LP28 500V 15A 8Pin Male Plug IP67 Waterproof Power Connector

1014.0 INR/Piece

Get a Price/Quote

Product Details:

IP Rating IP67
Operating Temperature -40C to +80C
Output 8-pin connection
Usage Industrial power equipment
Power Supply AC/DC
Power Source Wired electrical
Features Waterproof, dustproof, vibration resistant, corrosion resistant
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP28 500V 15A 8Pin Male Plug IP67 Waterproof Power Connector Price And Quantity

Minimum Order Quantity 100 Piece
Price 1014.0 INR/Piece

Contact Material Copper alloy, gold-plated
Number of Pins 8 (male)
Cable Diameter 8mm - 12mm
Mating Cycle Durability >500 cycles
Sealing Material Silicone rubber gasket
Wire Range 1.5mm2 - 2.5mm2
Contact Resistance 2.5m
Shell Material Zinc alloy with nickel plating
Mechanical Operation Bayonet-locking system
Flame Rating UL94-V0
Insulation Resistance >2000M at 500VDC

LP28 500V 15A 8Pin Male Plug IP67 Waterproof Power Connector Product Specifications

Features Waterproof, dustproof, vibration resistant, corrosion resistant
Operating Temperature -40C to +80C
Size LP28
IP Rating IP67
Power Source Wired electrical
Power Supply AC/DC
Application Outdoor, industrial, automation, machinery
Function Power connection and distribution
Current Rating 15A
Output 8-pin connection
Supply Voltage 500V max
Color Black/Silver
Input 8-pin male socket
Components Plug housing, contact pins, cable gland
Product Type Waterproof power connector plug
Rated Voltage 500V
Dimension (L*W*H) Approx. 110mm x 34mm x 34mm
Frequency 50/60Hz
Thickness Standard
Usage Industrial power equipment
Capacity 15A (per pin) max
Weight Approx. 150g

Contact Material Copper alloy, gold-plated
Number of Pins 8 (male)
Cable Diameter 8mm - 12mm
Mating Cycle Durability >500 cycles
Sealing Material Silicone rubber gasket
Wire Range 1.5mm2 - 2.5mm2
Contact Resistance 2.5m
Shell Material Zinc alloy with nickel plating
Mechanical Operation Bayonet-locking system
Flame Rating UL94-V0
Insulation Resistance >2000M at 500VDC

LP28 500V 15A 8Pin Male Plug IP67 Waterproof Power Connector Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:500V
Wire Specification:2.5mm-4.0mm
Line Diameter Range:13mm15mm
Withstand Voltage (AC.V) 1 Minute:2500V
Mating Cycle:>500 times
Working Temperature:-4080C
Connection Mode:Quick Plug Connection
Wiring Mode:Solder

Versatile Industrial Power Connector

Engineered for industrial power distribution, this 8-pin male plug is optimized for machinery and automation systems operating in challenging conditions. Its weatherproof and dustproof IP67 construction ensures reliability even in harsh outdoor environments. The connector's strong zinc alloy body protects sensitive power connections, while the secure bayonet-locking system guarantees a stable, long-lasting fit for frequent operations.

High-Performance Materials and Design

The LP28 plug utilizes premium materials, including gold-plated copper contacts for optimal electrical conductivity and a nickel-plated zinc shell for corrosion resistance. Dual silicone rubber gaskets enhance its sealing capability, while a UL94-V0 flame rating ensures added safety in industrial settings. These features collectively provide superior performance, safety, and operational longevity.

Easy Installation and Maintenance

Suitable for wire sizes between 1.5mm2 and 2.5mm2, the LP28 connector allows quick, secure cable terminations via a user-friendly bayonet-locking system. Its structure simplifies installation, while routine maintenance is minimal thanks to its high durability. Designed for both importers and manufacturers, this plug offers a dependable power connection solution for diverse electrical equipment.

FAQ's of LP28 500V 15A 8Pin Male Plug IP67 Waterproof Power Connector:

Q: How do I install the LP28 8Pin Male Plug for optimal waterproof performance?

A: To achieve optimal waterproofing, ensure cables with diameters between 8mm and 12mm are used. Insert wires within the specified range (1.5mm2 - 2.5mm2) into the contact pins, secure the bayonet-locking mechanism until fully locked, and verify the silicone rubber gasket is properly seated. This process maintains the IP67 rating and protects against water ingress.

Q: What type of equipment is this connector suitable for?

A: The LP28 8Pin male plug is ideal for industrial power equipment, automation systems, outdoor machinery, and environments where strong insulation, vibration resistance, and waterproofing are critical. Its robust construction makes it suitable for both AC and DC connections in challenging conditions.

Q: When should I consider using an IP67-rated connector like the LP28?

A: Choose the LP28 connector when your application demands protection against dust, water immersion, or exposure to harsh environmental elements. It is especially recommended for outdoor or industrial uses where reliability and safety under adverse conditions are essential.

Q: Where can this connector be installed?

A: This connector can be installed in outdoor, industrial, automation, and machinery settings across manufacturing plants or construction sites. Its rugged design withstands extreme temperatures and environmental hazards often encountered in these locations.

Q: What is the process for connecting power cables with this connector?

A: Begin by stripping the insulation from the cable within the recommended diameter and wire size range. Insert the cables into the corresponding contact pins, tighten securely, and engage the bayonet-locking system. Ensure the silicone rubber gasket fits snugly for a watertight seal before powering up the system.

Q: What are the main benefits of using the LP28 8Pin Male Plug?

A: The key benefits include superior waterproof and dustproof protection (IP67), excellent electrical conductivity, high current and voltage handling (15A, 500V), robust mechanical security via bayonet-locking, corrosion and vibration resistance, and extended durability through over 500 mating cycles.
