LP20 20A 4Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal

Name: LP20 20A 4Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 521.0 INR
Availability: InStock

521.0 INR/Piece

Get a Price/Quote

Product Details:

Power Source Wired Power
Input Panel Mount Solder Terminal (Female Socket)
IP Rating IP67
Output 4 Pin Connection
Components Connector body, mounting nut, waterproof gasket
Power Supply Wired, Solder Terminal
Features Waterproof, Dustproof, Rugged Metal Shell, Solder Terminals, Secure Locking System
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP20 20A 4Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 521.0 INR/Piece

Shell Material Zinc Alloy with Chrome Plating
Panel Cutout Diameter 20mm
Environmental Sealing Waterproof Gasket Included
Number of Pins 4 Pin Female Socket
Mating Style Threaded Coupling
Contact Material Copper Alloy with Silver/Gold Plating
Mounting Type Panel Mount with Nut
Flammability Rating UL94-V0

LP20 20A 4Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal Product Specifications

Product Type Panel Mount Power Connector
Output 4 Pin Connection
Function Power and signal connection
Components Connector body, mounting nut, waterproof gasket
Weight Approx 60g
Capacity 20A per pin
Current Rating 20A
Color Black and Silver
Rated Voltage 500V AC
Power Source Wired Power
Dimension (L*W*H) Approx. 28mm x 57mm (Length including mounting)
Input Panel Mount Solder Terminal (Female Socket)
Power Supply Wired, Solder Terminal
Features Waterproof, Dustproof, Rugged Metal Shell, Solder Terminals, Secure Locking System
Operating Temperature -40C to +80C
IP Rating IP67
Supply Voltage Up to 500V
Usage Industrial, Outdoor Equipment, Waterproof Connection
Application Power Distribution, LED Lighting, Industrial Automation, Outdoor Installations
Interface Solder Terminal, Panel Mount
Size LP20 Series

Shell Material Zinc Alloy with Chrome Plating
Panel Cutout Diameter 20mm
Environmental Sealing Waterproof Gasket Included
Number of Pins 4 Pin Female Socket
Mating Style Threaded Coupling
Contact Material Copper Alloy with Silver/Gold Plating
Mounting Type Panel Mount with Nut
Flammability Rating UL94-V0

LP20 20A 4Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:500V
Withstanding voltage:2500V
Mating cycle:1700 Times
Temperature and humidity:-40+80C; 40C, 85%RH
Contact dimension:Phi 2.7x3
Screw torque:42-53 (N.m)

Rugged and Waterproof Construction

Built with a zinc alloy shell and IP67 environmental sealing, the LP20 socket withstands tough conditions like dust, rain, and temperature extremes. The included waterproof gasket further protects sensitive connections, making it ideal for outdoor and industrial applications where reliability is essential.

Versatile Power and Signal Connectivity

Offering a 20A per pin current rating and support for up to 500V AC, the connector is suitable for both power supply and signal transmission tasks. Its secure 4-pin configuration ensures stable and efficient connections in LED lighting, automation, and power distribution systems.

Simple and Secure Panel Mount Installation

The connector's threaded coupling mechanism, 20mm cutout, and solder terminal design streamline installation on equipment panels. The mounting nut and gasket provide a steadfast fit, making assembly easy while ensuring long-term performance and safety for users and systems.

FAQ's of LP20 20A 4Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal:

Q: How do I install the LP20 4Pin Female Socket into my equipment panel?

A: To install the LP20 socket, cut a 20mm diameter hole in your panel, insert the connector body, and secure it from the back using the mounting nut. The solder terminals allow direct wire attachment. Ensure the included gasket is in place for optimal waterproofing.

Q: What environments is the LP20 socket suitable for?

A: This connector is rated IP67 for waterproof and dustproof protection, making it suitable for industrial facilities, outdoor electrical enclosures, LED lighting, and automation equipment that require reliable connectivity in harsh or exposed settings.

Q: What are the advantages of the LP20's contact and shell materials?

A: The copper alloy contacts plated in silver or gold ensure excellent electrical conductivity and reduced resistance, while the zinc alloy shell with chrome plating provides robust mechanical strength and corrosion resistance, all contributing to longevity and reliability.

Q: When should I choose an IP67 waterproof connector like the LP20?

A: Select the LP20 for applications where protection against water ingress and dust is critical-such as outdoor power distribution, industrial machinery, or environments with frequent exposure to moisture, vibration, or contaminants.

Q: Where can this connector be used within an electrical system?

A: The LP20 socket is versatile and can be used at power input locations, signal connection points, or anywhere a secure, panel-mount waterproof interface is required, especially in outdoor and industrial setups.

Q: What is the connection process for securing wires to the socket?

A: Wires are attached by soldering them to the socket's internal solder terminals. This process assures a strong, stable connection with minimal contact loss, crucial for efficient power or signal transmission.

Q: What benefits does the LP20 connector offer for power and signal applications?

A: It provides high current capacity (20A per pin), excellent environmental sealing, dependable electrical contact, and robust construction, ensuring safe and reliable performance in demanding applications such as industrial automation, power distribution, and outdoor installations.
