BD24 Series 500V 25A 3Pin Female Socket IP67 Metal Shell Waterproof Power Connector Screw Terminal

Name: BD24 Series 500V 25A 3Pin Female Socket IP67 Metal Shell Waterproof Power Connector Screw Terminal
Brand: CONNECTOR DEVICES
Price: 965.0 INR
Availability: InStock

965.0 INR/Piece

Get a Price/Quote

Product Details:

Usage Outdoor/Indoor heavy-duty electrical connection
Input 3-Pin (Female Socket)
Operating Temperature -40C to +80C
Components Connector housing, 3 screw-terminals, sealing ring, locking nut
Features Waterproof, dustproof, corrosion resistant, robust metal shell, easy installation
Output Stable electrical contact
IP Rating IP67
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

BD24 Series 500V 25A 3Pin Female Socket IP67 Metal Shell Waterproof Power Connector Screw Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 965.0 INR/Piece

Mounting Type Cable mount (inline/female)
Locking Mechanism Threaded coupling (secure screw locking)
Shell Material Zinc alloy with nickel plating
Standards/Certifications CE, RoHS compliant
Insulation Material High-grade engineering plastic
Connection Type Screw terminal
Flammability Rating UL94-V0
Electrical Life 1000 mating cycles
Contact Material Copper alloy with silver plating
Cable Diameter Range 8mm - 12mm
Environmental Protection Suitable for outdoor, wet, or harsh environments
Resistance Contact resistance 5 m; Insulation resistance 2000 M at 500VDC
Sealing Method Rubber gasket & O-ring seal

BD24 Series 500V 25A 3Pin Female Socket IP67 Metal Shell Waterproof Power Connector Screw Terminal Product Specifications

Dimension (L*W*H) Approx. 90mm x 36mm x 36mm
Size BD24 Series
Input 3-Pin (Female Socket)
Weight Approx. 290g
Usage Outdoor/Indoor heavy-duty electrical connection
Supply Voltage 500V Max.
Rated Voltage 500V
Color Metallic Silver
IP Rating IP67
Frequency 50-60Hz compatible
Output Stable electrical contact
Thickness Shell wall thickness approx. 2.0 mm
Application Industrial power distribution, automation equipment, machinery
Operating Temperature -40C to +80C
Capacity 25A (current)
Components Connector housing, 3 screw-terminals, sealing ring, locking nut
Features Waterproof, dustproof, corrosion resistant, robust metal shell, easy installation
Current Rating 25A
Interface Screw terminal (3-pin)
Product Type Waterproof Power Connector Socket
Power Supply AC or DC Compatible
Function Power transmission connector for industrial electrical systems
Power Source External cable connection

Mounting Type Cable mount (inline/female)
Locking Mechanism Threaded coupling (secure screw locking)
Shell Material Zinc alloy with nickel plating
Standards/Certifications CE, RoHS compliant
Insulation Material High-grade engineering plastic
Connection Type Screw terminal
Flammability Rating UL94-V0
Electrical Life 1000 mating cycles
Contact Material Copper alloy with silver plating
Cable Diameter Range 8mm - 12mm
Environmental Protection Suitable for outdoor, wet, or harsh environments
Resistance Contact resistance 5 m; Insulation resistance 2000 M at 500VDC
Sealing Method Rubber gasket & O-ring seal

BD24 Series 500V 25A 3Pin Female Socket IP67 Metal Shell Waterproof Power Connector Screw Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:500V
Withstanding voltage:2500V
Contact dimension:Phi 3x3
Mating cycle:1700 times
Insertion and extraction force:5.4N Max
Temperature and humidity:-40+80C; 40C, 85%RH

Reliable Power Connection for Industrial Applications

The BD24 Series 3Pin Female Socket ensures robust and stable power delivery across demanding industrial environments. Its durable metal construction, waterproof IP67 rating, and advanced sealing system make it ideal for both indoor and outdoor installations. With a high current capacity of 25A and 500V rating, it supports a wide range of heavy-duty applications.

Engineered for Longevity and Safety

Manufactured using premium materials such as a zinc alloy shell with nickel plating and high-grade plastics, the BD24 connector guarantees longevity even in corrosive or wet conditions. Its UL94-V0 flame rating, CE, and RoHS certifications ensure compliance with strict international safety standards, while its mechanical design allows up to 1000 secure mating cycles.

Versatile and Easy to Install

Thanks to a user-friendly screw terminal interface and a wide cable diameter range, the BD24 socket is simple to install for cable mount configurations. The threaded coupling system further secures the connection, making routine maintenance and future upgrades effortless. Its inline design is perfect for distributed power setups in automation and machinery fields.

FAQ's of BD24 Series 500V 25A 3Pin Female Socket IP67 Metal Shell Waterproof Power Connector Screw Terminal:

Q: How do I install the BD24 Series 3Pin Female Socket?

A: Installation involves connecting the stripped cable wires to the screw terminals inside the socket, ensuring a firm and secure fit. The cable is then sealed using the provided sealing ring and the device is locked with the threaded coupling for a watertight and dustproof seal. No special tools beyond a screwdriver are typically required.

Q: What environments is this power connector suitable for?

A: The BD24 Series socket is IP67 rated, making it ideal for outdoor, wet, or harsh industrial environments. Its corrosion-resistant zinc alloy shell and robust sealing method ensure reliable operation even in challenging conditions such as factories, automation equipment installations, and power distribution panels.

Q: When should I use this connector over standard alternatives?

A: This connector should be chosen for applications that demand high durability, waterproofing, and reliable power transmission-especially where environmental protection and safety certifications like CE and RoHS are critical. It is optimal for applications needing a 500V, 25A capacity with stable performance.

Q: What are the benefits of the screw terminal interface?

A: The screw terminal design provides a secure and reliable connection, allowing for easy installation, re-termination, or routine inspection without soldering. This reduces downtime and facilitates rapid maintenance, making it a preferred choice for industrial settings.

Q: How does the waterproofing and dustproofing system work?

A: The connector achieves an IP67 rating through the use of a rubber gasket and O-ring seal, preventing water and dust ingress. The thick metal wall and precise threaded coupling further enhance its environmental resistance, safeguarding the internal contacts from moisture, dust, and debris during operation.

Q: Where can the BD24 Series socket be used in an industrial setup?

A: It is ideal for use in industrial power distribution systems, automation equipment, and machinery that require robust, safe, and quick connect/disconnect solutions. Its cable mount design supports flexible installation across distributed power networks.
