YM20 20A 2Pin Female Socket IP68 Waterproof Power Connector Panel Mount Plastic Shell Solder Terminal

Name: YM20 20A 2Pin Female Socket IP68 Waterproof Power Connector Panel Mount Plastic Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 368.0 INR
Availability: InStock

368.0 INR/Piece

Get a Price/Quote

Product Details:

Features Waterproof, dustproof, corrosion-resistant, panel mountable, easy installation
Output 2 pin solder terminal
Usage For power connections in industrial and outdoor equipment
Components Female socket, waterproof ring, screw fixtures
Input 2 pin socket
Power Source External power via connector
IP Rating IP68
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

YM20 20A 2Pin Female Socket IP68 Waterproof Power Connector Panel Mount Plastic Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 368.0 INR/Piece

Mating Cycle Durability >500 cycles
Environmental Protection UV resistant, suitable for outdoor use
Insulation Resistance >2000M (at 500V DC)
Withstanding Voltage 2500V AC (1 min)
Sealing Method Silicone O-ring
Contact Material Copper alloy, gold-plated
Connector Gender Female
Contact Resistance 5m
Flame Retardant Rating UL94-V0
Number of Pins 2
Shell Material High strength plastic (PA66)
Mounting Type Panel Mount
Cable Diameter Range 6mm to 12mm
Wire Termination Solder terminal

YM20 20A 2Pin Female Socket IP68 Waterproof Power Connector Panel Mount Plastic Shell Solder Terminal Product Specifications

Product Type Power Connector
Rated Voltage 500V AC
IP Rating IP68
Operating Temperature -25C to +85C
Power Supply Through panel mount connection
Dimension (L*W*H) Panel mount face approx. 35mm diameter x 50mm depth with terminals
Interface 2 pin solder terminal
Capacity 20A Max
Power Source External power via connector
Usage For power connections in industrial and outdoor equipment
Thickness Approx. 3mm (panel mount flange)
Application Outdoor, LED lighting, industrial machinery, control cabinets
Components Female socket, waterproof ring, screw fixtures
Input 2 pin socket
Color Black
Current Rating 20A
Output 2 pin solder terminal
Weight Approx. 50g
Features Waterproof, dustproof, corrosion-resistant, panel mountable, easy installation
Frequency 50/60Hz
Size YM20 series (20mm shell diameter)
Supply Voltage Up to 500V AC
Function Panel mount female power connector

Mating Cycle Durability >500 cycles
Environmental Protection UV resistant, suitable for outdoor use
Insulation Resistance >2000M (at 500V DC)
Withstanding Voltage 2500V AC (1 min)
Sealing Method Silicone O-ring
Contact Material Copper alloy, gold-plated
Connector Gender Female
Contact Resistance 5m
Flame Retardant Rating UL94-V0
Number of Pins 2
Shell Material High strength plastic (PA66)
Mounting Type Panel Mount
Cable Diameter Range 6mm to 12mm
Wire Termination Solder terminal

YM20 20A 2Pin Female Socket IP68 Waterproof Power Connector Panel Mount Plastic Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:500V
Withstanding voltage:2500V
Insertion and extraction force:4.0N Max
Screw torque:42-53 (N.m)
Mating cycle:1700 Times
Temperature and humidity:-4080C; 40C, 85%RH
Contact dimension:Phi 2.7*2

Durable Waterproof Design for Outdoor Usage

With its IP68 rating and UV-resistant, high-strength PA66 plastic shell, the YM20 connector is built to withstand harsh environmental conditions. A silicone O-ring ensures a watertight seal, making it perfectly suited for outdoor power connections and industrial environments prone to moisture or dust exposure.

Easy and Secure Panel Mount Installation

The connector is designed for panel mounting, featuring a 3mm thick flange and screw fixtures for straightforward and stable installation. Its solder terminals simplify wiring, providing secure and reliable contact for efficient power delivery in a wide range of equipment and enclosures.

FAQ's of YM20 20A 2Pin Female Socket IP68 Waterproof Power Connector Panel Mount Plastic Shell Solder Terminal:

Q: How do I install the YM20 2Pin Female Socket on a panel?

A: To install, first prepare a panel cutout based on the connector's diameter. Insert the socket through the hole, secure it with the included screws, and ensure the silicone O-ring is properly positioned for sealing. Connect your wires to the solder terminals, and then verify all connections before powering up.

Q: What makes this connector suitable for outdoor and industrial uses?

A: The connector's IP68 waterproof rating, UV resistance, and flame-retardant PA66 shell make it well-suited for outdoor and harsh industrial conditions. Its gold-plated contacts and corrosion-resistant materials deliver long-term reliability even in challenging environments.

Q: When should I use a panel mount power connector like the YM20?

A: Panel mount connectors like the YM20 are ideal when you require a secure, permanent connection in equipment housings or control panels. Use it for LED lighting systems, industrial machinery, or any application needing robust, water and dustproof power links.

Q: What is the benefit of the gold-plated copper alloy contacts?

A: Gold-plated copper alloy contacts offer excellent conductivity and superior corrosion resistance, ensuring stable electrical performance over more than 500 mating cycles, even if exposed to humidity or challenging conditions.

Q: Where can the YM20 connector be effectively used?

A: This connector can be used in control cabinets, LED street lighting, outdoor equipment, industrial machines, and other locations where reliable, waterproof panel-mounted power connections are needed.

Q: What cable sizes are compatible with this connector?

A: The YM20 supports cable diameters ranging from 6mm to 12mm, making it versatile for various cable types and power requirements in industrial and outdoor settings.
