LP12 3A 8Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal

359.0 INR/Piece

Get a Price/Quote

Product Details:

Components 1 x Female Socket Connector (Panel Mount), Lock Nut, Waterproof Gasket
Power Source External Power Supply
Features Waterproof, Dustproof, Panel Mountable, Metal Body, Easy Installation, Anti-vibration
IP Rating IP67
Interface 8 Pin Female, Solder Terminal
Operating Temperature -20C to +85C
Power Supply Through external connector (not supplied)
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP12 3A 8Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal Price And Quantity

Price 359.0 INR/Piece
Minimum Order Quantity 100 Piece

Insulation Resistance 2000M at 500V DC
Sealing Method Silicone O-ring and Locking Nut
Locking System Threaded Coupling
Contact Resistance 5m
Pin Material Copper Alloy, Tin Plated
Withstand Voltage 1500V AC/min
Environmental Protection Waterproof, Dustproof, Corrosion Resistant
Mating Cycle Durability Over 500 mating cycles
Flammability Rating UL94 V-0
Connection Type Panel Mount, Solder Terminal
Mounting Hole Diameter 12mm
Shell Material Zinc Alloy with Nickel Plating

LP12 3A 8Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal Product Specifications

Capacity Up to 8A/Pin
Product Type Panel Mount Waterproof Power Connector
Size 12mm Series (Panel Cut-out Diameter)
Weight Approx. 20g
Usage Panel Mount Connector for Industrial Equipment
Supply Voltage 250V Max
Input Solder Terminal Input
Output 8Pin Female Socket Output
Color Silver Gray (Metallic)
Rated Voltage 250V AC/DC
Dimension (L*W*H) Approx. 45mm length, 19mm diameter (at widest point)
Features Waterproof, Dustproof, Panel Mountable, Metal Body, Easy Installation, Anti-vibration
Function Power Connection and Waterproof Signal Transmission
Components 1 x Female Socket Connector (Panel Mount), Lock Nut, Waterproof Gasket
Power Source External Power Supply
Operating Temperature -20C to +85C
Power Supply Through external connector (not supplied)
Interface 8 Pin Female, Solder Terminal
IP Rating IP67
Current Rating 5A per pin
Frequency 50/60Hz Supported
Application Industrial Automation, Outdoor Equipment, Power Distribution, Signal Control

Insulation Resistance 2000M at 500V DC
Sealing Method Silicone O-ring and Locking Nut
Locking System Threaded Coupling
Contact Resistance 5m
Pin Material Copper Alloy, Tin Plated
Withstand Voltage 1500V AC/min
Environmental Protection Waterproof, Dustproof, Corrosion Resistant
Mating Cycle Durability Over 500 mating cycles
Flammability Rating UL94 V-0
Connection Type Panel Mount, Solder Terminal
Mounting Hole Diameter 12mm
Shell Material Zinc Alloy with Nickel Plating

LP12 3A 8Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand: CNLINKO
Connecting mode: Easy locking type
Insertion and extraction force:0.6N Max
Wire specification:UL2464 24AWG*2C
Rated Current:3A
Contact dimension: Phi 1.0x6
Temperature and humidity:-4080C, 40C, 85%RH
Mating cycle: 1700 times

Superior IP67 Waterproof Protection

Built for harsh environments, the LP12 3A connector's silicone O-ring and threaded locking nut create a watertight seal, ensuring reliable operation in outdoor and industrial settings. The metal shell further shields against dust, corrosion, and vibration, making it ideal for equipment exposed to the elements.

Exceptional Performance and Durability

Engineered for high-reliability power and signal connectivity, this connector supports up to 8A per pin and boasts a low contact resistance of just 5m. Its robust construction offers insulation resistance of 2000M at 500V DC and withstands voltages up to 1500V AC, ensuring maximum safety and long-term use.

Easy Panel Mount Installation

Designed for straightforward panel mounting, the LP12 3A requires a 12mm cut-out and includes a lock nut and waterproof gasket. Its solder terminal contacts allow quick wiring, supporting fast installation and versatile integration into industrial automation systems and power distribution panels.

FAQ's of LP12 3A 8Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal:

Q: How do I install the LP12 3A 8Pin Female Socket into my equipment?

A: To install, create a 12mm hole in your panel, insert the socket from the front, secure it using the included lock nut and waterproof gasket from the rear, then solder your wires to the terminals. The threaded coupling ensures a secure, watertight fit.

Q: What environments and applications is this connector suitable for?

A: This socket is engineered for industrial automation, outdoor equipment, power distribution, and signal control systems where dust, water, or vibration may be present. Its IP67 rating, corrosion resistance, and robust metal shell make it perfect for harsh environmental conditions.

Q: What is the rated voltage and current capacity per pin for this connector?

A: Each of the 8 pins can handle up to 5A, with a maximum voltage rating of 250V AC or DC, supporting reliable power and signal transmission for a wide range of industrial needs.

Q: How does the waterproof sealing work, and what level of protection does it offer?

A: The connector uses a silicone O-ring in conjunction with a threaded lock nut to create a watertight seal. This ensures IP67 protection, making the device resistant to dust and immersion in water up to 1 meter deep for 30 minutes.

Q: What are the benefits of using a metal shell and threaded coupling system?

A: The zinc alloy, nickel-plated metal shell offers excellent durability, shielding, and corrosion resistance. The threaded coupling provides strong anti-vibration properties and helps maintain the waterproof integrity of the installation.

Q: Can the LP12 3A connector be used repeatedly, and what is its mating cycle durability?

A: Yes, this connector is made for repeated use with a mating cycle rating of over 500 cycles, ensuring long-term reliability even in frequently accessed connections.
