DH24 250V 5A 24Pin Female Socket IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal

680.0 INR/Piece

Get a Price/Quote

Product Details:

Interface 24-pin female socket, solder type
Input Solder terminal connection
Operating Temperature -40C to +85C
Power Source Supplied via connector
Output 24-pin female interface
IP Rating IP67
Components Metal shell, 24 solder pin contacts, sealing gasket
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

DH24 250V 5A 24Pin Female Socket IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 680.0 INR/Piece

Applicable Wire Gauge 18-24 AWG
Mating Cycle Durability >=500 cycles
Vibration Resistance MIL-STD-202, Method 204
Flame Rating UL94-V0
Shell Material Zinc alloy, nickel plated
Mounting Type Panel mount
RoHS Compliance Yes
Shielding EMI/RFI shielding (metal shell)
Locking Mechanism Screw coupling
Humidity Resistance MIL-STD-202, Method 103
Cable Entry Size 16mm (cable opening)
Pin Layout 24-pin circular arrangement
Sealing Method Silicone rubber gasket
Insulation Resistance >1000M at 500V DC
Contact Material Copper alloy, gold/tin plated
Contact Resistance 5m

DH24 250V 5A 24Pin Female Socket IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal Product Specifications

Interface 24-pin female socket, solder type
Output 24-pin female interface
Product Type Waterproof Power Connector
Power Source Supplied via connector
Application Outdoor, harsh environments requiring IP67 protection
IP Rating IP67
Capacity 5A per contact
Input Solder terminal connection
Rated Voltage 250V AC
Components Metal shell, 24 solder pin contacts, sealing gasket
Usage Industrial equipment, automation systems, power electronics
Color Metallic Silver
Power Supply AC
Function Power connection and transmission in industrial environments
Supply Voltage 250V
Weight Approx. 89g
Features Waterproof, dustproof, corrosion resistant, robust metal shell
Operating Temperature -40C to +85C
Frequency 50/60Hz
Current Rating 5A
Size Shell size DH24
Dimension (L*W*H) Approx. 37.5mm diameter x 59.5mm length

Applicable Wire Gauge 18-24 AWG
Mating Cycle Durability >=500 cycles
Vibration Resistance MIL-STD-202, Method 204
Flame Rating UL94-V0
Shell Material Zinc alloy, nickel plated
Mounting Type Panel mount
RoHS Compliance Yes
Shielding EMI/RFI shielding (metal shell)
Locking Mechanism Screw coupling
Humidity Resistance MIL-STD-202, Method 103
Cable Entry Size 16mm (cable opening)
Pin Layout 24-pin circular arrangement
Sealing Method Silicone rubber gasket
Insulation Resistance >1000M at 500V DC
Contact Material Copper alloy, gold/tin plated
Contact Resistance 5m

DH24 250V 5A 24Pin Female Socket IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:250V
Temperature and humidity:-4080C; 40C, 85%RH
Wire Gauge:0.150.2mm/26 -24AWG
Withstand voltage(AC.V)1min:2500V
Mating Cycle:1700 Times

Superior Protection and Durability

With an IP67 ingress protection rating, the DH24 24Pin Female Socket confidently resists ingress from water and dust. Its rugged zinc alloy nickel-plated shell and silicone gasket further enhance longevity, making it ideal for outdoor and harsh industrial settings where reliable performance is paramount.

Efficient and Safe Power Connection

Engineered for power supply up to 250V AC and 5A per contact, this connector's gold/tin-plated contacts assure low contact resistance (5m) and superior electrical conductivity. The 24-pin layout supports complex connections, and its flame-retardant UL94-V0 rating adds an essential safety layer.

Easy Installation and Versatile Application

Designed for simple panel mounting and secure attachment with a screw coupling lock, this female socket accommodates 18-24 AWG wires through a 16mm cable entry. Widely used by manufacturers, exporters, and installers in industries like automation, control systems, and power electronics.

FAQ's of DH24 250V 5A 24Pin Female Socket IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal:

Q: How is the DH24 24Pin Female Socket installed in industrial equipment?

A: The DH24 female socket is designed for panel mounting, secured in place with its screw coupling mechanism. Wires (18-24 AWG) are soldered onto the terminals, and the 16mm cable entry supports straightforward cable integration into your equipment.

Q: What environments and applications is this connector suitable for?

A: This connector is ideal for outdoor, harsh, or industrial environments requiring reliable, waterproof, and dustproof power connections. It's widely used in automation systems, power electronics, machinery, and other applications where IP67 protection is necessary.

Q: When should I choose a socket with an IP67 rating and metal shell?

A: You should choose the DH24 connector with IP67 and a robust metal shell when operating in conditions with exposure to moisture, dust, vibration, or mechanical stress. Its design ensures reliable performance in challenging environments, protecting against environmental hazards.

Q: Where can the DH24 socket be used within an industrial system?

A: This socket can be used as a panel-mount interface for power and signal transmission between equipment modules, control panels, or field devices-especially where secure, high-density connections and environmental sealing are required.

Q: What is the process for connecting cables to this socket?

A: Cables with wire gauges from 18-24 AWG are stripped and soldered onto the respective pin contacts inside the socket. After soldering, the cable is routed through the 16mm entry, and the assembly is completed by locking the socket onto the panel with its screw mechanism.

Q: How does the DH24 connector ensure long-term reliability and performance?

A: The connector employs durable gold/tin-plated copper alloy contacts for sustained conductivity, a nickel-plated zinc alloy shell for enhanced corrosion resistance, and a silicone gasket for superior sealing. It's rated for at least 500 mating cycles and complies with MIL-STD requirements for vibration and humidity.

Q: What are the main benefits of using this connector in industrial systems?

A: Primary benefits include robust protection against water, dust, and EMI/RFI, high current and voltage rating (5A/250V), ease of installation, compliance with safety and environmental standards, and suitability for demanding and critical power transmission applications.
