YM20 250V 5A 9Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal

Name: YM20 250V 5A 9Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 387.0 INR
Availability: InStock

387.0 INR/Piece

Get a Price/Quote

Product Details:

Usage Cable Connection, Power Transmission, Industrial Automation
Components Plastic Shell, Metal Pins, Sealing Gasket
Interface 9Pin Male
Power Source Electric
Power Supply Electrical
Operating Temperature -40C to +85C
IP Rating IP67
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

YM20 250V 5A 9Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal Price And Quantity

Price 387.0 INR/Piece
Minimum Order Quantity 100 Piece

Pin Number 9
Sealing Method Rubber Gasket and O-Ring
Mounting Type Cable Mount
Cable Diameter Range 7mm - 12mm
Contact Resistance 5m
Coupling Method Threaded Coupling
Shell Material High-strength Plastic
Insulation Resistance 1000M at 500V DC
Pin Material Brass with Silver Plating
Connector Type Male Plug
Flame Retardant Level UL94-V0

YM20 250V 5A 9Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal Product Specifications

Thickness Standard
Current Rating 5A
Interface 9Pin Male
Capacity 5A Max
Power Source Electric
Product Type Waterproof Power Connector
Dimension (L*W*H) Approx. 75mm Length, 20mm Diameter
Usage Cable Connection, Power Transmission, Industrial Automation
Supply Voltage AC 250V
Size YM20 series
Components Plastic Shell, Metal Pins, Sealing Gasket
Application Outdoor Equipment, LED Lighting, Electrical Power Supply, Industrial Control
Features Waterproof, Dustproof, Solder Terminal, Reliable Locking Mechanism
Input Male Plug
Color Black
Power Supply Electrical
Rated Voltage 250V AC
Function Power Connector
Weight Approx. 50g
Operating Temperature -40C to +85C
IP Rating IP67
Output 9 Solder Terminals

Pin Number 9
Sealing Method Rubber Gasket and O-Ring
Mounting Type Cable Mount
Cable Diameter Range 7mm - 12mm
Contact Resistance 5m
Coupling Method Threaded Coupling
Shell Material High-strength Plastic
Insulation Resistance 1000M at 500V DC
Pin Material Brass with Silver Plating
Connector Type Male Plug
Flame Retardant Level UL94-V0

YM20 250V 5A 9Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Withstanding voltage:1500V
Operating Voltage:250V
Contact dimension:Phi 1*9
Insertion and extraction force:2.7N Max
Temperature and humidity:-4080C; 40C, 85%RH

Superior Waterproof and Dustproof Protection

Engineered with an IP67-rated sealing system, including a rubber gasket and O-ring, the YM20 connector provides outstanding protection against water ingress and dust. This makes it a perfect choice for outdoor equipment and harsh industrial settings, delivering reliable performance even in unfavorable weather or wet conditions.

Robust Construction for Demanding Applications

Featuring a flame-retardant UL94-V0 plastic shell and corrosion-resistant brass pins with silver plating, the YM20 connector ensures both safety and longevity. Its threaded coupling design provides secure cable mounting and a firm electrical connection. Withstanding temperatures from -40C to +85C, it operates flawlessly in diverse environments.

FAQ's of YM20 250V 5A 9Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal:

Q: How is the YM20 9Pin Male Plug installed and what tools are required?

A: The YM20 connector is mounted onto cables using its threaded coupling method. You will need standard wire preparation tools and a soldering iron to connect wires to the 9 solder terminals. After soldering, secure the connector body and tighten the thread for watertight sealing.

Q: What makes the YM20 connector suitable for outdoor and industrial use?

A: This connector boasts an IP67 waterproof rating and uses high-strength, flame-retardant plastic with a rubber gasket and O-ring. Its robust materials and secure sealing protect against dust, moisture, and harsh temperatures, making it ideal for demanding environments.

Q: When should I use the YM20 9Pin Male Plug instead of other connectors?

A: Choose the YM20 when your application requires up to 9 connections, reliable power transmission (up to 5A at 250V AC), and protection against water and dust, especially in outdoor or industrial environments where robust locking and high insulation are essential.

Q: Where can the YM20 connector be applied?

A: The YM20 is commonly used in LED lighting systems, industrial automation panels, outdoor electrical equipment, and power supply connections that require secure, multi-pin, waterproof connectors.

Q: What is the process for ensuring a proper waterproof seal?

A: After soldering your wires to the terminals, fit the cable within the designated diameter range (7mm-12mm), insert the rubber gasket and O-ring, and screw the connector's shell tightly using the threaded coupling. This ensures a reliable, IP67-rated seal.

Q: What benefits does the silver plating on the pins provide?

A: The silver plating on brass pins offers excellent electrical conductivity and resistance to corrosion, ensuring stable and efficient power delivery across all nine terminals over extended periods.
