Ip68 Waterproof Connector SP17 Male Panel

Get a Price/Quote

Product Details:

Mounting Type Panel Mount
Efficiency High Transmission Efficiency
Overheating Protection Yes (Design Rated)
Feature IP68 Waterproof, UV Resistant, Corrosion Resistant
Operating Temperature -25C to +85C
Connector Type Male Circular Connector, Panel Mount
Shape Round
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Ip68 Waterproof Connector SP17 Male Panel Price And Quantity

Minimum Order Quantity 100 Piece

Ip68 Waterproof Connector SP17 Male Panel Product Specifications

Phase Single or Multi-phase (Depending on Poles)
Size SP17 (17mm Diameter)
Humidity % 0-95% RH (Non-condensing)
No Of Poles 2, 3, 4, 5, 7, 9 Poles Available
Material PA66 Nylon (Body), Copper Alloy (Contacts)
Shape Round
Frequency (MHz) 50/60Hz
IP Rating IP68
Insulation Material PA66 Nylon
Surface Finish Matte
Application Outdoor Electrical Equipment, LED Lighting, Machinery, Automation, Marine, Instrumentation
Connection Type Solder/Crimp (Depending on Model)
Input Voltage 250V Max
Connector Type Male Circular Connector, Panel Mount
Color Black
Output Type Panel Mount Male Socket
Protection Level Full Waterproof and Dustproof
Mounting Type Panel Mount
Rated Voltage 250V AC/DC
Dimension (L*W*H) Approx. 23mm x 53mm (Excludes Cable)
Product Type IP68 Waterproof Connector, SP17 Male Panel Mount
Weight 25g
Efficiency High Transmission Efficiency
Overheating Protection Yes (Design Rated)
Operating Temperature -25C to +85C
Feature IP68 Waterproof, UV Resistant, Corrosion Resistant

Flame Retardant Grade UL94-V0
Sealing Material Silicone Rubber Gasket
Torque 2-3Nm (Panel Nut Tightening)
Current Rating 10A Max (Depends on Model)
Cable Outer Diameter 6-10mm Suitable
Mating Cycles >500 Times
Contact Resistance 5m
Wire Range 24~16 AWG
Insulation Resistance >2000M at 500V DC

Product Description

Grab this illustrious IP68 Waterproof Connector SP17 Male Panel for applications where performance can't be compromised. Crafted from PA66 nylon with copper alloy contacts, this breathtaking connector withstands harsh environments-UV radiation, water, and corrosion-ensuring continuity. Scarce in supply due to high demand, this connector boasts astonishing features: 10A max current rating, insulation resistance over 2000M, and mating cycles exceeding 500. Equipped with a silicone rubber gasket, it is designed for outdoor LED lighting, machinery, marine, and automation. Purchase yours now for robust, high-efficiency, and reliable power connections.

Comprehensive Applications and Direct Usage

The SP17 Male Panel connector is engineered for direct panel mount installation, using either solder or crimp contacts depending on your requirements. Ideal for LED lighting, marine apparatus, automation, and outdoor electrical devices, simply secure it with recommended 2-3Nm torque and ensure proper cable range (6-10mm OD). Its full waterproofing and dustproof rating make it suitable for both indoor and outdoor environments. Additional applications include instrumentation, machinery controls, and distribution panels.

Delivery, Sample Availability, and Supply Capacity

Expect swift delivery for your IP68 Waterproof Connector SP17 Male Panel-promptly shipped and typically arriving within days, based on location and order volume. Sample units are available for initial testing, allowing you to evaluate its breathtaking performance firsthand. Our high-volume supply rate guarantees uninterrupted availability for trade, wholesale, and industrial projects across India. Secure your batch now and experience seamless arrival and support for all distribution needs.

FAQ's of Ip68 Waterproof Connector SP17 Male Panel:

Q: How do I properly install the IP68 Waterproof Connector SP17 Male Panel?

A: To install, mount the connector on your panel using the designated hole, ensuring you use a torque of 2-3Nm for the panel nut. Connect wires with either solder or crimp methods, suitable for 24~16 AWG cables, and secure cables with diameters between 6-10mm for optimal waterproof performance.

Q: What are the primary usage benefits of this connector in outdoor environments?

A: The SP17 Male Panel connector offers outstanding water and dust resistance (IP68), corrosion and UV exposure protection, and a flame retardant design, making it ideal for outdoor electrical, marine, and industrial applications where safety and durability are critical.

Q: When can I expect my order to be delivered after purchase?

A: Typically, orders are processed and shipped rapidly, with arrival times depending on your location and quantity ordered. Customers in India can generally expect delivery within a few working days.

Q: Where can this connector be effectively used besides industrial automation?

A: Alongside industrial automation, it excels in LED lighting systems, marine installations, instrumentation, and machinery due to its high transmission efficiency and robust weather resistance.

Q: What is the process for obtaining a sample of the SP17 Male Panel connector?

A: To request a sample, contact our sales team with your project requirements. Samples are dispatched promptly, enabling you to test performance before making a bulk purchase.

Q: How does the connector ensure protection against overheating?

A: The connector is rated for overheating protection by design, utilizing materials and contact structures that disperse heat effectively, ensuring safety during high-current operation.
