LP24 250V 5A 19Pin Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal

764.0 INR/Piece

Get a Price/Quote

Product Details:

Power Source Wired
Power Supply Wire to wire
Output 19-pin interface
Features Waterproof, dustproof, corrosion-resistant, secure locking
Operating Temperature -40C to +85C
Usage Outdoor and industrial machinery
Interface 19 pin solder terminal
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP24 250V 5A 19Pin Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 764.0 INR/Piece

Mounting Type Cable mount
Insulation Resistance >1000 M @ 500VDC
Mating Cycle 500 cycles
Standards Compliance RoHS compliant, CE approved
Termination Style Solder terminals
Flame Rating UL94-V0
Sealing Method O-ring and thread coupling
Contact Material Copper alloy, gold plated
Shell Material Plastic + metal
Mechanical Durability High, robust construction
Connector Gender Male
Contact Resistance 5m
Number of Contacts 19 pins

LP24 250V 5A 19Pin Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal Product Specifications

Application Signal and power transmission
Capacity 5A current carrying capacity
Dimension (L*W*H) Approx. 80mm x 34mm x 34mm
Color Black and Silver
Power Source Wired
Power Supply Wire to wire
Output 19-pin interface
Features Waterproof, dustproof, corrosion-resistant, secure locking
Thickness Shell thickness approx. 2mm
Weight Approx. 95g
Size Standard LP24 plug size
Current Rating 5A
Product Type Waterproof power connector
Supply Voltage 250V max
Operating Temperature -40C to +85C
Frequency 50/60Hz compatible
Usage Outdoor and industrial machinery
Rated Voltage 250V AC
Interface 19 pin solder terminal
IP Rating IP67
Components Male plug, outer shell, solder terminals
Input Male plug
Function Power connection for electrical equipment

Mounting Type Cable mount
Insulation Resistance >1000 M @ 500VDC
Mating Cycle 500 cycles
Standards Compliance RoHS compliant, CE approved
Termination Style Solder terminals
Flame Rating UL94-V0
Sealing Method O-ring and thread coupling
Contact Material Copper alloy, gold plated
Shell Material Plastic + metal
Mechanical Durability High, robust construction
Connector Gender Male
Contact Resistance 5m
Number of Contacts 19 pins

LP24 250V 5A 19Pin Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:250V
Insertion and extraction force:22N Max
Withstanding voltage:1500V
Wire Gauge:0.340.75mm/22 - 20AWG
Temperature and humidity:-40+80C; 40C, 85%RH
Screw torque:42-53 (Nm)

Durable and Reliable Construction

Engineered with a combination of plastic and metal shell, and gold-plated copper alloy contacts, the LP24 connector offers enhanced mechanical durability and robust performance. Its flame-retardant casing and secure sealing provide long-term reliability even in harsh environments.

Superior Waterproof and Dustproof Protection

With an IP67 rating, the LP24 19-pin plug is perfectly suited for outdoor and industrial settings. The O-ring and threaded coupling ensure secure, leak-proof operation, protecting your connections from water, dust, and corrosion.

Versatile Application and Easy Installation

Suitable for transmitting both power and signals, the LP24 male plug serves a wide range of industrial and machinery needs. Its solder terminal connection enables straightforward assembly and cable mounting, making installation efficient and dependable.

FAQ's of LP24 250V 5A 19Pin Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal:

Q: How is the LP24 19Pin Male Plug installed and connected?

A: The LP24 male plug is a cable-mounted connector with solder terminal contacts. Simply solder your wires to the terminals inside the plug, then secure the outer shell using the threaded coupling and O-ring to ensure a tight, waterproof connection.

Q: What types of environments is this connector best suited for?

A: This connector is ideal for outdoor and industrial environments, thanks to its IP67 waterproof and dustproof rating, as well as its corrosion-resistant construction. Its robust design handles harsh weather, dust, and moisture, ensuring reliable operation.

Q: What are the benefits of using gold-plated copper alloy contacts?

A: Gold-plated copper alloy contacts provide excellent conductivity, reduced contact resistance, and improved corrosion resistance. This ensures stable power and signal transmission over time, especially in demanding industrial settings.

Q: When should I use this connector for my equipment?

A: The LP24 19Pin Male Plug is perfect for applications requiring both power and signal transmission through a single compact, rugged connector. Use it when connecting machinery or electrical equipment in environments where durability and watertight sealing are paramount.

Q: What is the maximum voltage and current rating for this connector?

A: This plug supports a maximum voltage of 250V AC and a current of up to 5A, making it suitable for moderate-power applications in electrical equipment and industrial machinery.

Q: How does its sealing mechanism protect the connection?

A: The LP24 plug utilizes an O-ring combined with a threaded coupling to create a secure seal. This design prevents water, dust, and contaminants from entering the connector, maintaining its IP67-rated protection during operation.
