YT RJ45 Cat5e IP67 Waterproof Female Socket Ethernet Connector Panel Mount

Name: YT RJ45 Cat5e IP67 Waterproof Female Socket Ethernet Connector Panel Mount
Brand: CONNECTOR DEVICES
Price: 265.0 INR
Availability: InStock

265.0 INR/Piece

Get a Price/Quote

Product Details:

Usage Ethernet/IP data transmission
Components 1 x RJ45 female connector, waterproof sealing ring, mounting accessories
Input RJ45 (Cat5e) female
Interface RJ45 Cat5e
Power Supply Not applicable (passive connector)
Output RJ45 (Cat5e) female
Features Waterproof, dustproof, UV resistant, durable, corrosion-resistant, panel mountable, easy installation
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

YT RJ45 Cat5e IP67 Waterproof Female Socket Ethernet Connector Panel Mount Price And Quantity

Minimum Order Quantity 100 Piece
Price 265.0 INR/Piece

Shielding Shielded for EMI/RFI protection
Compliance RoHS compliant
Cable Compatibility Cat5e Ethernet cables
Contact Resistance 30m
Flame Retardant Yes, UL 94V-0
Storage Temperature -40C to +85C
Sealing Method Rubber O-ring gasket
Housing Material High-strength thermoplastic (nylon/ABS blend)
Insulation Resistance 500M at 500V DC
Contact Material Gold plated copper
Environmental Protection UV, water, dust, oil, vibration resistant
Panel Cutout Size Approx. 24mm diameter (check datasheet for details)
Mounting Type Panel mount, screw fixed
Connector Gender Female to Female
Dielectric Withstand Voltage 1000V AC RMS, 1 minute
Connector Life 750 mating cycles

YT RJ45 Cat5e IP67 Waterproof Female Socket Ethernet Connector Panel Mount Product Specifications

Size Standard RJ45 panel mount
Usage Ethernet/IP data transmission
Dimension (L*W*H) 34mm x 26mm x 26mm (approximate)
Capacity Supports up to 1 Gigabit Ethernet
Current Rating 1.5A max
Power Supply Not applicable (passive connector)
Weight Approx. 25g
Frequency Up to 250 MHz
Features Waterproof, dustproof, UV resistant, durable, corrosion-resistant, panel mountable, easy installation
Application Outdoor Ethernet networks, industrial automation, ruggedized devices
Components 1 x RJ45 female connector, waterproof sealing ring, mounting accessories
Input RJ45 (Cat5e) female
Thickness Panel mounting flange: approx. 2mm
IP Rating IP67
Product Type RJ45 Cat5e IP67 waterproof female socket Ethernet connector, panel mount
Rated Voltage 125V AC
Operating Temperature -25C to +80C
Interface RJ45 Cat5e
Color Black
Output RJ45 (Cat5e) female
Function Ethernet network connectivity in harsh/outdoor environments

Shielding Shielded for EMI/RFI protection
Compliance RoHS compliant
Cable Compatibility Cat5e Ethernet cables
Contact Resistance 30m
Flame Retardant Yes, UL 94V-0
Storage Temperature -40C to +85C
Sealing Method Rubber O-ring gasket
Housing Material High-strength thermoplastic (nylon/ABS blend)
Insulation Resistance 500M at 500V DC
Contact Material Gold plated copper
Environmental Protection UV, water, dust, oil, vibration resistant
Panel Cutout Size Approx. 24mm diameter (check datasheet for details)
Mounting Type Panel mount, screw fixed
Connector Gender Female to Female
Dielectric Withstand Voltage 1000V AC RMS, 1 minute
Connector Life 750 mating cycles

YT RJ45 Cat5e IP67 Waterproof Female Socket Ethernet Connector Panel Mount Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Connecting Mode:1/4 bayonet connecting type
Cable Specification:0.15mm2 0.2mm2 /2624AWG
Diameter Range:5.5mm7mm
Operating Voltage(AC.V.rms):42V
Withstand Voltage(AC.V)1min:1000V
Durability:> 500 mating & unmating cycles
Temperature Rating:-4080C

Superior Performance in Rugged Environments

This connector provides reliable Ethernet/IP data transmission even in harsh conditions. Its IP67-rated design, shielded construction, and flame-retardant, UV-resistant materials protect against moisture, dust, oil, and mechanical stress. The gold-plated copper contacts and high insulation values assure stable connectivity over long service life.

Simple and Secure Installation

With a screw-fixed panel mount, standard 24mm cutout, and included waterproof sealing ring, installation is hassle-free and robust. The connector secures tightly to panels up to 2mm thick, ensuring a long-lasting seal. Standard RJ45 female-female ports accommodate Cat5e Ethernet cables for seamless integration.

Versatile Applications

Built for outdoor Ethernet networks, industrial automation systems, and ruggedized devices, this connector suits a variety of sectors. Its -40C to +85C storage temperature range and -25C to +80C operating range make it highly adaptable for both indoor and outdoor deployments.

FAQ's of YT RJ45 Cat5e IP67 Waterproof Female Socket Ethernet Connector Panel Mount:

Q: How does this connector protect against water and dust ingress?

A: The YT RJ45 Cat5e connector uses a rubber O-ring gasket and precision sealing to achieve an IP67 rating, making it waterproof and dustproof for challenging environments.

Q: What installation process is required for mounting this connector?

A: Installation involves preparing a standard 24mm panel cutout, placing the connector with the sealing ring, and securing it with screws to ensure a stable, leak-proof mount.

Q: When is it most beneficial to use this panel mount Ethernet connector?

A: It is ideal for outdoor networks, industrial automation, or any application where Ethernet connectivity must be maintained despite exposure to water, dust, oil, or vibration.

Q: Where can this connector be used effectively?

A: It is suitable for use in outdoor networking, industrial equipment panels, control systems, and ruggedized devices deployed in factories, warehouses, or field installations.

Q: What Cat5e cable compatibility and performance does this connector offer?

A: It supports standard Cat5e Ethernet cables and delivers up to 1 Gigabit Ethernet speeds at frequencies up to 250 MHz, with low contact resistance and high insulation properties.

Q: How does the connector ensure high durability and safety?

A: The connector is constructed from flame-retardant, UV-resistant thermoplastic with gold-plated contacts, has undergone 750 mating cycles, meets UL 94V-0 and RoHS standards, and is shielded for EMI/RFI protection.
