector Gender Male
Shielding Unshielded (plastic shell)
Mounting Type Inline / cable mount

BD24-RJ45 Series RJ45 Male Plug IP67 Plastic Shell Waterproof Ethernet Connector Product Specifications

IP Rating IP67
Interface RJ45 Male Plug
Components RJ45 male plug, plastic waterproof shell, sealing ring
Supply Voltage Up to 48V DC
Usage Outdoor & industrial ethernet connections
Rated Voltage DC 48V Max
Power Supply Not Applicable (data only)
Thickness 3 mm (shell material approx.)
Output Ethernet signal
Features Waterproof, Dustproof, UV Resistant, Corrosion Resistant, Easy Assembly
Function Network connectivity, data transmission
Operating Temperature -40C to +85C
Size Standard RJ45 male dimensions, shell OD approx. 24 mm
Product Type RJ45 Male Plug Connector
Capacity Supports up to Cat6A transmission
Application Ethernet, LAN, Industrial Networks, Outdoor Applications
Weight Approx 28g
Dimension (L*W*H) Approx. 70 x 24 x 24 mm
Color Black / Grey
Current Rating 1.5A Max
Power Source Not Applicable (passive device)
Frequency Up to 500 MHz (Cat6A supported)
Input Ethernet signal

Material High-impact plastic (polyamide/enhanced polymer)
Contact Material Gold-plated phosphor bronze contacts
Cable Diameter Compatibility 5.0mm - 8.5mm
Flame Class UL94 V-0
Environmental Suitability Outdoor, Industrial, Harsh Environments
Corrosion Resistance Excellent (polymer is salt/spray resistant)
Mating Cycles Over 500 cycles
Sealing Method Threaded coupling & circular gasket
Clamping Range Cable gland supports 5.0 mm to 8.5 mm cables
UV Resistance Yes
Connector Gender Male
Shielding Unshielded (plastic shell)
Mounting Type Inline / cable mount

BD24-RJ45 Series RJ45 Male Plug IP67 Plastic Shell Waterproof Ethernet Connector Trade Information

Delivery Time 7 Days

Product Description

Utilise the ace BD24-RJ45 Series RJ45 Male Plug to access blue-ribbon data transmission in demanding environments. With an eminent design forged from high-impact polyamide, this IP67-rated connector guarantees value through longevity, supporting over 500 mating cycles and resisting corrosion, UV, and flame exposure. Suitable for cable diameters from 5.0mm to 8.5mm, its threaded coupling and circular gasket deliver watertight protection. Gold-plated phosphor bronze contacts ensure seamless connectivity for outdoor, industrial, or harsh setting LAN and Ethernet applications-an excellent solution for network professionals.

Versatile Usage Across Industrial and Outdoor Applications

The BD24-RJ45 Series is widely utilised by technicians, network engineers, and industries needing secure, weatherproof LAN connections. Application is easy-simply insert the compatible cable (5.0mm-8.5mm diameter), mount inline, and twist the threaded coupling for a firm, waterproof seal. Its robust, salt and spray-resistant polymer and gold-plated contacts make it ideal for plant automation, industrial networks, and outdoor surveillance setups, ensuring high performance in every critical installation.

Supplying Blue-Ribbon Connectivity Nationwide and Beyond

The ace BD24-RJ45 connectors are dispatched from Indian FOB ports. With abundant supply ability to meet bulk industrial demand, every shipment is expertly packed to protect against goods transport hazards and weather. Goods are delivered in secure exchange-ready boxes, facilitating streamlined distribution to importers, exporters, manufacturers, distributors, traders, and wholesalers. Every phase-from packaging to delivery-ensures product integrity and prompt availability wherever needed.

FAQ's of BD24-RJ45 Series RJ45 Male Plug IP67 Plastic Shell Waterproof Ethernet Connector:

Q: How do I install the BD24-RJ45 Series RJ45 Male Plug in outdoor environments?

A: To install, trim your cable to the 5.0mm-8.5mm compatible diameter, insert it through the gland, and connect the wires to the RJ45 male plug. Then, use the threaded coupling to secure the circular gasket, ensuring an IP67-level waterproof and dustproof seal.

Q: What makes the BD24-RJ45 Connector suitable for harsh and industrial environments?

A: Built from high-impact polyamide and enhanced polymer, this connector offers excellent corrosion, UV, and flame resistance, supporting over 500 cycles. Its IP67 rating and robust sealing make it reliable in exposed industrial or outdoor settings.

Q: When should I use the BD24-RJ45 Series over standard RJ45 connectors?

A: Choose the BD24-RJ45 for outdoor or harsh, industrial areas where water, dust, or corrosive elements threaten regular connectors. It provides enhanced sealing and resistance, outperforming standard RJ45 plugs in challenging conditions.

Q: Where can the BD24-RJ45 Male Plug be typically applied?

A: This connector is a preferred choice for Ethernet, LAN, plant automation, outdoor surveillance, and network infrastructure across various sectors including manufacturing, utilities, and telecom installations.

Q: What is the benefit of the gold-plated phosphor bronze contacts in this connector?

A: Gold-plated contacts significantly reduce signal loss and enhance conductivity, delivering reliable, high-speed network performance up to Cat6A transmission standards even in demanding environments.
