M12 To Rj45 Adapter

Get a Price/Quote

Product Details:

Connector M12 A-coded to RJ45 male plug
Temperature -20C to +80C
Material Copper (core), PVC (jacket)
Voltage Rating 30 V AC/DC
Application Industrial Ethernet, Fieldbus system, Network connection
Pairs 4
Connector Type Straight
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

M12 To Rj45 Adapter Price And Quantity

Minimum Order Quantity 100 Piece

M12 To Rj45 Adapter Product Specifications

Material Copper (core), PVC (jacket)
Connector M12 A-coded to RJ45 male plug
Cable Type Cat5e FTP
Connector Type Straight
Pairs 4
Application Industrial Ethernet, Fieldbus system, Network connection
Wire Gauge 24 AWG
Voltage Rating 30 V AC/DC
Outer Diameter 6.0 mm
Temperature -20C to +80C
Number of Conductor 8
Flame Resistance Level UL94V-0
Sheild Yes, overall shielded
Length 0.3 Meter
Jacket Material PVC
Color Black
Capacity 10/100 Mbps Ethernet
Insulation HDPE
Male End Type RJ45 8P8C male
Cable Length 30 cm
Female End Type M12 A-coded 8 pin female

IP Rating IP67 (M12 side only)
Shield Coverage 85%
Impedance 100 15% (at 1-100 MHz)
Contact Resistance 5 m
Shielding Type Foil and Braid
Durability 100 mating cycles
RoHS Compliance Yes

Product Description

Discover the ephemeral advantage with our M12 To RJ45 Adapter, a glorious solution engineered for pristine connectivity. Featuring unbeatable contact resistance of 5 m and robust IP67 rating (M12 side), this adapter brilliantly withstands harsh environments. Overall shielded with 85% foil and braid coverage, it delivers uncompromised data transfer at 10/100 Mbps Ethernet. Grab yours now - crafted with copper core, 24 AWG wire, and HDPE insulation for unmatched reliability. RoHS compliant and UL94V-0 flame resistant, this black 0.3m adapter is a fleeting, premium find for industrial networking needs.

Versatile Applications & Distinct Advantages

The M12 To RJ45 Adapter is an exceptional solution for industrial Ethernet, Fieldbus systems, and secure network connections in demanding environments. Its application surface extends to factories, automation plants, and data communication centers. Boasting primary competitive advantages such as IP67 water resistance (M12 side), 100 mating cycles, and superior shield coverage, it ensures enduring and stable performance where reliability is paramount. Benefit from both practical versatility and a robust, feature-rich design for your connectivity needs.

Swift Delivery & Premium Certifications

Experience the lowest price, swift Goods Transport, and premium logistics with every order of the M12 To RJ45 Adapter. Each unit is meticulously tested for quality and holds certifications including RoHS compliance and UL94V-0 flame resistance. Major export markets include Europe, Asia, America, and India, supported by experienced distributors, exporters, and importers. Our efficient delivery process ensures prompt arrival, so you never have to wait long for reliable, high-grade connectivity solutions.

FAQ's of M12 To Rj45 Adapter:

Q: How does the shielding of the M12 To RJ45 Adapter benefit industrial applications?

A: The adapter's foil and braid shielding with 85% coverage significantly reduces electromagnetic interference, ensuring stable and reliable network performance in demanding industrial environments.

Q: What applications are ideal for this M12 To RJ45 Adapter?

A: This adapter is perfectly suited for industrial Ethernet, Fieldbus systems, automation networks, and any setting that requires durable and secure network connectivity in challenging conditions.

Q: Where can this adapter be installed for optimum performance?

A: The adapter is designed for use in industrial plants, automation control cabinets, and network communication centers that require IP67-rated, robust connections.

Q: What certifications does the M12 To RJ45 Adapter have?

A: It complies with RoHS standards and UL94V-0 flame resistance, ensuring safety, environmental compliance, and dependable operation under rigorous industrial standards.

Q: How long does it typically take to deliver the M12 To RJ45 Adapter?

A: Thanks to swift Goods Transport and established distributor networks, delivery times are minimized, providing prompt, reliable access to high-quality adapter solutions worldwide.

Q: What is the process for connecting this adapter?

A: Simply connect the M12 A-coded 8-pin female end to your industrial device and the RJ45 8P8C male end to the network port-straight connection ensures secure signal transmission.
