YT-RJ45 Series RJ45 Male Plug Metal Shell IP65 Waterproof Ethernet Connector

Name: YT-RJ45 Series RJ45 Male Plug Metal Shell IP65 Waterproof Ethernet Connector
Brand: CONNECTOR DEVICES
Price: 361.0 INR
Availability: InStock

361.0 INR/Piece

Get a Price/Quote

Product Details:

Output RJ45 Ethernet Interface
Components Metal Shell, Rubber Gasket, RJ45 Plug Interface
Features Waterproof, Dustproof, Corrosion Resistant, Durable Metal Shell, Industrial Grade
Usage Outdoor and industrial network cabling
Input RJ45 Male Plug
Interface RJ45 (8P8C)
Operating Temperature -20C to +80C
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

YT-RJ45 Series RJ45 Male Plug Metal Shell IP65 Waterproof Ethernet Connector Price And Quantity

Minimum Order Quantity 100 Piece
Price 361.0 INR/Piece

Number of Contacts 8 Contacts
Standards Compliance IEEE 802.3 (Ethernet), RoHS Compliant
Connector Gender Male Plug
Shell Material Zinc Alloy with Nickel Plating
Cable Compatibility Cat5e, Cat6, Cat6a Ethernet Cables
Shielding Yes, Fully Shielded for EMI Protection
Termination Type Crimp or Solder Type (Depending on Model)
Sealing Method Rubber Gasket O-Ring
Locking Mechanism Threaded Coupling
Mounting Type Inline/Panel Mount (Depending on version)
Flammability Rating UL94V-0
Mating Cycles 500

YT-RJ45 Series RJ45 Male Plug Metal Shell IP65 Waterproof Ethernet Connector Product Specifications

Operating Temperature -20C to +80C
Size Standard RJ45 plug dimensions with extended waterproof shell
Features Waterproof, Dustproof, Corrosion Resistant, Durable Metal Shell, Industrial Grade
Capacity 1 Ethernet Channel
Frequency Ethernet 10/100/1000 Mbps support
Application Ethernet Networking, Field Installations, IP Cameras, Industrial Automation
Interface RJ45 (8P8C)
Components Metal Shell, Rubber Gasket, RJ45 Plug Interface
Current Rating 2A max
IP Rating IP65
Power Supply Not Applicable (Signal Connector)
Output RJ45 Ethernet Interface
Weight Approx. 30g
Color Metallic Silver
Rated Voltage DC 60V max
Input RJ45 Male Plug
Usage Outdoor and industrial network cabling
Dimension (L*W*H) Approx. 65mm 20mm 20mm
Function Ethernet data transmission and connectivity
Product Type RJ45 Male Ethernet Plug Connector

Number of Contacts 8 Contacts
Standards Compliance IEEE 802.3 (Ethernet), RoHS Compliant
Connector Gender Male Plug
Shell Material Zinc Alloy with Nickel Plating
Cable Compatibility Cat5e, Cat6, Cat6a Ethernet Cables
Shielding Yes, Fully Shielded for EMI Protection
Termination Type Crimp or Solder Type (Depending on Model)
Sealing Method Rubber Gasket O-Ring
Locking Mechanism Threaded Coupling
Mounting Type Inline/Panel Mount (Depending on version)
Flammability Rating UL94V-0
Mating Cycles 500

YT-RJ45 Series RJ45 Male Plug Metal Shell IP65 Waterproof Ethernet Connector Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Diameter range:5.57mm
Insulation resistance:>500Mohm
Durability:>500
Contact diameter x number:8
Operating voltage (AC):500V
Working temperature:-4080C
Modular Interface:RJ45

Exceptional Waterproof and Dustproof Performance

Designed with an IP65 rating, the YT-RJ45 Series connector employs a rubber gasket O-ring for a robust seal. This ensures reliable Ethernet connectivity even in harsh outdoor and industrial environments, making the connector resistant to water, dust, and corrosion.

Sturdy Metal Shell for Enhanced Durability

Constructed from zinc alloy with nickel plating, the connector boasts industrial-grade strength and long-lasting resistance to mechanical stress and chemical exposure. The metallic silver finish also adds to its corrosion-resistant properties.

Universal Compatibility and Easy Installation

Compatible with Cat5e, Cat6, and Cat6a Ethernet cables, the YT-RJ45 connector supports standard 8-contact RJ45 interfaces. It is available in crimp or solder termination options, streamlining both field and panel installations across a range of applications.

FAQ's of YT-RJ45 Series RJ45 Male Plug Metal Shell IP65 Waterproof Ethernet Connector:

Q: How do you install the YT-RJ45 Series RJ45 Male Plug in industrial or outdoor environments?

A: Installation is straightforward. Depending on the model, simply select the appropriate crimp or solder termination. Attach the connector to your compatible Cat5e, Cat6, or Cat6a cable, then secure it using the threaded coupling mechanism and rubber gasket O-ring to achieve a waterproof seal. Inline or panel mounting options are available for flexible placement.

Q: What level of protection does the IP65 rating provide for this Ethernet connector?

A: IP65 ensures the connector is dust-tight and protected against water jets from any direction. Combined with its durable metal shell and sealing gasket, this makes the connector highly suitable for demanding outdoor and industrial settings.

Q: Where can the YT-RJ45 Series be used effectively?

A: Thanks to its rugged, waterproof, and dustproof construction, this connector is ideal for outdoor network cabling, IP camera installations, industrial automation systems, and any application requiring secure Ethernet connectivity in challenging environments.

Q: What benefits does the fully shielded design offer?

A: The full shielding provides excellent electromagnetic interference (EMI) protection. This ensures stable data transmission and reduces signal loss, making the connector reliable for high-speed network applications.

Q: Which Ethernet cables are compatible with this connector?

A: The YT-RJ45 Series is designed to work seamlessly with Cat5e, Cat6, and Cat6a Ethernet cables, supporting a range of 10/100/1000 Mbps Ethernet standards as per IEEE 802.3 compliance.

Q: How durable is the connector in terms of usage and environmental conditions?

A: The connector features a robust metal shell, has a mating cycle rating of up to 500 insertions, a wide operating temperature from -20C to +80C, and complies with industrial-grade flammability (UL94V-0), guaranteeing lasting performance in tough environments.
