YM20 500V 20A 2Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal

338.0 INR/Piece

Get a Price/Quote

Product Details:

Power Source External Power Supply
Output Solder Terminal
Usage Electrical Equipment, Power Transmission
Operating Temperature -40C to +105C
Input Solder Terminal
Thermal Conductivity Standard
Components Plastic Shell, Solder Terminals, Male Pins
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

YM20 500V 20A 2Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 338.0 INR/Piece

Material High-quality engineering plastic shell
Contact Material Copper alloy with silver plating
Cable Diameter Range 6-12mm
Insulation Resistance >2000M (at 500VDC)
Contact Resistance 2.5m
Locking Mechanism Screw lock
Mounting Type Cable-mount
Environmental Standard RoHS compliant
Number of Contacts 2
Flammability UL94-V0
Connection Method Solder terminal connection
Mechanical Durability >=500 mating cycles
Protection Level IP67 waterproof, dustproof

YM20 500V 20A 2Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal Product Specifications

Features Waterproof, Dustproof, Corrosion-resistant, Quick Connection
Size YM20 Standard Shell Size
Application Outdoor/Indoor Power Distribution, Industrial Automation, LED Lighting
Product Type 2 Pin Male Plug Power Connector
Capacity 20A
Weight Approx. 72g
Interface 2Pin Male Plug
Supply Voltage 500V (Max)
IP Rating IP67
Thermal Conductivity Standard
Dimension (L*W*H) Approx. 90mm x 28mm x 28mm
Components Plastic Shell, Solder Terminals, Male Pins
Power Supply AC/DC
Current Rating 20A
Rated Voltage 500V
Input Solder Terminal
Frequency 50/60Hz
Function Power Connection
Color Black
Usage Electrical Equipment, Power Transmission
Operating Temperature -40C to +105C
Output Solder Terminal
Power Source External Power Supply

Material High-quality engineering plastic shell
Contact Material Copper alloy with silver plating
Cable Diameter Range 6-12mm
Insulation Resistance >2000M (at 500VDC)
Contact Resistance 2.5m
Locking Mechanism Screw lock
Mounting Type Cable-mount
Environmental Standard RoHS compliant
Number of Contacts 2
Flammability UL94-V0
Connection Method Solder terminal connection
Mechanical Durability >=500 mating cycles
Protection Level IP67 waterproof, dustproof

YM20 500V 20A 2Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:500V
Withstanding voltage:2500V
Insertion and extraction force:4.0N Max
Screw torque:42-53 (N.m)
Mating cycle:1700 Times
Temperature and humidity:-4080C; 40C, 85%RH
Contact dimension:Phi 2.7*2

Reliable Power Connection in Demanding Environments

Engineered with a rugged plastic shell and IP67 protection, the YM20 connector withstands harsh conditions including moisture, dust, and temperature extremes. Its screw-lock system and RoHS compliance guarantee lasting, safe, and environmentally responsible use in industrial and commercial settings. Suitable for outdoor power distribution and automation systems.

Enhanced Safety Features and Standards Compliant

With a flammability rating of UL94-V0, insulation resistance above 2000M, and a durable silver-plated copper contact design, the YM20 assures high electrical integrity and user safety. Its strong mechanical build supports over 500 mating cycles, enabling dependable performance for critical applications.

FAQ's of YM20 500V 20A 2Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal:

Q: How do I install the YM20 500V 20A 2Pin Male Plug?

A: The YM20 connector is designed for cable-mount installation and uses solder terminals for both input and output connections. Simply strip the cable insulation, solder the wires to the respective pins, insert the cable, and tighten the screw-lock mechanism to secure the connector in place.

Q: What are the typical applications for this connector?

A: This connector is ideal for power distribution in environments like industrial automation, LED lighting installations, electrical equipment, and both indoor and outdoor settings where a durable, waterproof connection is required.

Q: When should I use this connector instead of standard models?

A: Choose the YM20 when you need high resistance to water, dust, and environmental hazards, especially in outdoor or industrial environments. Its IP67 rating and robust construction make it suitable for challenging conditions where standard connectors may fail.

Q: Where can the YM20 connector be used effectively?

A: The connector can be used in various locations-factory floors, construction sites, outdoor lighting setups, or anywhere reliable power connections must withstand environmental exposure such as rain, dust, or temperature fluctuations.

Q: What is the process for ensuring a waterproof connection?

A: After soldering the cables to the terminals, ensure that the outer shell is fully tightened with the screw-lock mechanism. Make sure the cable diameter fits within the 6-12mm range to maintain the IP67 seal, preventing water intrusion.

Q: What benefits does the YM20 offer for electrical applications?

A: The YM20 offers robust electrical performance with high current (20A) and voltage (500V) ratings, superior insulation, and low contact resistance, enhancing reliability and safety. Its quick connection system saves installation time, while corrosion resistance ensures long service life.
