LP28 500V 35A 3Pin Male Plug IP67 Waterproof Power Connector

1113.0 INR/Piece

Get a Price/Quote

Product Details:

Interface Screw Lock/Thread Lock
IP Rating IP67
Power Supply AC
Usage Waterproof Power Transmission
Input 3-Pin Male Connector
Features Waterproof, Dustproof, Corrosion Resistant, High Durability
Operating Temperature -40C to +105C
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP28 500V 35A 3Pin Male Plug IP67 Waterproof Power Connector Price And Quantity

Minimum Order Quantity 100 Piece
Price 1113.0 INR/Piece

Flammability Rating UL94 V-0
Contact Material Copper Alloy with Silver Plating
Mating Cycles >500
Insulation Material High Grade Engineering Plastic
Connector Type LP28 Series, Circular
Wire Gauge Supported 2.5 mm2 - 6 mm2
Shell Material Nickel-Plated Brass
Mounting Type Cable Mount
Number of Pins 3 Pin
Sealing Method Integral Rubber O-Ring

LP28 500V 35A 3Pin Male Plug IP67 Waterproof Power Connector Product Specifications

Frequency 50/60Hz
Features Waterproof, Dustproof, Corrosion Resistant, High Durability
Input 3-Pin Male Connector
Current Rating 35A
Components Connector Shell, Pins, Rubber Seals
Power Source Electric
Operating Temperature -40C to +105C
Output Electrical Power
Weight Approximately 210g
Thickness Standard
Application Outdoor and Industrial Environments, Heavy Equipment
Rated Voltage 500V
Power Supply AC
Function Power Connection for Industrial Applications
Product Type Male Plug Power Connector
IP Rating IP67
Color Black / Blue
Size 28mm Connector Series
Supply Voltage 500 Volts AC/DC
Interface Screw Lock/Thread Lock
Dimension (L*W*H) Approx. 115mm x 37mm x 37mm
Capacity 35A Continuous Current
Usage Waterproof Power Transmission

Flammability Rating UL94 V-0
Contact Material Copper Alloy with Silver Plating
Mating Cycles >500
Insulation Material High Grade Engineering Plastic
Connector Type LP28 Series, Circular
Wire Gauge Supported 2.5 mm2 - 6 mm2
Shell Material Nickel-Plated Brass
Mounting Type Cable Mount
Number of Pins 3 Pin
Sealing Method Integral Rubber O-Ring

LP28 500V 35A 3Pin Male Plug IP67 Waterproof Power Connector Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:500V
Wire Specification:2.5mm5mm/14-12AWG
Line Diameter Range:18mm20mm
Working Temperature:-4080C
Connection Mode:Quick Plug Connection
Wiring Mode:Welding / Crimping

Reliable Power in Demanding Environments

Engineered for outdoor and industrial usage, the LP28 Series circular connector thrives where reliability is critical. Its IP67 rating guarantees protection against dust and water immersion, making it ideal for heavy machinery, construction sites, and other extreme settings. The robust design ensures uninterrupted operation, even in fluctuating temperatures from -40C up to +105C.

Superior Material and Construction

Using nickel-plated brass for the shell and high-grade engineering plastic for insulation, this connector provides exceptional resistance to corrosion and wear. The internal copper alloy contacts, enhanced with silver plating, provide excellent conductivity and low contact resistance. These features ensure the connector performs reliably even after more than 500 mating cycles.

FAQ's of LP28 500V 35A 3Pin Male Plug IP67 Waterproof Power Connector:

Q: How does the LP28 3Pin Male Plug ensure waterproof and dustproof performance?

A: This connector is rated IP67, which means it is fully protected against dust ingress and can withstand temporary immersion in water. The integral rubber O-ring creates a tight seal around the mating interface, ensuring reliable operation in wet or harsh environments.

Q: What is the process for installing the LP28 series connector?

A: Installation involves mounting the connector onto the cable (supports 2.5 mm2 to 6 mm2 gauges), inserting and securing the wires to the three pins, and then using the thread or screw lock mechanism to join male and female components. This ensures a secure, vibration-proof connection.

Q: Where can the LP28 power connector be used?

A: It is suitable for outdoor or industrial environments, including heavy equipment, machinery, construction sites, and any application requiring waterproof and reliable AC power connection up to 500V and 35A.

Q: What benefits does the silver plating on the contacts provide?

A: Silver plating on the copper alloy contacts improves electrical conductivity, reduces contact resistance, and enhances corrosion resistance. This extends the lifespan of the connector and ensures consistent power delivery.

Q: When is this connector recommended over standard power plugs?

A: The LP28 connector is preferred when you need robust waterproofing, high current capacity, and resistance to harsh environmental conditions-applications where standard plugs might fail or degrade quickly.

Q: What safety features does the LP28 power connector offer?

A: Its high-grade insulation meets the UL94 V-0 flammability standard, and the nickel-plated brass shell resists corrosion. The thread/screw locking system prevents accidental disconnection, while the rubber O-ring ensures a safe, sealed interface.
