YW16 500V 10A 3Pin Metal Female Plug IP67 Waterproof Power Connector Metal Shell Solder Terminal

Name: YW16 500V 10A 3Pin Metal Female Plug IP67 Waterproof Power Connector Metal Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 580.0 INR
Availability: InStock

580.0 INR/Piece

Get a Price/Quote

Product Details:

IP Rating IP67 (dust-tight & waterproof)
Operating Temperature -40C to +85C
Power Source External powered circuit
Power Supply Cable powered connection
Usage Outdoor and industrial applications
Input Panel/cable mount, solder terminal
Output 3 Pin Female power interface
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

YW16 500V 10A 3Pin Metal Female Plug IP67 Waterproof Power Connector Metal Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 580.0 INR/Piece

Cable Diameter Suitability 3.5mm - 7mm
Compliance RoHS Compliant
Dielectric Withstand Voltage 1500V AC/min
Contact Resistance 5m
Mechanical Life >500 Mating cycles
Locking Mechanism Screw locking ring
Connector Gender Female
Mounting Type Panel mount/cable end
Insulation Resistance >2000M (at 500V DC)
Environmental Resistance UV, moisture, vibration
Shell Material Zinc alloy, chrome plated
Contact Material Copper alloy with nickel plating
Pin Diameter 1.5mm per pin (approx.)
Wire Connection Solder termination

YW16 500V 10A 3Pin Metal Female Plug IP67 Waterproof Power Connector Metal Shell Solder Terminal Product Specifications

Product Type Metal Female Plug Power Connector
Dimension (L*W*H) Approx. 61mm x 24mm x 24mm (cylindrical housing)
Power Supply Cable powered connection
Operating Temperature -40C to +85C
Power Source External powered circuit
Capacity Supports up to 10A current
Features Waterproof, dustproof, corrosion resistant, metal shell, secure connection, quick-connect/disconnect
Color Silver (metallic)
Output 3 Pin Female power interface
Components Metal shell, 3-pin solder terminal insert
Application Machinery, LED lighting, equipment, power distribution
Supply Voltage 500V
Size YW16 Series standard size
Usage Outdoor and industrial applications
Input Panel/cable mount, solder terminal
Interface 3-Pin solder terminal
Function Power connection and waterproof protection
Weight Approx. 26g
Rated Voltage 500V AC/DC
Frequency 50/60Hz compatible
Thickness 2.5mm (shell approx.)
IP Rating IP67 (dust-tight & waterproof)
Current Rating 10A

Cable Diameter Suitability 3.5mm - 7mm
Compliance RoHS Compliant
Dielectric Withstand Voltage 1500V AC/min
Contact Resistance 5m
Mechanical Life >500 Mating cycles
Locking Mechanism Screw locking ring
Connector Gender Female
Mounting Type Panel mount/cable end
Insulation Resistance >2000M (at 500V DC)
Environmental Resistance UV, moisture, vibration
Shell Material Zinc alloy, chrome plated
Contact Material Copper alloy with nickel plating
Pin Diameter 1.5mm per pin (approx.)
Wire Connection Solder termination

YW16 500V 10A 3Pin Metal Female Plug IP67 Waterproof Power Connector Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:500V
Number of Pins:3
Withstanding voltage:2500V
Contact dimension:Phi 1.5x3
Insertion and extraction force:1.8N Max
Mating cycle:1700 Times
Temperature and humidity:-40+80C; 40C, 85%RH
Screw torque:42-53 (N.m)

Exceptional Durability and Protection

Crafted with a zinc alloy shell and nickel-plated copper contacts, the YW16 connector is engineered for resilience against harsh environments. It offers outstanding waterproof and dustproof performance, with an IP67 rating ensuring operations remain unaffected by moisture, UV, or vibration. Chrome plating protects against corrosion, making it ideal for both outdoor and industrial settings.

Secure and Versatile Connections

The YW16 features a screw-locking ring for a reliable, tamper-resistant connection that stands up to repeated use, rated for over 500 mating cycles. Solder terminals accommodate 3.5mm to 7mm cable diameters, providing flexibility for various wiring needs. This design supports cable or panel mounting, making installation straightforward across a wide array of systems.

FAQ's of YW16 500V 10A 3Pin Metal Female Plug IP67 Waterproof Power Connector Metal Shell Solder Terminal:

Q: How do I install the YW16 3Pin Female Plug for my application?

A: To install the YW16, first solder your wires to the pin terminals within the connector, ensuring a secure electrical contact. The connector can be panel-mounted or used as a cable end, supporting 3.5mm to 7mm cables. Secure the plug with the screw-locking ring for a watertight fit, providing optimal performance in industrial or outdoor configurations.

Q: What environments is the YW16 connector suitable for?

A: The YW16 connector is rated IP67, making it ideal for environments exposed to dust, water, vibration, and UV. Its rugged metal shell and corrosion-resistant materials make it suitable for outdoor, industrial, and machinery applications, ensuring reliable power connections even in harsh conditions.

Q: When should I choose this connector over plastic or non-waterproof alternatives?

A: Choose the YW16 connector when durability, moisture resistance, UV resistance, and mechanical stability are critical. Its IP67 rating and robust build provide reliable operation in demanding industrial, outdoor, or machinery applications where exposure to dust and water can occur.

Q: Where can the YW16 plug be utilized?

A: The YW16 is well-suited for use in power distribution, LED lighting systems, industrial machinery, equipment panels, and anywhere a secure, waterproof connection is necessary. Its versatility makes it a reliable choice for both new installations and retrofitting existing systems.

Q: What is the process for connecting wires to the YW16 connector?

A: Wires are connected to the YW16 by soldering them directly to the copper alloy terminals. After soldering, insert the wires into the connector shell, secure the assembly with the locking ring, and then mount the connector as required for your panel or cable application.

Q: What are the benefits of using a metal shell and screw-locking ring in this connector?

A: The metal shell adds significant mechanical strength and corrosion resistance, while the screw-locking ring ensures a secure, vibration-proof connection. Together, they provide long-term reliability, even in rugged environments or where regular connection/disconnection is needed.
