LP20 10A 5Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal

493.0 INR/Piece

Get a Price/Quote

Product Details:

Operating Temperature -40C to +80C
Output 5 Pins, Power/Signal Supply
Interface Solder Terminal, 5 Pin
Power Source Wired electrical supply
IP Rating IP67
Usage Industrial / Outdoor Electrical Connections
Features Waterproof, Dustproof, Flange Mount, Durable Metal Construction
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP20 10A 5Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal Price And Quantity

Price 493.0 INR/Piece
Minimum Order Quantity 100 Piece

Contact Resistance 5m
Sealing Method O-Ring Gasket
Locking System Threaded Coupling
Mount Type Flange Mount
Insulation Resistance 2000M at 500V DC
Mating Cycle >500 times (durability)
Protection Level IP67 Waterproof / Dustproof
Connection Method Solder Type
Wire Size Applicable up to 2.5mm2 (AWG14)
Shell Material Zinc Alloy
Contact Material Copper Alloy with Gold Plating

LP20 10A 5Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal Product Specifications

Operating Temperature -40C to +80C
Output 5 Pins, Power/Signal Supply
Interface Solder Terminal, 5 Pin
Size 20mm series
Current Rating 10A
Color Silver (Metallic)
Usage Industrial / Outdoor Electrical Connections
Product Type Waterproof Power Connector Socket
IP Rating IP67
Power Source Wired electrical supply
Input 5 Pins, Female Socket
Components Metal Shell, Solder Terminals, Gasket
Features Waterproof, Dustproof, Flange Mount, Durable Metal Construction
Capacity 10A
Dimension (L*W*H) Flange diameter approx. 29mm
Power Supply AC / DC
Weight Approx. 45g
Rated Voltage 500V AC
Function Power Connection
Frequency 50/60Hz
Supply Voltage Up to 500V
Application LED Lighting, Equipment, Power Distribution

Contact Resistance 5m
Sealing Method O-Ring Gasket
Locking System Threaded Coupling
Mount Type Flange Mount
Insulation Resistance 2000M at 500V DC
Mating Cycle >500 times (durability)
Protection Level IP67 Waterproof / Dustproof
Connection Method Solder Type
Wire Size Applicable up to 2.5mm2 (AWG14)
Shell Material Zinc Alloy
Contact Material Copper Alloy with Gold Plating

LP20 10A 5Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:400V
Withstanding voltage:2500V
Mating cycle:1700 Times
Temperature and humidity:-40+80C; 40C,85%RH
Contact dimension:Phi 2.7x3
Screw torque:42-53 (N.m)

Reliable Waterproof & Dustproof Design

Boasting an IP67 protection rating, the LP20 10A 5Pin Female Socket is engineered for challenging environments. The device's O-ring gasket and durable metal shell ensure excellent sealing, making it impervious to water and dust infiltration. This reliability makes it ideal for both outdoor and industrial applications where environmental resistance is non-negotiable.

Efficient and Secure Power Connection

With a copper alloy contact system and gold plating, this connector offers low contact resistance (5m) and high insulation resistance (2000M at 500V DC). The reliable threaded coupling mechanism guarantees a secure interface, minimizing the risk of accidental disconnection during operation. Its capability to carry 10A at up to 500V AC/DC supports diverse power distribution needs.

Versatile Installation and Usage

The product's flange mount design simplifies secure installation in panels or enclosures. Suitable for both power and signal transmission, the connector integrates seamlessly into a variety of systems, including LED lighting, industrial machinery, and outdoor power distribution. Its robust construction and easy-to-use solder connections make it favorable among manufacturers, exporters, and installers.

FAQ's of LP20 10A 5Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal:

Q: How is the LP20 10A 5Pin Female Socket installed in equipment?

A: This socket features a flange mount design for stable attachment to panels or enclosures. Installation involves securely fastening the flange with screws and soldering wires up to 2.5mm2 (AWG14) to the terminals. The threaded coupling ensures a firm connection with the mating plug.

Q: What environmental benefits does the IP67 rating provide?

A: IP67 signifies complete protection against dust and resistance to water immersion up to 1 meter for 30 minutes. This makes the connector highly suitable for outdoor and industrial environments prone to moisture, debris, and adverse weather, thereby enhancing equipment reliability.

Q: Where is this connector best utilized?

A: The LP20 female socket is well-suited for applications such as LED lighting installations, power distribution units, industrial electrical setups, and outdoor equipment. Its rugged build and waterproof design allow it to perform in both indoor and demanding outdoor settings.

Q: What process should be followed to connect wires to this socket?

A: To connect wires, strip the insulation from wires (up to 2.5mm2), insert them into the appropriate terminal, and solder them securely. Ensure correct pin alignment according to your circuit, then mount the socket and use the threaded coupling to seal with the corresponding male plug.

Q: What are the benefits of the gold-plated copper alloy contacts?

A: Gold-plated copper alloy contacts offer superior conductivity, corrosion resistance, and minimize electrical loss. This guarantees a stable, long-lasting connection with low contact resistance, even in challenging environmental conditions.

Q: How durable is this connector for repeated use?

A: The connector supports over 500 mating cycles, ensuring reliable performance across numerous connection and disconnection operations without compromising efficiency or safety.
