PIN HEADER RIGHT ANGLE

15.0 INR/Piece

Get a Price/Quote

Product Details:

Interface Right Angle, Through Hole
Components Brass pins with plastic insulator
Operating Temperature -40C to +105C
Usage PCB mount, Signal transmission
IP Rating Not Rated (for standard pin headers)
Features Right angle, through hole mounting, tin/gold plated for low resistance
Product Type Right Angle Pin Header Connector
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

PIN HEADER RIGHT ANGLE Price And Quantity

Minimum Order Quantity 100 Piece
Price 15.0 INR/Piece

Material Brass contact, plastic (PA6T/UL 94V-0) insulator
Durability 200 mating cycles
Pin Pitch 2.54 mm standard
No. of Rows Single or dual row
Mounting Type Through-hole right angle
Contact Resistance 20 m
Contact Plating Gold or tin over nickel
Flammability Rating UL 94V-0
Insulation Resistance >1000 M
RoHS Compliance Yes

PIN HEADER RIGHT ANGLE Product Specifications

Capacity Depends on pin count (e.g., 2-40 pins per row)
Rated Voltage 250V AC/DC
Size Standard 2.54 mm pitch; length varies per pin count
Application Electronics, embedded systems, prototyping, industrial automation
Product Type Right Angle Pin Header Connector
Thickness Pin Thickness: 0.64 mm (typical)
IP Rating Not Rated (for standard pin headers)
Weight Approx. 0.5 grams (per pin)
Features Right angle, through hole mounting, tin/gold plated for low resistance
Dimension (L*W*H) Length x Width x Height depends on pin count; typical: 2.54mm x (No. of pins)*(pin-pitch) x ~5mm
Supply Voltage 250V Max
Components Brass pins with plastic insulator
Color Black/Gold
Operating Temperature -40C to +105C
Usage PCB mount, Signal transmission
Current Rating 3A per pin
Function Establishes electrical connections between PCBs or components
Interface Right Angle, Through Hole

Material Brass contact, plastic (PA6T/UL 94V-0) insulator
Durability 200 mating cycles
Pin Pitch 2.54 mm standard
No. of Rows Single or dual row
Mounting Type Through-hole right angle
Contact Resistance 20 m
Contact Plating Gold or tin over nickel
Flammability Rating UL 94V-0
Insulation Resistance >1000 M
RoHS Compliance Yes

PIN HEADER RIGHT ANGLE Trade Information

Supply Ability 100000 Piece Per Day
Delivery Time 2 Days

Product Description

Procure our world-class Right Angle Pin Header-praiseworthy for its robust build and flexible use in industrial, electronics, and embedded systems applications. These customizable headers feature a standard 2.54 mm pin pitch, gold or tin over nickel contact plating, and selectable single or dual rows to capitalise on layout efficiency. With a lavish insulation resistance (>1000 M), durable through-hole mounting, and a flammability rating of UL 94V-0, they deliver reliable signal transmission even under rigorous conditions. RoHS compliance, white, black, or gold finishes, and compatibility across 2-40 pins per row ensure seamless integration with your designs.

Versatile Application and Enhanced Features

The PIN HEADER RIGHT ANGLE is optimally designed for industrial electronics, automation systems, prototyping, and embedded platforms. Capitalise on its versatility-engineers, manufacturers, and prototypers often use these lavish connectors for reliable PCB mounting and signal transmission. Extra features include through-hole mounting, superior current rating (3A per pin), and your choice of gold or tin plating. This header is a praiseworthy solution for robust, long-term connections in demanding environments.

Certifications, Export Markets, and Sample Policy

With RoHS compliance and UL 94V-0 flammability certification, each unit delivered undergoes stringent quality checks to ensure global standards. As a reputable distributor and exporter in India, our PIN HEADER RIGHT ANGLE is exchanged across international markets with efficient order processing. Sample availability allows you to order and test units, streamlining your procurement decisions and ensuring each delivery aligns with your project requirements.

FAQ's of PIN HEADER RIGHT ANGLE:

Q: How does the PIN HEADER RIGHT ANGLE ensure reliable electrical connections between PCBs?

A: This connector features precision-machined brass pins, gold or tin over nickel plating, and a durable plastic insulator, creating stable contacts with low resistance, suitable for industrial and electronic PCBs.

Q: What customization options are available for this pin header?

A: You can select from single or dual row configurations, gold or tin plating, and various pin counts (2-40 per row) to capitalise on design flexibility for your unique application needs.

Q: Where is the PIN HEADER RIGHT ANGLE most commonly used?

A: It is widely used in industrial automation, electronics assemblies, embedded systems, and prototyping environments, supporting a variety of signal transmission and PCB mounting needs.

Q: What are the main certifications and compliance standards met by this product?

A: The pin header is RoHS compliant and rated UL 94V-0 for flammability, ensuring it meets stringent international safety and material standards.

Q: How can I order and receive samples for evaluation?

A: We offer a straightforward sample policy. You can place an order for evaluation units, and samples will be exchanged and delivered quickly for your review before bulk procurement.

Q: What are the benefits of gold or tin over nickel plating in this header?

A: Gold or tin plating over nickel provides excellent corrosion resistance, low contact resistance, and longevity, ensuring praiseworthy performance across mating cycles.

Tell us about your requirement

Price:

Quantity

Select Unit

50
100
200
250
500
1000+

Additional detail

Mobile number

Other Products in 'Pin Header' category

Burg Strip Connectors Price : 4.0 INR/Piece Minimum Order Quantity : 100 Color : White / Transparent Size : Standard: 2.54mm (0.1 inch) pitch Application : Electronics, PCB, Prototyping, Consumer Electronics, Industrial Control Operating Temperature : 40C to 85C Current Rating : 2A 5A (per contact, depends on model) Features : Reusable, Easy to Plug/Unplug, Standard pitch, Polarized version available Components : Plastic housing, Tin/Gold plated brass/copper contacts Usage : Join and terminate electrical wires on PCBs or for prototyping Function : Electrical connection of wires and PCB circuits Capacity : Multiple pin variants (2 pin 40 pin) Rated Voltage : 250V AC Product Type : Burg Strip Connectors Thickness : Approx. 6 mm Weight : Approx. 2g per piece (varies with position count) Dimension (L*W*H) : Depends on number of pins, e.g. 25mm x 6mm x 8mm (for 10 pin) Supply Voltage : Up to 250V AC

Send Inquiry

40x3 bergstrip right angle Minimum Order Quantity : 10 Color : Silver Size : 40x3 mm Application : Junction boxes, control panels, and busbar systems Operating Temperature : 20C to +120C Current Rating : Depends on installation, typically up to 100A Features : Corrosionresistant, durable, easy to install Components : Copper or tinned copper strip Usage : Electrical panel and wiring applications Function : Right angle electrical conducting strip Capacity : High current carrying capacity Rated Voltage : Up to 600V Product Type : Right Angle Bergstrip Thickness : 3mm Weight : Approx. 40g per meter Dimension (L*W*H) : Variable length x 40mm x 3mm Thermal Conductivity : Good, suitable for power distribution Supply Voltage : Up to 600V

Send Inquiry

40x3 Flow Solder Minimum Order Quantity : 10 Color : Silvery Gray Size : 40x3 mm Application : Flow/Wave Soldering Machines, Electronics Assembly Operating Temperature : Melting Point 183190C Features : High Purity, Smooth Flow, Low Dross Formation, Excellent Wetting Components : High Purity Tin and Lead Alloy Usage : Electronics Manufacturing, SMD and Thruhole PCB Soldering Function : Used for soldering and joining electronic components on printed circuit boards (PCBs) in a wave/flow soldering process. Capacity : As per order (customizable) Product Type : Solder Bar / Solder Alloy Thickness : 3 mm Weight : Approximately 1113 kg/ingot Dimension (L*W*H) : 40 mm x 3 mm x Variable Length Thermal Conductivity : Good
