1.27mm burg strip 20mm

Get a Price/Quote

Product Details:

Operating Temperature -40C to +105C
Input Signal/Data transmission
Components Gold-plated/Phosphor bronze pins, plastic housing
Interface Through-hole or SMD
Features Compact design, High-density mounting, Reliable contact
Output Signal/Data conduction
Usage PCB mounting, electrical/electronic circuits
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

1.27mm burg strip 20mm Price And Quantity

Minimum Order Quantity 100 Piece

1.27mm burg strip 20mm Product Specifications

Input Signal/Data transmission
Color Black
Rated Voltage 250V AC/DC
Product Type Burg Strip (Male Header Pin) Connector
Size 20mm length, pitch 1.27mm
Function Electrical connector for mezzanine or board-to-board connections
Thickness Standard pin thickness: 0.4mm
Operating Temperature -40C to +105C
Current Rating 1A Max
Application Electronics, Embedded Systems, Communication devices, Motherboard connection
Weight Approx. 2g (for 20mm length)
Usage PCB mounting, electrical/electronic circuits
Supply Voltage Up to 250V AC/DC
Output Signal/Data conduction
Features Compact design, High-density mounting, Reliable contact
Interface Through-hole or SMD
Dimension (L*W*H) 20mm x ~2.54mm x ~2.5mm
Components Gold-plated/Phosphor bronze pins, plastic housing

Insulation Resistance >=1000M at 500V DC
Insulator Material High-temperature plastic, UL 94V-0
Pin Length 4-6mm (typical exposed length)
Contact Plating Gold Flash or Tin over Nickel
Contact Material Phosphor Bronze or Brass
Contact Resistance 20m
Mounting Type Through-Hole or Surface Mount
Number of Pins Variable (custom and standard configurations available)
Pitch 1.27mm (0.05")
Row Configuration Single Row (Standard), Dual row available
Storage Temperature -50C to +125C

Product Description

Unlock the potential of your electronic designs with our distinguished 1.27mm Burg Strip-20mm length, offering unrivaled reliability for signal and data transmission. Featuring uncommon flexibility, select from custom or standard configurations of variable pins. The superior contact system leverages phosphor bronze or brass with gold flash or tin over nickel plating, ensuring robust performance. Engineered for PCB mounting, it supports both through-hole and surface mount interfaces. Order today and benefit from a special combination of compact design, high-density mounting, and consistently dependable connectivity.

Versatile Application and Superior Features

This 1.27mm burg strip excels in diverse application surfaces such as motherboards, embedded systems, and communication devices, supporting both plant and field installation. With extra features like high-temperature plastic insulation (UL 94V-0), dual row availability, and a compact footprint, it ensures reliable connections in high-density electronic assemblies. Its robust construction and gold-plated or tin-over-nickel contacts provide exceptional data integrity and electrical performance, making it essential for sophisticated electronic and industrial applications alike.

Timely Delivery and Dependable Supply Policy

Benefit from efficient goods transport and reliable outlay schedules with our speedy delivery options for the 1.27mm burg strip-20mm. We maintain outstanding supply ability to meet various customer needs, ensuring that your goods arrive on time and in optimal condition. Our sample policy is straightforward, allowing clients to test product features before making larger commitments. As a trusted distributor, manufacturer, and trader, our processes ensure you always have access to quality connectors when you need them.

FAQ's of 1.27mm burg strip 20mm:

Q: How do I choose between through-hole and surface mount types for the 1.27mm burg strip?

A: Selecting between through-hole and surface mount depends on your PCB design and assembly process. Through-hole offers stronger mechanical support, while surface mount is suitable for compact, high-density layouts.

Q: What is the typical usage of the 1.27mm burg strip in electronic systems?

A: This connector is primarily used for board-to-board, mezzanine, and PCB signal/data transmission applications in electronics, embedded systems, communication devices, and motherboards.

Q: Where can this burg strip be applied within a plant environment?

A: It is ideal for use in industrial control systems, automation panels, and instrumentation inside plant facilities where reliable and high-density connections are crucial.

Q: What benefits do gold flash or tin-over-nickel plated contacts provide?

A: Gold flash plating ensures minimal contact resistance and long-term durability in demanding conditions, while tin-over-nickel plating offers excellent corrosion and wear resistance for cost-sensitive applications.

Q: What is the process for requesting custom configurations or sample products?

A: Simply contact our sales team with your specific pin, length, and row configuration requirements. We offer a streamlined sample outlay policy for clients to evaluate product fit and performance.

Q: When can I expect delivery after placing my order?

A: Standard products are typically dispatched within a few days. For custom configurations, delivery times depend on the complexity and quantity of the order. Our efficient supply chain ensures prompt goods transport.
