LP24 500V 25A 3Pin Female Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal

761.0 INR/Piece

Get a Price/Quote

Product Details:

Operating Temperature -40C to +85C
Interface 3-pin, Solder Type
Power Supply AC/DC Compatible
Features Waterproof, Dustproof, Corrosion Resistance, Easy Installation
Usage Industrial, Outdoor Power Supply
Output Up to 25A
Components Plastic housing, metal shell, solder terminals
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP24 500V 25A 3Pin Female Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal Price And Quantity

Price 761.0 INR/Piece
Minimum Order Quantity 100 Piece

Flame Retardant Level UL94-V0
Cable Entry Diameter 8-12mm
Shell Material Plastic + Metal
Number of Pins 3 (Female)
Insulation Resistance >2000M
Contact Resistance 5m
Locking Mechanism Threaded Coupling
Connection Method Solder Terminal
Mechanical Life >500 Mating Cycles
Dielectric Withstanding Voltage 2500V AC/min
Contact Material Copper alloy with gold or nickel plating

LP24 500V 25A 3Pin Female Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal Product Specifications

Current Rating 25A
Interface 3-pin, Solder Type
Product Type Female Plug Connector
Color Black + Blue
Capacity 25A Max
Size LP24 Standard
Weight Approx. 185g
Operating Temperature -40C to +85C
Rated Voltage 500V
Supply Voltage Up to 500V
Features Waterproof, Dustproof, Corrosion Resistance, Easy Installation
Function Power Connection
Dimension (L*W*H) Approx. 37mm diameter x 100mm length
Frequency 50/60Hz
Input Up to 500V
IP Rating IP67
Components Plastic housing, metal shell, solder terminals
Power Source Electrical
Output Up to 25A
Usage Industrial, Outdoor Power Supply
Application Machinery, Automation Equipment, Power Distribution, Outdoor Installations
Power Supply AC/DC Compatible

Flame Retardant Level UL94-V0
Cable Entry Diameter 8-12mm
Shell Material Plastic + Metal
Number of Pins 3 (Female)
Insulation Resistance >2000M
Contact Resistance 5m
Locking Mechanism Threaded Coupling
Connection Method Solder Terminal
Mechanical Life >500 Mating Cycles
Dielectric Withstanding Voltage 2500V AC/min
Contact Material Copper alloy with gold or nickel plating

LP24 500V 25A 3Pin Female Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:500V
Insertion and extraction force:4.5N Max
Withstanding voltage:2500V
Contact diameter:Phi 3.0x3
Temperature and humidity:-40+80C; 40C, 85%RH
Mating cycle:1700 times
Screw torque:42-53 (Nm)

Outstanding Performance in Harsh Conditions

This power connector boasts an IP67 rating, making it impervious to dust and protected against water immersion. With a flame-retardant shell (UL94-V0), and an operating temperature range from -40C to +85C, it delivers consistent performance for outdoor and industrial settings.

Secure and Reliable Power Connections

Utilizing a threaded coupling mechanism, the LP24 plug assures a tight, vibration-resistant connection. The solder terminal contact system, made from copper alloy with gold or nickel plating, minimizes contact resistance to just 5m, ensuring efficient energy transfer.

Easy Installation and Versatile Usage

The plug is straightforward to install with its 8-12mm cable entry diameter and intuitive solder terminal design. It supports both AC and DC applications up to 500V and 25A, making it suitable for a wide range of uses such as automation equipment, machinery, and outdoor power solutions.

FAQ's of LP24 500V 25A 3Pin Female Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal:

Q: How do I install the LP24 500V 25A 3-Pin Female Plug?

A: Installation requires soldering the power wires to the three pins inside the connector. The cable entry supports diameters of 8-12mm, and the plug is completed with a threaded coupling for a secure fit.

Q: What applications is this connector suitable for?

A: This connector is ideal for industrial machinery, automation equipment, power distribution systems, and outdoor installations thanks to its IP67 waterproof rating and robust construction.

Q: When should I use this connector over other models?

A: Choose the LP24 500V 25A 3-Pin connector when you need a high-capacity (25A max), waterproof (IP67), and flame-retardant (UL94-V0) connection for harsh or outdoor environments.

Q: Where can I use the LP24 connector in terms of power type?

A: It is compatible with both AC and DC power supplies up to 500V, making it versatile for different power solutions in industrial and outdoor applications.

Q: What are the benefits of its threaded coupling mechanism?

A: The threaded coupling offers secure mating, resists vibrations, and prevents accidental disconnection, essential for reliable operation in challenging environments.

Q: What is the mechanical lifespan of this connector?

A: The LP24 plug is rated for more than 500 mating cycles, ensuring dependable long-term usage even in frequent connect/disconnect situations.

Q: How does its build quality enhance safety and durability?

A: Its plastic and metal shell provides solid construction, while the UL94-V0 flame retardant material increases safety. The gold or nickel plated copper alloy contacts also boost corrosion resistance and electrical performance.
