YM24 10A 12Pin Female Socket IP67 Waterproof Power Connector

1003.0 INR/Piece

Get a Price/Quote

Product Details:

Interface Screw/Panel Mount
Features Waterproof, Dustproof, Durable, High current capacity
Power Supply AC/DC
Operating Temperature -40C to +80C
IP Rating IP67
Input Female socket, panel mount
Output 12 pin connection
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

YM24 10A 12Pin Female Socket IP67 Waterproof Power Connector Price And Quantity

Minimum Order Quantity 100 Piece
Price 1003.0 INR/Piece

Sealing Method Rubber sealing ring
Connection Type Solder or screw terminal
Mating Cycles >500 times
Mounting Type Panel mount with flange
Contact Material Copper alloy with gold or silver plating
Flame Retardant Grade UL94 V-0
Cable Diameter Range 8mm - 12mm
Insulation Material High-grade engineering plastic

YM24 10A 12Pin Female Socket IP67 Waterproof Power Connector Product Specifications

Frequency 50/60Hz
Thickness Standard industrial type
Supply Voltage Up to 250V
Interface Screw/Panel Mount
Features Waterproof, Dustproof, Durable, High current capacity
Power Supply AC/DC
Current Rating 10A
Function Power connection for industrial equipment
Operating Temperature -40C to +80C
IP Rating IP67
Rated Voltage 250V AC
Capacity 10A per pin
Color Black
Weight Approx. 80g
Product Type Waterproof Power Connector
Dimension (L*W*H) Approx. 47mm (diameter, flange) x 60mm (length)
Input Female socket, panel mount
Output 12 pin connection
Size YM24 standard, flange mount
Application Industrial automation, machinery, power distribution
Power Source External power supply
Components Female socket, IP67 housing, sealing ring
Usage Outdoor/Indoor power supply connections

Sealing Method Rubber sealing ring
Connection Type Solder or screw terminal
Mating Cycles >500 times
Mounting Type Panel mount with flange
Contact Material Copper alloy with gold or silver plating
Flame Retardant Grade UL94 V-0
Cable Diameter Range 8mm - 12mm
Insulation Material High-grade engineering plastic

YM24 10A 12Pin Female Socket IP67 Waterproof Power Connector Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Connecting mode:latching lock
Contact diameter:phi 3.0x3
Operating voltage(AC.V.rms):500V
Withstand voltage(AC.V)1min:2500V
Temperature and humidity:-4080C, 40C, 85%RH

Exceptional Durability and Safety

This connector is constructed with flame-retardant UL94 V-0 rated plastic and a tough waterproof IP67 housing. The rugged build ensures resilience in harsh industrial settings, while the copper alloy contacts with gold or silver plating deliver excellent conductivity and corrosion resistance, making the socket suitable for both outdoor and indoor environments.

Versatile Industrial Applications

With a capacity of 10A per pin and a 12-pin configuration, the YM24 female socket is tailored for industrial automation, machinery power distribution, and equipment needing secure and efficient connections. Its panel mount with flange design allows for easy and reliable integration into control panels and junction boxes in various sectors.

Reliable Waterproof and Dustproof Design

Protected by a rubber sealing ring, the connector maintains an IP67 rating, preventing water and dust ingress even when exposed to challenging conditions. This guarantees consistent performance and long operational lifespan for equipment deployed in moisture-prone or dusty locations.

FAQ's of YM24 10A 12Pin Female Socket IP67 Waterproof Power Connector:

Q: How do I install the YM24 10A 12Pin Female Socket onto a panel?

A: To install the YM24 socket, simply prepare the panel with the correct cutout for the flange mount, secure the socket with screws through the flange holes, and connect your cables using either the solder or screw terminals as per your application requirements.

Q: What environments is this female socket suitable for?

A: This connector is designed for both indoor and outdoor environments, thanks to its IP67 waterproof and dustproof rating. It operates reliably in temperatures from -40C to +80C, making it ideal for industrial automation, machinery, and outdoor power distribution.

Q: What is the cable diameter range supported by this socket?

A: The YM24 12Pin Female Socket supports cable diameters from 8mm to 12mm, accommodating a wide variety of standard industrial power cables.

Q: What are the benefits of using the copper alloy contacts with gold or silver plating?

A: Copper alloy contacts plated with gold or silver offer enhanced electrical conductivity, reduce contact resistance, and provide excellent corrosion resistance, ensuring reliable power transfer and a long connector service life.

Q: What is the process for achieving a waterproof seal with this connector?

A: The waterproof seal is created using the included rubber sealing ring, which compresses between the connector and the panel during mounting, preventing ingress of water and dust for IP67 protection.

Q: Can this socket handle both AC and DC power supplies?

A: Yes, the YM24 connector is rated for up to 250V AC or DC, allowing for flexible power supply options in various industrial systems.
