LP12 125V 5A 2Pin Female Socket IP67 Waterproof Power Connector

161.0 INR/Piece

Get a Price/Quote

Product Details:

Output Connects to Male Plug
Power Supply Wired
Input 2 Pin Female Socket
Usage Outdoor Power Connection
Operating Temperature -40C to +85C
Power Source Electrical
Features Waterproof, Dustproof, Easy Installation, Corrosion Resistant
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP12 125V 5A 2Pin Female Socket IP67 Waterproof Power Connector Price And Quantity

Minimum Order Quantity 100 Piece
Price 161.0 INR/Piece

Seal Type Rubber Gasket and O-ring
Contact Plating Gold Plated
Connection Method Solder/Cable Connection
Insulation Resistance 500M at 500V DC
Wire Gauge Supported 20-16 AWG
Environmental Protection UV Resistant, Moisture Proof
Locking Mechanism Threaded Coupling
Material Nylon PA66 and copper contacts
Mounting Type Panel Mount
Flame Retardant Standard UL94V-0
Contact Resistance 5m
Withstanding Voltage 1500V AC/minute

LP12 125V 5A 2Pin Female Socket IP67 Waterproof Power Connector Product Specifications

Dimension (L*W*H) Approx. 43mm x 18mm x 18mm
Rated Voltage 125V AC/DC
Capacity 5A
Current Rating 5A
Usage Outdoor Power Connection
Frequency 50/60 Hz
Power Source Electrical
Size LP12 Series
Weight Approx. 20g
IP Rating IP67
Operating Temperature -40C to +85C
Color Black
Function Power Connection
Features Waterproof, Dustproof, Easy Installation, Corrosion Resistant
Interface 2-Pin Female
Components Socket Body, Gasket, Terminals
Product Type Waterproof Power Connector
Output Connects to Male Plug
Input 2 Pin Female Socket
Supply Voltage 125V
Thickness Standard Shell Thickness
Power Supply Wired
Application Industrial Equipment, Outdoor Lighting, Electrical Devices

Seal Type Rubber Gasket and O-ring
Contact Plating Gold Plated
Connection Method Solder/Cable Connection
Insulation Resistance 500M at 500V DC
Wire Gauge Supported 20-16 AWG
Environmental Protection UV Resistant, Moisture Proof
Locking Mechanism Threaded Coupling
Material Nylon PA66 and copper contacts
Mounting Type Panel Mount
Flame Retardant Standard UL94V-0
Contact Resistance 5m
Withstanding Voltage 1500V AC/minute

LP12 125V 5A 2Pin Female Socket IP67 Waterproof Power Connector Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Connecting mode:Easy locking type
Insertion and extraction force:0.6N Max
Wire specification:UL246424AWG*2C
Rated Current:5A
Contact dimension:Phi 1.0x2
Temperature and humidity:-4080C, 40C, 85%RH
Mating cycle:1700 times

Reliable Outdoor Power Connection

Engineered for tough environments, the LP12 2Pin Female Socket stands out with its IP67 waterproof rating, robust nylon PA66 construction, and corrosion resistance. With a secure threaded locking mechanism and a rubber gasket plus O-ring seal, it ensures dependable and safe connections in moisture-rich or dusty areas, such as outdoor installations, industrial equipment, and field lighting.

Easy and Secure Installation

The panel mount design, paired with a threaded coupling mechanism, allows straightforward, tool-assisted installation and a firm connection with the matching male plug. The socket supports solder or cable connections, accommodating wire gauges from 20-16 AWG. Comprehensive sealing and gold-plated contacts guarantee long-lasting and secure electrical performance.

FAQ's of LP12 125V 5A 2Pin Female Socket IP67 Waterproof Power Connector:

Q: How do I install the LP12 125V 5A 2Pin Female Socket?

A: The LP12 socket is designed for easy panel mounting. Simply prepare the mounting panel, insert the socket through the opening, and secure it with the included gasket and threaded coupling mechanism. Connect your wires using solder or direct cable connection, ensuring proper insulation and secure attachment.

Q: What makes the LP12 socket suitable for outdoor use?

A: Its IP67 rating means the socket is completely dustproof and protected against immersion in water up to 1 meter, making it ideal for outdoor environments. Additionally, the nylon PA66 body is UV-resistant and moisture-proof, and sealing is provided by a rubber gasket and O-ring, ensuring durability in extreme weather conditions.

Q: When should I use a 2-pin female socket like the LP12?

A: Choose the LP12 2-pin female socket when you need a reliable power connection for outdoor lighting, industrial equipment, or electrical devices requiring robust weather resistance and dependable current delivery up to 5A at 125V AC/DC.

Q: Where can the LP12 power connector be applied?

A: This connector is ideal for use in outdoor lighting installations, industrial control panels, electrical equipment, and other applications in need of a durable, waterproof, and corrosion-resistant connection. Its versatility makes it suitable for use by manufacturers, distributors, and installers across India.

Q: What process should I follow to wire the LP12 socket?

A: After securing the socket in place, strip the ends of your wires (20-16 AWG) and solder or insert them into the designated terminals as per the connection method. Properly tighten the connections and confirm the seal before finalizing installation to maintain waterproof integrity.

Q: What are the main benefits of using the LP12 socket?

A: The LP12 socket offers reliable performance in harsh conditions, thanks to its waterproof and dustproof design, UL94V-0 flame-retardant nylon, gold-plated corrosion-resistant contacts, and ease of installation. These features ensure safety, long product lifespan, and consistent power delivery.

Q: How does the threaded coupling mechanism enhance connector security?

A: The threaded coupling mechanism provides a secure, vibration-resistant connection that maintains electrical integrity and protects against accidental disconnection, especially important in industrial and outdoor environments.
