LP12 125V 5A 2Pin Female Plug IP67 Waterproof Power Connector Plastic Shell

261.0 INR/Piece

Get a Price/Quote

Product Details:

IP Rating IP67
Usage Electrical equipment, outdoor installations
Power Source External power supply
Input 2-pin female connector
Power Supply Wired
Features Waterproof, dustproof, corrosion-resistant, easy installation
Output To compatible male connector/cable
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP12 125V 5A 2Pin Female Plug IP67 Waterproof Power Connector Plastic Shell Price And Quantity

Minimum Order Quantity 100 Piece
Price 261.0 INR/Piece

Cable Diameter Range 4mm - 6.5mm
Insulation Resistance >1000M at 500V DC
Contact Material Copper alloy, gold plated
Flame Retardant Grade UL94-V0
Locking Mechanism Threaded coupling
Waterproof Level IP67 (temporary immersion up to 1 meter)
Compliance/Standard CE, RoHS compliant
Contact Resistance 5m
Number of Pins 2
Mating Cycle Durability >500 cycles
Mounting Type Inline cable mount
Dielectric Withstanding Voltage 1500V AC/min
Shell Material Flame-retardant polyamide (plastic)

LP12 125V 5A 2Pin Female Plug IP67 Waterproof Power Connector Plastic Shell Product Specifications

Size LP12 standard
Components Plastic shell, copper alloy contacts, sealing ring
Current Rating 5A
Operating Temperature -25C to +85C
Dimension (L*W*H) Approx. 53mm x 21mm x 21mm
Interface 2 Pin female plug
Power Supply Wired
Features Waterproof, dustproof, corrosion-resistant, easy installation
Output To compatible male connector/cable
Weight Approx. 20g
Input 2-pin female connector
Power Source External power supply
Capacity 5A
Usage Electrical equipment, outdoor installations
Thickness Plastic shell approx. 3mm
Application LED lighting, power distribution, instruments, outdoor equipment
IP Rating IP67
Color Black
Frequency 50-60Hz compatible
Rated Voltage 125V AC/DC
Supply Voltage AC/DC 125V
Function Power cable connection and waterproof electric connection
Product Type Waterproof Power Connector (Female Plug)

Cable Diameter Range 4mm - 6.5mm
Insulation Resistance >1000M at 500V DC
Contact Material Copper alloy, gold plated
Flame Retardant Grade UL94-V0
Locking Mechanism Threaded coupling
Waterproof Level IP67 (temporary immersion up to 1 meter)
Compliance/Standard CE, RoHS compliant
Contact Resistance 5m
Number of Pins 2
Mating Cycle Durability >500 cycles
Mounting Type Inline cable mount
Dielectric Withstanding Voltage 1500V AC/min
Shell Material Flame-retardant polyamide (plastic)

LP12 125V 5A 2Pin Female Plug IP67 Waterproof Power Connector Plastic Shell Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Connecting mode:Plug (Female pin)
Wire specification:UL246424AWG*2C
Rated Current:5A
Contact dimension:Phi 1.0x2
Temperature and humidity:-4080C, 40C, 85%RH
Mating cycle:1700 times
Operating Voltage:125V

Superior Waterproof and Safety Features

Designed with an IP67 rating, this connector can withstand temporary immersion in water up to 1 meter, making it perfect for outdoor installations. The shell is crafted from flame-retardant polyamide, compliant with UL94-V0, offering excellent fire resistance and operational safety. Reliable sealing ensures dust and moisture cannot compromise your connections, even in challenging environments.

Easy Installation and Durable Performance

The threaded coupling locking mechanism ensures a secure and stable connection, while the inline cable mount design streamlines the setup process. With a mating cycle durability of over 500 cycles and gold-plated copper alloy contacts, it provides long-term, corrosion-resistant performance. Suitable for various cable diameters, installation and maintenance are simple and efficient.

Versatile Applications Across Industries

This connector is ideal for powering LED lighting, power distribution, instruments, and other outdoor equipment. Its robust construction supports both AC and DC inputs up to 125V and a current rating of 5A, making it suitable for demanding industrial and commercial electrical systems where reliable, waterproof connectivity is essential.

FAQ's of LP12 125V 5A 2Pin Female Plug IP67 Waterproof Power Connector Plastic Shell:

Q: How do I install the LP12 2Pin Female Waterproof Power Connector?

A: To install, strip the cable to fit the 4mm-6.5mm diameter range, connect the conductors to the gold-plated copper alloy contacts, and tighten the threaded coupling for a secure, waterproof seal. The inline mount ensures straightforward integration with existing wiring.

Q: What environments is this power connector suitable for?

A: Thanks to its IP67 waterproof rating and flame-retardant polyamide shell, the LP12 connector is ideal for outdoor installations and harsh environments, including LED lighting systems, outdoor instruments, and power distribution units exposed to moisture and dust.

Q: When should I use a connector with an IP67 rating?

A: Use an IP67-rated connector when protection against dust and temporary water immersion is critical, such as in outdoor, industrial, or wet environments. It is tested to safeguard connections even when submerged up to 1 meter.

Q: Where can I use the LP12 2Pin female connector in electrical setups?

A: This connector is broadly applicable in industries, including LED outdoor lighting, field equipment, power supply installations, and instrumentation that require a robust, waterproof, and dustproof power connection.

Q: What is the benefit of the gold-plated contacts and flame-retardant shell?

A: Gold-plated copper alloy contacts enhance conductivity and resist corrosion, ensuring reliable power transfer. The flame-retardant polyamide shell, rated UL94-V0, increases safety against fire hazards.

Q: How reliable is the LP12 connector during repeated use?

A: With mating cycle durability rated over 500 cycles and a robust locking mechanism, the LP12 connector is engineered for frequent connections and disconnections while maintaining its waterproof and dustproof qualities.
