Dsub Wire Wrap

Get a Price/Quote

Product Details:

Response Time Instantaneous Signal Transfer
Features Corrosion Resistant; Solderless; Durable Wire Wrap Posts; Easy Installation
Components Metal Shell, Wire Wrap Pins, Insulator, Mounting Hardware
IP Rating Not Rated (Standard indoor use)
Output Multi-Pin Electrical Signal
Operating Temperature -55C to +105C
Input Multi-Pin Electrical Signal
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Dsub Wire Wrap Price And Quantity

Minimum Order Quantity 10 Piece

Dsub Wire Wrap Product Specifications

Product Type Dsub Wire Wrap Connector
Frequency DC to Several MHz
Capacity Up to 50 Signal Contacts
Function Electrical Signal Transmission and Secure Connection
Application Computers, Data Communication Devices, Industrial Control, Networking, Panel Boards
Output Multi-Pin Electrical Signal
Dimension (L*W*H) Varies per pin count; Example (9-pin): 30.81mm x 12.55mm x 12.5mm
Usage Used for Wire Wrapping in D-sub Connectors; Applications in Electronics and Communication Equipment
Rated Voltage 300V AC/DC
Size Standard D-sub Sizes: 9, 15, 25, 37, 50 pin
Interface D-sub Interface (Standardized Multi-pin)
Current Rating 5A Max per Pin
Weight Approx. 5-8g per connector
Input Multi-Pin Electrical Signal
Color Silver with Blue/White Insulator
Operating Temperature -55C to +105C
Thickness Standard Pin Thickness: ~0.64 mm (0.025)
Features Corrosion Resistant; Solderless; Durable Wire Wrap Posts; Easy Installation
Response Time Instantaneous Signal Transfer
Components Metal Shell, Wire Wrap Pins, Insulator, Mounting Hardware
IP Rating Not Rated (Standard indoor use)

Insulation Resistance >=1000 M at 500V DC
Mounting Style Panel Mount or PCB Mount
Contact Termination Wire Wrap
Pin Type Wire Wrap Post, Square Pin 0.64 x 0.64 mm
Contact Resistance 20 m
Environment RoHS Compliant
Flammability Rating UL 94V-0
Material Nickel-Plated Steel Shell with Gold or Tin Plated Copper Alloy Contacts
Contact Plating Gold or Tin over Nickel
Shell Size E, A, B, C, D (Dependent on Pin Count)
Number of Rows 2 or 3 (Depending on Pin Count)
Connector Gender Male/Female

Product Description

Discover the famed D-sub Wire Wrap connector, engineered to provide flawless performance in communication and electronics equipment. Its astonishing nickel-plated steel shell, paired with gold or tin-plated copper alloy contacts, guarantees unrivaled conductivity and corrosion resistance. Mount effortlessly on your panel or PCB-this RoHS compliant connector meets the UL 94V-0 flammability rating for safe operations. Add to Cart today for secure, solderless wire wrapping at the best price. Order now; experience a durable, industry-grade solution for instantaneous signal transfer!

Dsub Wire Wrap: Special Features and Competitive Advantages

The Dsub Wire Wrap stands out with corrosion-resistant metal shells, solderless wire wrap posts, and unmatched durability, making it ideal for electronics, computers, and industrial controls. This connector supports wire-wrapping techniques for robust and reliable installations, offering competitive advantages and easy panel or PCB mounting. Its versatile applications in networking and panel boards showcase its adaptability and performance under rigorous usage scenarios.

Certifications and Domestic Logistics: Streamlined Dispatching

Our Dsub Wire Wrap is certified RoHS compliant and meets the UL 94V-0 flammability rating, ensuring low expenditure on replacement and maintenance. With a robust supply chain, we efficiently dispatch products from our main domestic market-India-through reputed logistics at your chosen FOB port. This approach enables rapid and cost-effective deliveries, enhancing reliability and minimizing downtime while meeting global export and import standards.

FAQ's of Dsub Wire Wrap:

Q: How can the Dsub Wire Wrap benefit my electronics or industrial setup?

A: The Dsub Wire Wrap ensures secure, corrosion-resistant connections with instantaneous signal transfer, making it an excellent choice for electronics, computers, industrial controls, and networking applications.

Q: What mounting styles are supported by this connector?

A: It supports both panel mount and PCB mount, providing installation flexibility to match your project requirements.

Q: Where is the Dsub Wire Wrap commonly used?

A: This connector is widely used in computers, data communication devices, industrial control systems, networking components, and panel boards.

Q: What certifications does the Dsub Wire Wrap meet?

A: The connector is RoHS compliant and meets the UL 94V-0 flammability rating, ensuring safety and adherence to international industry standards.

Q: What is the process for ordering and dispatching these connectors?

A: Once you order today or add to cart, we ensure prompt dispatching via dependable logistics from our main market in India, with efficient handling at the designated FOB port.

Q: Is it easy to install and does it require soldering?

A: Installation is easy thanks to the durable wire wrap posts, allowing robust connections without the need for soldering.

Tell us about your requirement

Price:

Quantity

Select Unit

50
100
200
250
500
1000+

Additional detail

Mobile number

Other Products in 'D SUB Connector' category

RS232 44 Pin Dsub Solderless Minimum Order Quantity : 100 Size : Standard 44pin DSub size Application : Data transfer, Device connectivity, Testing, Prototyping Color : Silver/Grey (metallic) Operating Temperature : 55C to +105C Features : Solderless screw terminals, Removable shell, Corrosionresistant metal housing, Easy assembly Usage : For connecting RS232 serial devices Power Supply : Not applicable (passive connector) IP Rating : IP20 Interface : 44 pin Dsub (RS232 standard pinout) Current Rating : 5A (maximum) Product Type : DSub Connector (Solderless) Dimension (L*W*H) : Approx. 69mm x 16mm x 30mm Thickness : Standard shell thickness approx. 1.5mm Weight : Approx. 34g Function : RS232 data communication interface Components : Metal shell, 44 contact pins, Solderless screw terminals Rated Voltage : 250V AC (maximum) Capacity : 44pin connectivity

Send Inquiry

Machine Pin Dsub 5+2 Pin 7 W 2 Size : Standard 7Way DSub (5+2 pin) size Application : Data communication, industrial, and electronic equipment Color : Silver/Gold (Plated) Operating Temperature : 40C to +85C Features : High precision machine pins, corrosion resistant, durable, secure fit, easy soldering Usage : Used for connecting electronic devices via Dsub interface Power Supply : Not applicable (Passive component) IP Rating : IP20 Interface : DSub 7W2 (5+2 Pin) Current Rating : 5A max Product Type : Dsub Connector (Machine Pin, Solder Type) Dimension (L*W*H) : Approx. 22.8 mm x 10.0 mm x 7.2 mm (shell size) Thickness : Standard Pin Thickness 0.50.8 mm Weight : 25 grams (approx.) Function : Electrical connection and signal transmission Components : Brass pins, tin/gold plating, molded plastic insulator, and metal shell Rated Voltage : 250V AC/DC Capacity : Supports 7 Pin Connection

Send Inquiry

Dsub Hex Stud Minimum Order Quantity : 100 Size : M3, M3.5 standard (other custom sizes available) Application : Electronic enclosure, PCB chassis, equipment Color : Nickel Plated / Metallic Silver Operating Temperature : 20C to +80C Features : Rugged, corrosion resistant, easy to install Usage : Fixing and locking Dsub connectors Interface : Mechanical Mount Product Type : DSub Hex Stud Dimension (L*W*H) : L = 612mm (varies by model) Thickness : Standard Weight : Approx. 25 grams per piece Function : Secures Dsub connectors to mating connectors or panels Components : Stud body, hex head, threads
