LP20 400V 5A 9Pin Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal

475.0 INR/Piece

Get a Price/Quote

Product Details:

Input 9 Pin Male Plug
Features Waterproof, Dustproof, Corrosion Resistant, Robust Locking System, Durable Construction
IP Rating IP67
Operating Temperature -25C to +85C
Output Solder Terminal Connection
Power Source Wired Power Supply
Components Plastic+Metal Shell, Gold-plated Contacts
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP20 400V 5A 9Pin Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 475.0 INR/Piece

Shell Finish Nickel-Plated Metal Parts
Cable Diameter Range 6-12mm
Sealing Method Threaded Coupling with Rubber Seal
Contact Material Brass with Gold-plated Contacts
Vibration Resistance Meets IEC 60512-6-4/6-5
Insulation Resistance >1000M at 500V DC
Standards Compliance IEC, CE Certified
Humidity Tolerance 95% RH
Material Plastic+Metal Shell
Mounting Type Cable Mount
Mechanical Life >500 Mating Cycles
Connector Type Male Plug
Flammability Rating UL94 V-0
Contact Resistance 5m
Number of Pins 9 Pins

LP20 400V 5A 9Pin Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal Product Specifications

Function Power Connector
Color Black+Silver
Interface Solder Terminal
Power Supply Electrical
Usage Industrial and Outdoor Power Applications
Weight Approx. 60g
Product Type Power Connector
Components Plastic+Metal Shell, Gold-plated Contacts
Capacity 5A per pin
Dimension (L*W*H) Approx. 70mm x 28mm x 28mm
Size LP20 Series
Power Source Wired Power Supply
Application Power Distribution, Automation Equipment, Machinery
Operating Temperature -25C to +85C
Output Solder Terminal Connection
IP Rating IP67
Supply Voltage 400V AC/DC
Features Waterproof, Dustproof, Corrosion Resistant, Robust Locking System, Durable Construction
Current Rating 5A
Input 9 Pin Male Plug
Frequency 50/60Hz
Thickness Shell Thickness Approx. 2mm
Rated Voltage 400V

Shell Finish Nickel-Plated Metal Parts
Cable Diameter Range 6-12mm
Sealing Method Threaded Coupling with Rubber Seal
Contact Material Brass with Gold-plated Contacts
Vibration Resistance Meets IEC 60512-6-4/6-5
Insulation Resistance >1000M at 500V DC
Standards Compliance IEC, CE Certified
Humidity Tolerance 95% RH
Material Plastic+Metal Shell
Mounting Type Cable Mount
Mechanical Life >500 Mating Cycles
Connector Type Male Plug
Flammability Rating UL94 V-0
Contact Resistance 5m
Number of Pins 9 Pins

LP20 400V 5A 9Pin Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Connecting Mode:Quickly bayonet connect
Cable Specification:0.34mm2 0.75mm2 /22-20AWG
Diameter Range:7mm 10mm
Operating Voltage:400V
Withstand Voltage(AC.V)1min:1500V
Durability:> 500 mating & unmating cycles
Temperature Rating:-40C80C

Reliable Waterproof Performance

The LP20 9Pin Male Plug offers exceptional protection with an IP67 waterproof and dustproof rating. Its threaded coupling and rubber seal ensure safety and performance even in harsh environments, making it perfect for outdoor and industrial uses where moisture and debris are concerns.

Superior Build Quality and Durability

Constructed from a combination of high-grade plastic and nickel-plated metal, this connector features gold-plated brass contacts for excellent conductivity and corrosion resistance. With over 500 mating cycles, it delivers lasting reliability for rigorous applications.

Easy and Secure Cable Mounting

Supporting cable diameters of 6-12mm and utilizing a cable mount design, installation is both simple and secure. The plug's robust locking system and solder terminal interface guarantee a stable, vibration-resistant connection for automation and power distribution needs.

FAQ's of LP20 400V 5A 9Pin Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal:

Q: How do I install the LP20 400V 9Pin Male Plug for power connections?

A: To install the LP20 male plug, strip your cable to fit the 6-12mm diameter range, then solder the wires to the terminal pads as per the pin configuration. Secure the plug by threading the coupling with the included rubber seal to ensure an IP67-rated waterproof and dustproof connection.

Q: What are the benefits of using this connector in outdoor or industrial applications?

A: This connector is IP67 waterproof and dustproof, equipped with gold-plated contacts for reliable conductivity, and constructed from durable plastic and nickel-plated metal, making it resistant to corrosion and harsh environments-ideal for outdoor and industrial use.

Q: When should I use a 9-pin male plug like the LP20 series?

A: Choose the LP20 9-pin male plug when you need to transmit power (up to 400V and 5A per pin) across multiple circuits in power distribution, automation equipment, or machinery requiring reliable and robust connections in potentially adverse conditions.

Q: Where can the LP20 9Pin Male Plug be deployed?

A: This connector is suitable for use in power distribution panels, automation systems, heavy machinery, and outdoor electrical applications, particularly in industries such as manufacturing, energy, and process automation.

Q: What process ensures the LP20 connector remains sealed and protected?

A: Threaded coupling and a reinforced rubber seal provide a secure, watertight fit that protects internal connections from water and dust, maintaining IP67 integrity and ensuring long-term performance.

Q: What makes this connector compliant with international standards?

A: The LP20 connector meets IEC and CE certification requirements, features a UL94 V-0 flammability rating, and exceeds 500 mating cycles, guaranteeing safety and durability for global applications.

Q: How does the gold-plated contact material benefit the connector's performance?

A: Gold-plated contacts provide superior electrical conductivity and resistance to corrosion, reducing contact resistance (5m) and ensuring reliable, consistent power transmission over extended use.
