LP20 5A 12Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal

510.0 INR/Piece

Get a Price/Quote

Product Details:

Interface Solder terminal
Features Waterproof, dustproof, corrosion resistant, secure lock, robust metal shell
Operating Temperature -25C to +85C
IP Rating IP67
Power Supply Electrical
Usage Outdoor power distribution, Industrial automation, Lighting systems
Power Source Electrical
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP20 5A 12Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 510.0 INR/Piece

Mating Style Bayonet lock
Number of Contacts 12 pins
Mounting Type Panel mount
Recommended Panel Cutout 20mm diameter
Connection Type Solder terminal
Flame Retardant Grade UL94-V0
Contact Material Copper alloy, gold-plated
Mechanical Life >500 mating cycles
Shell Material Zinc alloy with nickel plating
Sealing Method Silicone rubber gasket
RoHS Compliance Yes
Insulation Resistance >2000M at 500V DC
Withstanding Voltage 1500V AC/min
Contact Resistance 5m
Wire Gauge Support 24-18 AWG
Environmental Protection UV resistant, vibration resistant

LP20 5A 12Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal Product Specifications

Rated Voltage 500V AC
Output Multi-pin output (12 positions)
Components Female socket, metal shell, solder terminals
Application Industrial equipment, electronic devices, outdoor installations
Capacity 12-pin socket
Function Power and signal connection
Current Rating 5A per pin
Color Metallic grey
Supply Voltage Up to 500V AC
Size 20mm mounting diameter
Frequency 50/60Hz
Usage Outdoor power distribution, Industrial automation, Lighting systems
Product Type Panel Mount Power Connector
Power Source Electrical
Input Multi-pin input (12 positions)
Features Waterproof, dustproof, corrosion resistant, secure lock, robust metal shell
Interface Solder terminal
Weight Approx. 40g
Thickness Standard panel thickness 1-5mm
Operating Temperature -25C to +85C
Power Supply Electrical
Dimension (L*W*H) Approx. 38mm 24mm 24mm
IP Rating IP67

Mating Style Bayonet lock
Number of Contacts 12 pins
Mounting Type Panel mount
Recommended Panel Cutout 20mm diameter
Connection Type Solder terminal
Flame Retardant Grade UL94-V0
Contact Material Copper alloy, gold-plated
Mechanical Life >500 mating cycles
Shell Material Zinc alloy with nickel plating
Sealing Method Silicone rubber gasket
RoHS Compliance Yes
Insulation Resistance >2000M at 500V DC
Withstanding Voltage 1500V AC/min
Contact Resistance 5m
Wire Gauge Support 24-18 AWG
Environmental Protection UV resistant, vibration resistant

LP20 5A 12Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:250V
Withstanding voltage:2500V
Mating cycle:1700 Times
Temperature and humidity:-40+80C; 40C, 85%RH
Contact dimension:Phi 2.7x3
Screw torque:42-53 (N.m)

Rugged Durability Meets Reliable Performance

Constructed with a zinc alloy shell and nickel plating, the LP20 Female Socket offers excellent protection against corrosion and mechanical wear. Its IP67 rating ensures comprehensive waterproof and dustproof capabilities, while a silicone gasket delivers a secure environmental seal. Designed to handle tough usage, this connector is well-suited for demanding outdoor and industrial applications.

Superior Electrical and Signal Connectivity

The LP20 12-pin socket supports both power and signal connections with a current rating of 5A per pin and a maximum voltage of 500V AC. Gold-plated copper alloy contacts ensure low contact resistance and reliable signal transmission. This connector is perfect for systems requiring multi-channel inputs and outputs, such as industrial control panels, outdoor lighting, or automation setups.

Easy, Secure Installation and Mating

Panel mounting is effortless with its 20mm recommended cutout, supporting standard panel thicknesses from 1-5mm. The bayonet lock design allows quick and secure connections, and the solder terminal type ensures robust cable attachment. With a mechanical life exceeding 500 cycles, maintenance and replacements are minimized over time.

FAQ's of LP20 5A 12Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal:

Q: How is the LP20 12Pin Female Socket installed on a panel?

A: The LP20 Female Socket is designed for panel mount applications and requires a 20mm diameter cutout in the mounting surface. Secure the connector using the mounting hardware provided, and connect your wires to the solder terminals as per your wiring diagram.

Q: What benefits does the IP67 rating provide for this connector?

A: The IP67 rating safeguards the connector against dust ingress and temporary immersion in water, making it highly reliable for outdoor installations, industrial environments, and areas exposed to adverse weather conditions.

Q: Where can this 12-pin connector be used?

A: This connector is suitable for outdoor power distribution, industrial automation panels, electronic devices, and lighting systems, especially where robust environmental protection and secure electrical connections are critical.

Q: What process should I follow to solder wires to the terminals?

A: Prepare your wires within the supported 24-18 AWG range, strip the ends, and carefully solder them to the 12 available terminals. Ensure there are no cold joints and that each connection is insulated and secured before panel mounting.

Q: What are the advantages of using a bayonet lock mating style?

A: The bayonet lock mechanism enables quick, secure, and vibration-resistant mating and unmating, reducing installation time and preventing accidental disconnects during operation in high-activity environments.

Q: When should I consider this connector for my application?

A: Choose this connector when you need reliable multi-pin connections for power and signal transmission, especially in challenging conditions requiring waterproof and UV-resistant performance, such as outdoor or industrial locations.

Q: What makes the LP20 connector resistant to corrosion and harsh environments?

A: Its zinc alloy shell with nickel plating and silicone rubber gasket provide robust corrosion resistance, while its UV resistance and flame-retardancing (UL94-V0) further ensure longevity and safety in demanding outdoor settings.
