LP12 3A 7Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal

372.0 INR/Piece

Get a Price/Quote

Product Details:

Output N/A (socket only)
Power Source External power/connection
Interface 7-pin socket, solder termination
IP Rating IP67
Input Solder terminal, 7-pin input
Features Waterproof, dustproof, corrosion resistant, easy installation, robust metal housing
Components Metal shell, 7-pin solder terminal, waterproof rubber gasket
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP12 3A 7Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 372.0 INR/Piece

Contact Resistance 5m
Contact Material Copper alloy with gold plating
Mating Cycle Durability >500 cycles
Connector Gender Female socket
Cable Entry Size PG9
Sealing Method Threaded coupling with rubber gasket
Insulation Resistance >2000M at 500V DC
Mounting Type Flange mount, panel cut-out required
Flame Resistance UL 94V-0 rated plastic insert
Shell Material Zinc alloy with nickel plating

LP12 3A 7Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal Product Specifications

Application Outdoor power equipment, stage lighting, industrial control, LED displays
Input Solder terminal, 7-pin input
Frequency 50/60Hz
Components Metal shell, 7-pin solder terminal, waterproof rubber gasket
Color Metallic silver (shell), black (insert)
Features Waterproof, dustproof, corrosion resistant, easy installation, robust metal housing
Operating Temperature -40C to +80C
Capacity 7 pins, each up to 5A current
Usage Panel mount electrical wiring
Power Supply Power connector
Output N/A (socket only)
Supply Voltage Up to 250V AC
Current Rating 5A max per pin
Dimension (L*W*H) Flange size approx. 23mm x 23mm
Interface 7-pin socket, solder termination
Power Source External power/connection
Function Waterproof power connection for industrial and outdoor applications
Size Shell size LP12 (approx. 12mm diameter)
Weight Approx. 30g
IP Rating IP67
Product Type Female Socket, Circular Connector
Rated Voltage 250V AC

Contact Resistance 5m
Contact Material Copper alloy with gold plating
Mating Cycle Durability >500 cycles
Connector Gender Female socket
Cable Entry Size PG9
Sealing Method Threaded coupling with rubber gasket
Insulation Resistance >2000M at 500V DC
Mounting Type Flange mount, panel cut-out required
Flame Resistance UL 94V-0 rated plastic insert
Shell Material Zinc alloy with nickel plating

LP12 3A 7Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:250V
Contact resistance:< 5.0mohm
Contact dimension:Phi 1.0x2
Insertion and extraction force:0.6N Max.
Mating cycle:1700 times
Temperature and humidity:-4080C, 40C,85%RH.
Screw torque:42-53 (N.m)
Wire specification:UL2464 24AWG*2C
Connecting mode:Easy locking type

Engineered for Harsh Environments

With a durable zinc alloy shell and a threaded coupling sealed by a rubber gasket, the LP12 3A 7Pin Female Socket achieves IP67 waterproof and dustproof protection. It's built to withstand demanding conditions, including outdoor installation, industrial environments, and frequent connection cycles. Whether exposed to rain or dust, this connector ensures uninterrupted performance and long-term reliability, making it a trusted choice for a variety of rugged applications.

Flexible Power and Signal Solutions

Offering up to 7 pins, each rated at 5A and 250V AC, this socket supports various power and signal configurations for your devices. The solder terminals enable secure and easy wiring. It's widely used in outdoor power systems, LED displays, industrial machines, automation controls, and stage lighting-anywhere safe, stable, and weather-resistant connections are crucial.

FAQ's of LP12 3A 7Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal:

Q: How is the LP12 3A 7Pin Female Socket installed?

A: The socket uses a flange mount design and requires a panel cut-out with fixings. After securing it to your panel, connect wires to the solder terminals of each pin, then seal the assembly using the threaded coupling and rubber gasket to maintain the IP67 rating.

Q: What applications are best suited for this waterproof connector?

A: This connector is ideal for outdoor power equipment, stage lighting, industrial control systems, and LED displays-essentially any application demanding secure, weather-resistant electrical connections in harsh or exposed environments.

Q: How does the connector ensure a waterproof and dustproof seal?

A: A threaded coupling mechanism paired with a high-quality rubber gasket safeguards against water ingress and dust. The IP67 rating means it can withstand temporary immersion in water and is completely protected against dust.

Q: What is the benefit of the gold-plated copper alloy contacts?

A: Gold plating on copper alloy contacts ensures low contact resistance (5m) and high conductivity while resisting corrosion and oxidation, thus delivering stable electrical performance over long-term use.

Q: Is the LP12 3A socket compatible with any 7-pin cable or plug?

A: It is designed to mate with compatible LP12 7-pin male plugs that match in size, pin configuration, and mounting specifications. Ensure proper alignment and secure coupling for full waterproof protection.

Q: What is the maximum voltage and current the socket can handle?

A: Each pin supports up to 5A of current and the connector is rated for use with power supplies up to 250V AC, making it suitable for most standard industrial power distribution requirements.

Q: When should I consider using this connector over standard connectors?

A: If your application requires exposed installations or frequent disconnections in challenging environments-such as moisture, dust, or temperature variations-this connector offers enhanced durability, safety, and longevity compared to typical indoor-rated connectors.
