LP28 500V 35A 3Pin Female Socket IP67 Waterproof Power Connector Metal Shell Screw Terminal

Name: LP28 500V 35A 3Pin Female Socket IP67 Waterproof Power Connector Metal Shell Screw Terminal
Brand: CONNECTOR DEVICES
Price: 1076.0 INR
Availability: InStock

1076.0 INR/Piece

Get a Price/Quote

Product Details:

Output 3 Pin Female Socket
Interface 3 Pin Female, Screw Terminal
IP Rating IP67
Power Source Mains Power
Usage Electrical Equipment, Power Distribution
Power Supply AC/DC Universal
Operating Temperature -40C to +80C
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP28 500V 35A 3Pin Female Socket IP67 Waterproof Power Connector Metal Shell Screw Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 1076.0 INR/Piece

Cable Diameter Range 8mm - 12mm
Mounting Type Panel/Chassis Mount
Flame Retardant Grade UL94 V-0
Connect/Disconnect Cycles 500
Sealing Silicone Gasket
Number of Pins 3
Environmental Protection Waterproof, Dustproof
Contact Resistance 1m
Shell Material Zinc Alloy with Nickel Plating
Withstand Voltage 2500V AC (1 min)
Mechanical Life 1000 cycles
Insulation Resistance >2000M at 500VDC
Contact Material Copper Alloy, Tin Plated

LP28 500V 35A 3Pin Female Socket IP67 Waterproof Power Connector Metal Shell Screw Terminal Product Specifications

Capacity 35 Amps
Application Industrial, Outdoor, Machinery, Power Equipment
Interface 3 Pin Female, Screw Terminal
Color Metallic Grey/Black
IP Rating IP67
Current Rating 35A
Power Source Mains Power
Frequency 50/60 Hz
Output 3 Pin Female Socket
Thickness Standard, Metal Shell - approximately 2 mm
Product Type Waterproof Power Connector
Rated Voltage 500V
Size LP28 Series, Standard Size
Operating Temperature -40C to +80C
Dimension (L*W*H) Approx. 65mm x 38mm x 38mm
Components Connector Body, Pins, Seal Gasket, Screw Terminals
Features Waterproof, Dustproof, Corrosion Resistant, Metal Housing, Easy Installation
Input Screw Terminal Entry
Weight 135 g (approx.)
Function Power Connection
Usage Electrical Equipment, Power Distribution
Supply Voltage 500V
Power Supply AC/DC Universal

Cable Diameter Range 8mm - 12mm
Mounting Type Panel/Chassis Mount
Flame Retardant Grade UL94 V-0
Connect/Disconnect Cycles 500
Sealing Silicone Gasket
Number of Pins 3
Environmental Protection Waterproof, Dustproof
Contact Resistance 1m
Shell Material Zinc Alloy with Nickel Plating
Withstand Voltage 2500V AC (1 min)
Mechanical Life 1000 cycles
Insulation Resistance >2000M at 500VDC
Contact Material Copper Alloy, Tin Plated

LP28 500V 35A 3Pin Female Socket IP67 Waterproof Power Connector Metal Shell Screw Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:500V
Wire Specification:2.5mm5mm/14-12AWG
Line Diameter Range:18mm20mm
Withstand Voltage (AC.V) 1 Minute:2500V
Mating Cycle:> 500 times
Working Temperature:-4080C
Connection Mode:Quick Plug Connection

Durable and Waterproof Design

Built for the harshest conditions, the LP28 connector's metal shell and IP67 sealing ensure resistance to dust, water, and corrosion. The zinc alloy with nickel plating, combined with a silicone gasket, protects electrical connections and extends product life, making it ideal for outdoor and industrial use.

Reliable Power Transmission

This connector supports up to 35A at 500V, making it suitable for high-power equipment. Its copper alloy, tin-plated contacts minimize resistance and energy loss, while its screw terminals ensure a secure and stable connection for reliable power transmission in both AC and DC systems.

Versatile and Easy Installation

Panel or chassis mount design and a wide cable diameter range (8-12mm) enable flexible and straightforward installation. The screw terminal input allows quick wiring, supporting industrial applications such as machinery power supplies, outdoor equipment, and power distribution systems.

FAQ's of LP28 500V 35A 3Pin Female Socket IP67 Waterproof Power Connector Metal Shell Screw Terminal:

Q: How do I install the LP28 3Pin Female Socket in my equipment?

A: First, create the appropriate panel cutout matching the connector's dimensions (65mm x 38mm x 38mm). Position the connector and secure it using the mounting fixtures. Strip your cable, insert the conductors, and tighten them into the screw terminals. Ensure the silicone gasket is properly seated for IP67 sealing before finalizing installation.

Q: What environments is the LP28 connector suitable for?

A: The LP28 connector is designed for industrial, outdoor, and machinery applications, offering dustproof and waterproof protection (IP67). Its corrosion-resistant metal housing and wide operating temperature range (-40C to +80C) make it suitable for harsh and demanding environments.

Q: When should I choose the LP28 over standard connectors?

A: Select the LP28 when you require robust environmental protection, a high current rating (up to 35A), and a flame-retardant housing (UL94 V-0). It is ideal for locations where exposure to dust, water, or vibration could compromise standard connectors.

Q: What is the process for connecting cables to the LP28 socket?

A: Simply strip your cable ends, insert them into the appropriate screw terminal entries, and securely tighten the screws. The screw terminals ensure a stable mechanical and electrical connection, making wiring quick and reliable.

Q: Where can I use the LP28 connector for power distribution?

A: The LP28 is suitable for use in power distribution panels, field equipment, industrial machinery, outdoor power installations, and anywhere reliable, waterproof power connections are essential.

Q: What are the benefits of the LP28's metal shell and silicone gasket?

A: The nickel-plated zinc alloy shell ensures mechanical strength and corrosion resistance, while the silicone gasket delivers effective waterproofing and dust proofing. Together, they guarantee long-lasting, secure connections in adverse conditions.

Q: How long can I expect the LP28 connector to last?

A: The LP28 is rated for up to 1,000 mechanical cycles and 500 connect/disconnect operations, ensuring reliable service life for industrial and outdoor applications.
