LP20 500V 10A 5Pin Female Plug IP67 Waterproof Power Connector

604.0 INR/Piece

Get a Price/Quote

Product Details:

Output To 5-pin male connector
Power Source External power
Interface 5-Pin Female
Operating Temperature -25C to +85C
Power Supply AC/DC Power
Input Cable input (female)
Components Plastic body, copper pins, sealing gasket
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP20 500V 10A 5Pin Female Plug IP67 Waterproof Power Connector Price And Quantity

Minimum Order Quantity 100 Piece
Price 604.0 INR/Piece

Mounting Style Inline cable mount
Insulation Resistance > 500M at 500VDC
Material Nylon (PA66) housing with copper alloy contacts
Wire Range up to 12mm2
Mating Cycle > 500 cycles
Contact Resistance 2m
Standards Compliance CE, RoHS
Locking Mechanism Threaded coupling
Cable Diameter Compatibility 6-12mm
Connector Gender Female

LP20 500V 10A 5Pin Female Plug IP67 Waterproof Power Connector Product Specifications

Dimension (L*W*H) Approx. 54mm (Length) x 28mm (Diameter)
Interface 5-Pin Female
Usage Electrical wiring and device connection
Capacity 10A
Frequency 50/60Hz
IP Rating IP67
Supply Voltage 500V max
Size LP20 series
Function Power connection for industrial equipment
Power Source External power
Features Waterproof, vibration-resistant, dustproof, secure connection
Components Plastic body, copper pins, sealing gasket
Color Black
Product Type Waterproof Power Connector
Rated Voltage 500V
Weight Approx. 80g
Current Rating 10A
Operating Temperature -25C to +85C
Output To 5-pin male connector
Input Cable input (female)
Application Industrial, Outdoor, Automation, LED lighting, Equipment
Power Supply AC/DC Power

Mounting Style Inline cable mount
Insulation Resistance > 500M at 500VDC
Material Nylon (PA66) housing with copper alloy contacts
Wire Range up to 12mm2
Mating Cycle > 500 cycles
Contact Resistance 2m
Standards Compliance CE, RoHS
Locking Mechanism Threaded coupling
Cable Diameter Compatibility 6-12mm
Connector Gender Female

LP20 500V 10A 5Pin Female Plug IP67 Waterproof Power Connector Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Connecting Mode:Latching Lock connect
Cable Specification:1.01.5mm/18-16AWG
Diameter Range:7mm 10mm
Operating Voltage:500V
Withstand Voltage(AC.V)1min:2500V
Durability:> 1500 mating & unmating cycles
Temperature Rating:-40C80C

Enhanced Durability and Safety

Built with a sturdy plastic body and copper alloy pins, the LP20 connector boasts excellent insulation resistance (>500M at 500VDC) and low contact resistance (2m), ensuring both safety and efficiency. The sealing gasket and threaded coupling lock provide reliable protection against dust, water, and mechanical stress, making it optimal for demanding environments.

Versatile Application Scope

Engineered for industrial, automation, and outdoor settings, this connector is suitable for LED lighting, electrical equipment, and machinery wiring. Its wide operating temperature range (-25C to +85C) and compatibility with both AC and DC power expand its usability across various installations and power supply systems.

FAQ's of LP20 500V 10A 5Pin Female Plug IP67 Waterproof Power Connector:

Q: How do I install the LP20 5Pin Female Connector for a secure electrical connection?

A: To install, strip your cable to fit wire sizes up to 12mm2 and ensure the cable diameter is between 6-12mm. Insert the stripped wires into the connector, secure them as per the terminal instructions, and use the threaded coupling to fasten the connection tightly. The sealing gasket ensures an IP67-rated waterproof seal.

Q: What are the main benefits of using this power connector in industrial and outdoor applications?

A: This connector offers a waterproof, vibration-resistant, and dustproof solution, ensuring reliable operation even in harsh environments. Its robust nylon housing, high insulation resistance, and secure threaded locking mechanism guarantee a safe and stable power connection.

Q: When should I choose this 5-pin connector over others for my equipment?

A: Choose this connector when you require high voltage (up to 500V) and current (up to 10A) support, reliable environmental protection (IP67), and longevity (over 500 mating cycles). It is ideal for powering industrial equipment, automation systems, and outdoor LED setups.

Q: Where is the LP20 5Pin Female Plug typically used?

A: This connector is commonly used in industrial automation, outdoor machinery, LED lighting installations, and electrical distribution systems where durable and safe connections are necessary.

Q: What is the process for maintaining or replacing this connector over time?

A: Periodic inspection is recommended: check for signs of wear, verify that all seals are intact, and ensure no corrosion on the contacts. Replacement is straightforward; simply unscrew the threaded coupling, disconnect the wires, and install a new unit as originally configured.

Q: Can this connector handle both AC and DC power supplies, and what standards does it comply with?

A: Yes, the LP20 5Pin Female Plug is designed for both AC and DC power supplies up to 500V, rated at 10A. It is compliant with CE and RoHS standards, ensuring electrical safety and environmental stewardship.
