LP20 400V 5A 9Pin Female Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal

Name: LP20 400V 5A 9Pin Female Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 447.0 INR
Availability: InStock

447.0 INR/Piece

Get a Price/Quote

Product Details:

Features Waterproof, Dustproof, Secure locking, Corrosion resistant, Vibration resistant
Power Supply AC
Operating Temperature -25C to +85C
Power Source Wired Electrical
Usage Cable-to-panel waterproof power connections
Output Panel Mount Connection
Components 9 Female Solder Terminals, Metal Shell, Rubber Sealing Ring
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP20 400V 5A 9Pin Female Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal Price And Quantity

Price 447.0 INR/Piece
Minimum Order Quantity 100 Piece

Protection Level Complete protection against dust and temporary immersion up to 1m
Shell Material Zinc Alloy, Nickel-plated
Wire Connection Solder Type
Flame Retardancy UL94 V-0 rated insulator
Mounting Style Panel Mount, Circular Flange
Mechanical Life >500 Mating cycles
Contact Material Brass with Gold plating
Contact Resistance 5m
Insulation Resistance >2000M at 500V DC
Connector Gender Female (Socket)
Sealing Method Silicone O-ring

LP20 400V 5A 9Pin Female Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal Product Specifications

Features Waterproof, Dustproof, Secure locking, Corrosion resistant, Vibration resistant
Power Supply AC
Color Black/Silver
Operating Temperature -25C to +85C
Rated Voltage 400V AC
Dimension (L*W*H) 26mm panel hole, Length 55mm
Power Source Wired Electrical
Usage Cable-to-panel waterproof power connections
Weight Approx. 55g
Capacity 5A per contact
Output Panel Mount Connection
Frequency 50-60Hz (typical mains)
Product Type Waterproof Power Connector
Size LP20 Series Compact
Function Power Connector
Components 9 Female Solder Terminals, Metal Shell, Rubber Sealing Ring
Interface Solder Terminal
Application Industrial equipment, LED drivers, Electric vehicles, Outdoor electronics
Supply Voltage 400V Maximum
Input 9 Pin Female Socket
Current Rating 5A
IP Rating IP67
Thickness Metal Shell - approx. 1.5mm

Protection Level Complete protection against dust and temporary immersion up to 1m
Shell Material Zinc Alloy, Nickel-plated
Wire Connection Solder Type
Flame Retardancy UL94 V-0 rated insulator
Mounting Style Panel Mount, Circular Flange
Mechanical Life >500 Mating cycles
Contact Material Brass with Gold plating
Contact Resistance 5m
Insulation Resistance >2000M at 500V DC
Connector Gender Female (Socket)
Sealing Method Silicone O-ring

LP20 400V 5A 9Pin Female Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Connecting Mode:Quickly bayonet connect
Cable Specification:0.34mm2 0.75mm2 /22-20AWG
Diameter Range:7mm10mm
Operating Voltage:400V
Durability:>500 mating & unmating cycles
Temperature Rating:-40C80C

Reliable Waterproof Performance

The LP20 connector is designed for environments where protection from moisture and dust is critical. With its IP67 rating and silicone O-ring seal, it ensures connectors remain operational even when temporarily submerged in water up to 1 meter. This makes it a dependable choice for outdoor installations and challenging industrial applications where environmental sealing is essential.

Panel Mount for Secure and Convenient Usage

Featuring a circular flange and panel mount style, this socket simplifies installation onto equipment panels. The solder type wire connection and robust locking mechanism mean quick assembly and a stable electrical connection, minimizing maintenance while maximizing safety and operational uptime across a broad range of electronic systems.

FAQ's of LP20 400V 5A 9Pin Female Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal:

Q: How do I mount and connect the LP20 9Pin Female Socket to my equipment?

A: The LP20 socket features a panel mount with a circular flange for secure attachment to equipment panels. To connect, solder your wires to the 9 female terminals, insert the connector into a 26mm panel hole, and secure it with the included locking mechanism. Ensure the silicone O-ring is in place to maintain its IP67 waterproof rating.

Q: What makes the LP20 power connector suitable for outdoor or industrial use?

A: This connector offers complete protection against dust and temporary immersion in water up to 1m, thanks to its IP67 rating and silicone sealing ring. Its metal shell resists corrosion and mechanical stress, flame-retardant insulation (UL94 V-0), and strong vibration resistance make it ideal for demanding environments like outdoor electronics and industrial machinery.

Q: When should I use a connector with a 400V, 5A rating and 9 pins?

A: Use this connector when your application requires transmission of appreciable power (up to 400V, 5A per contact) and multiple signal or power lines (9 pins). It is commonly employed in equipment such as LED drivers, motor control units, electric vehicles, and other devices needing rugged, waterproof multi-circuit power connections.

Q: What is the benefit of the solder terminal and panel mount design?

A: The solder terminal ensures a strong, low-resistance electrical connection, reducing the risk of loose connections and power loss. Panel mounting provides a secure and neat integration into device enclosures, enhancing reliability and simplifying future maintenance or replacement.

Q: Where can the LP20 connector be applied effectively?

A: It is well-suited for industrial equipment, LED lighting drivers, electric vehicles, and outdoor electronic equipment in need of robust, waterproof, and dustproof power connections. Its versatility extends to any application requiring secure, multi-pin AC power interconnections in harsh conditions.

Q: How does the LP20 ensure long mechanical and operational life?

A: Constructed with a nickel-plated zinc alloy shell and gold-plated brass contacts, the LP20 maintains low contact resistance and high insulation over 500 mating cycles. This durability ensures sustained performance, even in environments subject to frequent connection and disconnection.
