M12 12 Pin Male and female bulkhead front nut

1850 INR/Piece

Get a Price/Quote

Product Details:

Voltage Rating 250V AC/DC
Temperature -25C to +80C
Material Brass with Nickel Plating (Connector), PA66 (Insulator)
Female End Type M12 Female Bulkhead, Solder Type
Connector M12 Male/Female
Capacity 12 Pin Signal Transmission
Connector Type Front Nut Bulkhead Mount
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

M12 12 Pin Male and female bulkhead front nut Price And Quantity

Price 1850 INR/Piece
Minimum Order Quantity 100 Piece

M12 12 Pin Male and female bulkhead front nut Product Specifications

Connector Type Front Nut Bulkhead Mount
Capacity 12 Pin Signal Transmission
Jacket Material PVC or PUR
Color Black
Cable Type PVC/PUR jacketed signal cable
Material Brass with Nickel Plating (Connector), PA66 (Insulator)
Male End Type M12 Male Bulkhead, Solder Type
Pairs 12 single conductors
Application Sensor/Actuator connection, Industrial Automation
Insulation PVC or PUR
Sheild Optional, according to customer requirements
Voltage Rating 250V AC/DC
Female End Type M12 Female Bulkhead, Solder Type
Length Customizable
Connector M12 Male/Female
Cable Length As per requirement (typically 1m, 2m, 5m, 10m)
Temperature -25C to +80C
Wire Gauge 26 AWG
Flame Resistance Level UL94 V-0
Number of Conductor 12
Outer Diameter 6.5mm 0.2mm

Ingress Protection IP67 (when mated)
Contact Resistance 10 m
Insulation Resistance > 100 M (at 500V DC)
Mounting Type Panel Mount with Front Nut
Standard IEC 61076-2-101
Thread Size M12 x 1.0
Contact Material Gold Plated Brass
Mating Cycle > 100 Cycles
Current Rating 4A maximum (per pin)
Termination Type Solder
Clamp Range 4-6 mm (cable diameter)

Product Description

Experience the exclusive and latest innovation in connectivity with our M12 12 Pin Male and Female Bulkhead Front Nut connectors. Featured for their radiant signal integrity and peerless durability, these connectors are built for triumphant performance in industrial automation and sensor-actuator applications. Achieving an IP67 ingress rating and UL94 V-0 flame resistance, they secure optimal operations even in challenging conditions. Gold-plated brass contacts, customizable cable lengths, and a robust PVC/PUR jacket provide unmatched reliability, ensuring high-quality, secure connections that meet IEC 61076-2-101 standards. Ideal for distributors, manufacturers, and industrial users across India.

Versatile Usage & Functionality

The M12 12 Pin Male and Female Bulkhead Front Nut is expertly designed for panel mounting in industrial settings, serving as a reliable interface for sensor and actuator connections. Used in both automation and signal transmission, it facilitates robust connections where high-density pin count and secure mating are paramount. Its solder-type terminals and front nut mounting make it ideal as a fixed connector for various machinery and equipment, ensuring consistent and efficient performance in demanding environments.

Reliable Supply & Packaging Solutions

Our supply proposal amount is tailored for large and small orders alike, guaranteeing stock readiness for immediate dispatch. Each M12 12 Pin Bulkhead connector is meticulously packaged to ensure safe transit and arrives ready for installation. We efficiently cater to the main domestic market in India, with flexible supply options and fast delivery. Customers can choose from various cable lengths, with stocks available for both short and bulk quantities according to usage requirements.

FAQ's of M12 12 Pin Male and female bulkhead front nut:

Q: How do I install the M12 12 Pin bulkhead connectors using the front nut feature?

A: To install the M12 12 Pin bulkhead connectors, insert the connector through the panel opening, secure it with the provided front nut, and solder the wires to the designated terminals according to wiring requirements.

Q: What applications are these connectors best suited for?

A: These connectors are best suited for industrial automation, sensor and actuator connections, and anywhere a robust, high-pin-count interface is needed, particularly in harsh or high-vibration environments.

Q: When should I choose optional shielding for these connectors?

A: Optional shielding is recommended when your application requires additional protection against electromagnetic interference (EMI) or where signal integrity is critical in electrically noisy environments.

Q: Where can I use the M12 bulkhead connectors within an industrial setup?

A: The connectors are designed for panel mounting in machinery, control panels, and other industrial equipment requiring secure multi-pin connectivity for signal or power transmission.

Q: What are the benefits of the gold-plated brass contacts and the specified insulation materials?

A: Gold-plated brass contacts ensure low contact resistance and excellent corrosion resistance, while PVC or PUR insulation provides flexibility, chemical resistance, and durability in harsh operating conditions.
