2.54mm Xh Male SMD Connector

Get a Price/Quote

Product Details:

Humidity % 85% RH
Connector Type Male SMD XH Series
Insulation Material Nylon 66 (UL94V-0)
Shape Rectangular
Surface Finish Tin Plated Contacts
Overheating Protection NO
Mounting Type Surface Mount (SMD)
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

2.54mm Xh Male SMD Connector Price And Quantity

Minimum Order Quantity 10 Piece

2.54mm Xh Male SMD Connector Product Specifications

Output Type SMD Connector Terminal
Dimension (L*W*H) Varies by No. of pins (e.g. 2-pin: 6.4mm x 4.5mm x 11.0mm)
Protection Level Standard
Rated Voltage 250V AC/DC
Feature Flame Retardant, Halogen-Free
IP Rating Not Rated (Open Connector)
Operating Temperature -25C to +85C
Overheating Protection NO
Mounting Type Surface Mount (SMD)
Shape Rectangular
No Of Poles 2 to 12 (Available in various positions)
Application PCB Mount, Wire-to-board Connection, Consumer Electronics, Industrial Equipment
Surface Finish Tin Plated Contacts
Material Housing: Nylon 66 UL94V-0, Contacts: Phosphor Bronze, Tin Plated
Product Type XH Male SMD Connector
Phase Single
Insulation Material Nylon 66 (UL94V-0)
Connection Type Surface Mount (SMD)
Humidity % 85% RH
Weight 2g (approx)
Connector Type Male SMD XH Series
Color White (Housing)
Size 2.54mm Pitch
Input Voltage 250V AC/DC maximum

Lead-Free Yes
Withstanding Voltage 1000V AC/minute
Insulation Resistance 1000 M at 500V DC
Brand Compatibility Universal/JST XH Compatible
Contact Resistance 20 m
Standard Packing Tape & Reel for SMT
RoHS Compliance Yes
Row Configuration Single Row
Pitch 2.54mm
Mating Cycles Over 20 cycles
