HIROSE HR10A-7P-10P MALE PLUG

HIROSE HR10A-7P-10P MALE PLUG Price And Quantity

• Minimum Order Quantity 100 Piece

HIROSE HR10A-7P-10P MALE PLUG Product Specifications

• Power Supply Not applicable (passive connector)
• IP Rating IP40
• Dimension (L*W*H) Length approx. 39.5 mm x Diameter 12 mm
• Components Shell, insulator, contacts
• Application Industrial automation, measurement equipment, medical devices, security and communication systems
• Usage For cable-to-equipment, cable-to-cable connections
• Size HR10A-7P-10P (compatible with cable diameter 3.5-5mm)
• Current Rating 2A per contact max at 100V AC/DC
• Function Electrical signal and power connector for cables and devices
• Color Silver (metallic)
• Weight Approximately 12 g
• Supply Voltage Upto 100 V AC (as per rated voltage)
• Rated Voltage 100 V AC / 140 V DC
• Operating Temperature -25C to +85C
• Input Up to 10 signal lines
• Interface Solder cup type
• Features Quick push-pull lock, compact size, lightweight, easy soldering, durable connection
• Output Up to 10 signal lines
• Product Type Circular male plug connector
• Capacity 10 pins (contacts)

• Cable Diameter Range 3.5 mm to 5 mm
• Connector Series HR10A
• Mating Cycles 1000 cycles min
• Locking Mechanism Push-pull self-latching system
• Mounting Type Free/hanging cable mounting
• Insulation Resistance 1000 M min at 500V DC
• Compliance RoHS compliant
• Contact Material Gold plated phosphor bronze
• Contact Resistance 15 m max
• Shell Material Nickel plated brass
