YM20 400V 12A 5Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal

Name: YM20 400V 12A 5Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 403.0 INR
Availability: InStock

403.0 INR/Piece

Get a Price/Quote

Product Details:

Power Supply External power supply
Power Source Electrical connection, plug-in
Features Waterproof, dustproof, vibration-resistant, corrosion-resistant, high mechanical strength
Input Up to 400V, 12A max
Components 1 x 5Pin male connector, plastic shell, solder terminals
Output Up to 400V, 12A max
IP Rating IP67
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

YM20 400V 12A 5Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 403.0 INR/Piece

Mechanical Life > 500 mating cycles
Sealing Method Rubber O-ring gasket
Wire Range 0.5mm2 to 2.5mm2
Shell Type Cylindrical
Contact Resistance 5m
Compatibility Suitable for matching YM20 Series female connectors
Material High-quality plastic shell with copper alloy contacts
Locking Mechanism Bayonet locking
Flame Retardant Standard UL94 V-0
Mounting Type Cable mount
Insulation Resistance > 2000 M at 500V DC
Connection Type Solder terminal

YM20 400V 12A 5Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal Product Specifications

Operating Temperature -40C to +105C
Features Waterproof, dustproof, vibration-resistant, corrosion-resistant, high mechanical strength
Size YM20 Series
IP Rating IP67
Power Supply External power supply
Power Source Electrical connection, plug-in
Application Power distribution, machinery, automation systems, marine, lighting
Function Power connector for electrical connections
Current Rating 12A
Output Up to 400V, 12A max
Supply Voltage 400V
Color Black
Input Up to 400V, 12A max
Components 1 x 5Pin male connector, plastic shell, solder terminals
Product Type Male Plug Connector
Rated Voltage 400V AC/DC
Dimension (L*W*H) 88mm x 35mm x 35mm (approx.)
Frequency 50/60 Hz
Usage Industrial and outdoor equipment
Capacity 12A continuous current
Weight Approx. 90g
Interface 5Pin male plug, solder terminal

Mechanical Life > 500 mating cycles
Sealing Method Rubber O-ring gasket
Wire Range 0.5mm2 to 2.5mm2
Shell Type Cylindrical
Contact Resistance 5m
Compatibility Suitable for matching YM20 Series female connectors
Material High-quality plastic shell with copper alloy contacts
Locking Mechanism Bayonet locking
Flame Retardant Standard UL94 V-0
Mounting Type Cable mount
Insulation Resistance > 2000 M at 500V DC
Connection Type Solder terminal

YM20 400V 12A 5Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:400V
Withstanding voltage:2000V
Contact dimension:Phi 1.8*5
Insertion and extraction force:8.2N Max
Mating cycle:1700 Times
Screw torque:42-53 (N.m)
Temperature and humidity:-4080C; 40C, 85%RH

Exceptional Durability and Reliability

This connector is designed to handle the rigors of industrial, marine, and automation environments. The high-quality plastic shell and copper alloy contacts deliver superior conductivity and mechanical strength while withstanding exposure to vibration, moisture, and dust. Its mechanical life exceeds 500 mating cycles, ensuring a long service duration even in demanding conditions.

Waterproof and Secure Connection

With its IP67 waterproof rating and rubber O-ring gasket, the YM20 plug offers secure, moisture-proof operation. The bayonet locking mechanism prevents accidental disconnection, and the dustproof build keeps contaminants out, making it ideal for outdoor equipment, marine, and power distribution settings.

Versatile Applications and Easy Integration

Compatible with the YM20 Series female connectors, this 5-pin male plug is suitable for use in diverse fields such as machinery, automation, lighting systems, and power distribution panels. Its solder terminals provide a reliable connection, and its cable-mount design supports wire sizes from 0.5mm2 to 2.5mm2 for easy, flexible installation.

FAQ's of YM20 400V 12A 5Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal:

Q: How is the YM20 5Pin Male Plug typically installed?

A: The plug is cable-mounted and utilises solder terminals for wire attachment. Simply prepare wires within the 0.5mm2 to 2.5mm2 range, solder them to the respective terminals, and secure the cable in the connector housing for a robust installation.

Q: What environments is this connector designed for?

A: With its IP67 waterproof rating, flame-retardant UL94 V-0 compliant shell, and rugged build, the YM20 connector is ideal for industrial, outdoor, marine, and automated machinery environments where moisture, dust, and vibration resistance are essential.

Q: When should the YM20 plug be used over other connectors?

A: Choose this connector when high-current (up to 12A), mid-voltage (up to 400V AC/DC), water and dustproof, and mechanical durability are vital requirements. It's particularly suitable for demanding environments requiring frequent mating and unmating.

Q: Where can the YM20 connector be applied?

A: Common applications include power distribution units, automation equipment, outdoor lighting systems, marine electronics, and other industrial settings that require reliable, safe power connections.

Q: What is the mating process, and how secure is the connection?

A: The YM20 uses a bayonet locking mechanism for quick and secure connections. After aligning the plug and matching female connector, twist and lock for a stable, vibration-resistant connection resistant to accidental unplugging.

Q: What benefits does the high-quality plastic and copper alloy construction offer?

A: The plastic shell delivers high mechanical strength and corrosion resistance, while copper alloy contacts provide excellent electrical conductivity and low contact resistance, ensuring efficient and safe power transmission.

Q: How does the waterproof feature enhance safety and longevity?

A: The IP67 rating, achieved with a rubber O-ring gasket, protects internal contacts from water and dust intrusion. This prevents corrosion, reduces maintenance needs, and extends the connector's service life in harsh environments.
