YM24 35A 2Pin Female Socket IP67 Waterproof Power Connector Flange Mount Plastic Shell Solder Terminal

Name: YM24 35A 2Pin Female Socket IP67 Waterproof Power Connector Flange Mount Plastic Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 621.0 INR
Availability: InStock

621.0 INR/Piece

Get a Price/Quote

Product Details:

Interface Solder Terminal
Features Waterproof, Screw Flange Mount, Corrosion Resistant
Operating Temperature -40C to +85C
Input 2-pin Female Contact
IP Rating IP67
Power Supply Wired
Output Electrical Connection Output
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

YM24 35A 2Pin Female Socket IP67 Waterproof Power Connector Flange Mount Plastic Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 621.0 INR/Piece

Contact Resistance <2.5m
Sealing Waterproof silicone O-ring
Cable Diameter Range 10mm~14mm
Shell Material High-strength Thermoplastic
Contact Material Copper Alloy (Gold-plated)
Connection Mode Solder Terminal
Mounting Type Flange Mount
Locking Mechanism Screw Lock Ring
Flammability Rating UL94-V0
Mating Cycle 500 cycles
Insulation Resistance >1000M (500V DC)
Number of Poles 2

YM24 35A 2Pin Female Socket IP67 Waterproof Power Connector Flange Mount Plastic Shell Solder Terminal Product Specifications

Operating Temperature -40C to +85C
Thickness Shell thickness approx. 3.8mm
Input 2-pin Female Contact
Dimension (L*W*H) Flange 32mm x 32mm, Body Length 65mm
Product Type 2-Pin Female Power Connector Socket
Function Power Connection
Size YM24 Size Standard
IP Rating IP67
Usage Outdoor and Industrial Applications
Capacity 35A Max Current
Current Rating 35A
Frequency 50/60Hz
Power Supply Wired
Weight 80g (approx.)
Interface Solder Terminal
Color Black
Components Plastic Shell, Copper Alloy Contacts
Power Source External Powered
Features Waterproof, Screw Flange Mount, Corrosion Resistant
Supply Voltage Max 500V
Rated Voltage 500V AC/DC
Output Electrical Connection Output
Application LED Lighting, Machinery, Electric Equipment

Contact Resistance <2.5m
Sealing Waterproof silicone O-ring
Cable Diameter Range 10mm~14mm
Shell Material High-strength Thermoplastic
Contact Material Copper Alloy (Gold-plated)
Connection Mode Solder Terminal
Mounting Type Flange Mount
Locking Mechanism Screw Lock Ring
Flammability Rating UL94-V0
Mating Cycle 500 cycles
Insulation Resistance >1000M (500V DC)
Number of Poles 2

YM24 35A 2Pin Female Socket IP67 Waterproof Power Connector Flange Mount Plastic Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Connecting mode:latching lock
Contact diameter:phi 3.0x3
Operating voltage(AC.V.rms):500V
Withstand voltage(AC.V)1min:2500V
Temperature and humidity:-4080C, 40C, 85%RH
Mating cycle:1700 times

Reliable Outdoor Power Connections

Engineered for resilience, the YM24 connector is a trusted choice for any application exposed to water, dust, or demanding environmental factors. Its IP67 rating and corrosion-resistant shell ensure dependable connections for machinery, industrial equipment, and outdoor lighting, regardless of weather or location.

Safe and Easy Installation

With its flange mount design and screw lock ring, setting up the YM24 socket is straightforward and secure. The solder terminals provide solid electrical contact, and the UL94-V0 high-strength plastic shell offers enhanced safety against fire hazards.

Versatile Performance

Supporting up to 35A and 500V AC/DC with insulation resistance above 1000M, the YM24 is built for high-performance usage. Its compatibility with a wide cable diameter range and operating temperature between -40C and +85C ensures adaptable integration in diverse industrial settings.

FAQ's of YM24 35A 2Pin Female Socket IP67 Waterproof Power Connector Flange Mount Plastic Shell Solder Terminal:

Q: How is the YM24 35A 2Pin Female Socket installed in outdoor or industrial equipment?

A: The YM24 connector features a flange mount design with a screw lock ring, allowing secure attachment to panels or enclosures. Cables are soldered onto the terminal contacts to provide a reliable connection in challenging environments.

Q: What makes this power connector suitable for outdoor and industrial applications?

A: Its IP67 waterproof rating, corrosion-resistant high-strength thermoplastic shell, and waterproof silicone O-ring ensure the connector withstands exposure to moisture, dust, and extreme temperatures, making it ideal for outdoor and industrial setups.

Q: When should I choose the YM24 connector for my project?

A: You should use the YM24 connector when you require a robust, waterproof, and high-current power connection (up to 35A, 500V) for equipment such as LED lighting, industrial machinery, or outdoor electrical systems.

Q: Where can the YM24 2Pin Female Socket be applied?

A: This connector is commonly used in outdoor lighting installations, factory automation, electric equipment panels, and machinery that demand secure and reliable power connections in harsh environments.

Q: What benefits does the gold-plated copper alloy contact material provide?

A: Gold-plated copper alloy contacts offer excellent conductivity and resist oxidation and corrosion, which ensures longer-lasting, stable electrical performance even in challenging conditions.

Q: What process is involved in making the electrical connection with this socket?

A: The connection is established by soldering the electrical wires to the internal terminals, ensuring a secure bond. Once soldered, the connector is fixed to a panel via the flange mount, and then sealed tightly using the screw lock ring.

Q: How does the YM24 socket ensure safety during high current or voltage operation?

A: With a UL94-V0 high-strength thermoplastic shell, over 1000M insulation resistance, and a secure sealing design, the connector minimizes the risk of electrical leakage, short-circuiting, and fire, delivering reliable performance under load.
