DH20 250V 5A 12Pin Female Socket IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal

Name: DH20 250V 5A 12Pin Female Socket IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 481.0 INR
Availability: InStock

481.0 INR/Piece

Get a Price/Quote

Product Details:

Operating Temperature -25C to +85C
Interface Solder terminal, 12-pin female
Power Supply AC/DC Compatible
Features Waterproof, dustproof, metal shell, corrosion resistant, secure locking mechanism
Input 12-pin solder type input
IP Rating IP67
Power Source External (via cable)
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

DH20 250V 5A 12Pin Female Socket IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 481.0 INR/Piece

Connector Gender Female Socket
Mounting Type Panel mount
Wire Size Supported 20-16 AWG
Flame Retardant Grade UL94 V-0
Sealing Material Silicone gasket
Contact Resistance 5m
Insulation Resistance 1000M at 500V DC
Locking Mechanism Threaded coupling
Material Zinc alloy shell, copper alloy terminal, nickel plated
Number of Pins 12
Withstand Voltage 1500V AC/min

DH20 250V 5A 12Pin Female Socket IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal Product Specifications

Usage Industrial equipment, electrical installations
Output 12-pin female socket output
Power Source External (via cable)
Components Metal casing, 12 solder terminals
Frequency 50/60 Hz
IP Rating IP67
Input 12-pin solder type input
Dimension (L*W*H) Approx. 58mm x 26mm (L x D)
Function Multi-pin electrical power connectivity
Features Waterproof, dustproof, metal shell, corrosion resistant, secure locking mechanism
Power Supply AC/DC Compatible
Application Outdoor, automation, harsh environments
Weight Approx. 62g
Size DH20 shell size (Approx. 20mm diameter housing)
Thickness Metal shell approx. 1.5mm
Capacity 5A max per pin
Color Metallic silver
Product Type Waterproof Power Connector Socket
Interface Solder terminal, 12-pin female
Current Rating 5A max
Supply Voltage AC 250V max
Rated Voltage 250V AC
Operating Temperature -25C to +85C

Connector Gender Female Socket
Mounting Type Panel mount
Wire Size Supported 20-16 AWG
Flame Retardant Grade UL94 V-0
Sealing Material Silicone gasket
Contact Resistance 5m
Insulation Resistance 1000M at 500V DC
Locking Mechanism Threaded coupling
Material Zinc alloy shell, copper alloy terminal, nickel plated
Number of Pins 12
Withstand Voltage 1500V AC/min

DH20 250V 5A 12Pin Female Socket IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:250V
Temperature and humidity:-4080C; 40C, 85%RH
Wire Gauge:0.340.75mm/2220AWG
Withstand voltage(AC.V)1min:2500V
Mating Cycle:1700 Times

Superior Sealing and Durability

Designed for rugged use, the DH20 socket features a metal shell with 1.5mm thickness and silicone gasket sealing, ensuring IP67 water and dust protection. Its corrosion-resistant, nickel-plated finish enhances durability, making it ideal for outdoor and harsh environments.

Reliable Multi-Pin Connectivity

With 12 dedicated solder terminals supporting 5A each, this socket is perfect for complex electrical installations that require stable, high-capacity connections. The panel mount form factor provides secure attachment to equipment housings and control panels.

Versatile Industrial Applications

Compatible with both AC and DC power supplies, the DH20 socket suits automation systems, heavy machinery, and outdoor equipment. Its broad operating temperature range and flame-retardant construction further underline its industrial readiness.

FAQ's of DH20 250V 5A 12Pin Female Socket IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal:

Q: How is the DH20 12Pin Female Socket installed?

A: The DH20 socket is designed for panel mounting using its threaded coupling mechanism. Simply fit the socket into a suitably sized panel cutout, secure with the threaded locking ring, and solder your wires (20-16 AWG) to the provided terminals for a firm, sealed connection.

Q: What environments are suitable for using this waterproof connector?

A: This connector is IP67 rated, making it ideal for outdoor, automation, and harsh industrial environments where resistance to water, dust, and corrosive elements is essential.

Q: When should I use a 12-pin power connector like the DH20?

A: Use the DH20 when your equipment requires multiple channels of power or signal in a compact, secure connector-especially in industrial or outdoor installations demanding high durability and safety standards.

Q: Where can the DH20 250V 5A socket be used?

A: It is suitable for use in industrial equipment, electrical control panels, outdoor automation systems, and other demanding environments in manufacturing plants, distribution hubs, or remote installations.

Q: What is the benefit of the threaded coupling and silicone gasket?

A: The threaded coupling provides a secure, vibration-resistant connection, while the silicone gasket ensures a waterproof and dustproof seal, maintaining the connector's integrity even in harsh conditions.

Q: How does the DH20 connector ensure electrical safety?

A: With a withstand voltage of 1500V AC/min, insulation resistance over 1000M at 500V DC, and UL94 V-0 flame-retardant grade, the DH20 minimizes risks associated with overload, short-circuit, or fire.

Q: What is the maximum current and voltage supported by this socket?

A: Each pin supports up to 5A of current, with a maximum overall voltage capability of 250V AC, suitable for both AC and DC power applications.
