YM20 500V 10A 5Pin Male Socket IP67 Waterproof Power Connector Plastic Shell Solder Terminal

342.0 INR/Piece

Get a Price/Quote

Product Details:

Power Source Wired
Power Supply Electric
Interface Solder Terminal
Features Waterproof, Weather Resistant, High Durability, Flame Retardant
Usage Industrial, Outdoor Power Supply
IP Rating IP67
Input 5Pin Male
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

YM20 500V 10A 5Pin Male Socket IP67 Waterproof Power Connector Plastic Shell Solder Terminal Price And Quantity

Price 342.0 INR/Piece
Minimum Order Quantity 100 Piece

Flammability Rating UL94 V-0
Mating Cycle Durability 500 Times
Contact Plating Silver or Gold Plated
Sealing Method Rubber Gasket
Mounting Type Panel Mount
Connector Type 5Pin Male Socket
Housing Material Engineering Plastic
Material High Quality Plastic Shell, Copper Alloy Contacts
Cable Diameter Range 5mm to 10mm
Insulation Resistance 500 M at 500V DC
Contact Resistance 5 m

YM20 500V 10A 5Pin Male Socket IP67 Waterproof Power Connector Plastic Shell Solder Terminal Product Specifications

Capacity 5Pin connection, 10A each pin
Rated Voltage 500V AC/DC
Weight Approx. 40g
Features Waterproof, Weather Resistant, High Durability, Flame Retardant
Size 20mm series
Thickness Shell thickness approx. 2-3mm
Power Source Wired
Current Rating 10A
Interface Solder Terminal
Product Type Waterproof Power Connector
Function Power Connection
Power Supply Electric
Output Through terminal
Frequency 50/60Hz
Application Outdoor, Automation Equipment, LED Lighting, Industrial Control
Components Connector body, solder terminals, sealing gasket
Input 5Pin Male
IP Rating IP67
Usage Industrial, Outdoor Power Supply
Thermal Conductivity Standard for plastic shell
Color Black
Dimension (L*W*H) Approx. 74mm x 26mm x 26mm
Operating Temperature -40C to +105C
Supply Voltage 500V Max

Flammability Rating UL94 V-0
Mating Cycle Durability 500 Times
Contact Plating Silver or Gold Plated
Sealing Method Rubber Gasket
Mounting Type Panel Mount
Connector Type 5Pin Male Socket
Housing Material Engineering Plastic
Material High Quality Plastic Shell, Copper Alloy Contacts
Cable Diameter Range 5mm to 10mm
Insulation Resistance 500 M at 500V DC
Contact Resistance 5 m

YM20 500V 10A 5Pin Male Socket IP67 Waterproof Power Connector Plastic Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:500V
Withstanding voltage:2500V
Insertion and extraction force:8.2N Max
Mating cycle:1700 Times
Screw torque:42-53 (N.m)
Temperature and humidity:-4080C; 40C, 85%RH

Superior Waterproof Performance

With an IP67 waterproof rating, the YM20 5Pin Male Socket can withstand immersion in water and protect against dust, making it perfectly suited for outdoor and industrial power applications. The rubber gasket sealing ensures moisture and debris cannot penetrate, providing peace of mind in challenging environments.

Durable and Safe Construction

Built with a high-quality engineering plastic shell and copper alloy contacts, this connector offers excellent flame resistance (UL94 V-0), robust thermal stability, and long-lasting durability with a 500-cycle mating lifespan. The panel-mount design ensures a secure and stable installation for continuous operation.

Versatile Application Range

The YM20 power connector is designed to serve a variety of needs, from outdoor LED lighting installations to automation and industrial control systems. Its compatibility with cable diameters from 5mm to 10mm, and reliable performance at up to 500V and 10A per pin, ensure flexibility and effectiveness across diverse environments.

FAQ's of YM20 500V 10A 5Pin Male Socket IP67 Waterproof Power Connector Plastic Shell Solder Terminal:

Q: How is the YM20 5Pin Male Socket installed in outdoor equipment?

A: The YM20 socket is designed for panel mounting. Simply insert the connector into a pre-cut panel hole, secure it with mounting screws, and ensure the rubber gasket is properly seated for a watertight seal. Then, connect wires to the solder terminals before final assembly.

Q: What kind of environments can this connector be used in?

A: With its IP67 waterproof rating, flame-retardant housing, and operating temperature range of -40C to +105C, the YM20 connector is suitable for outdoor, industrial, and automation applications. It withstands exposure to dust, water, and harsh temperatures.

Q: When should I use a 5Pin connector like the YM20?

A: The YM20 is ideal when you need to transmit power (up to 500V and 10A per pin) over multiple lines while ensuring environmental protection. Common applications include LED lighting, industrial machinery, and outdoor power supply connections.

Q: What benefits does the IP67 rating provide for power connections?

A: IP67 protection means the connector is dust-tight and safeguarded against temporary submersion in water, which maintains reliable electrical connections in wet or dirty settings, reducing risks of failure due to environmental exposure.

Q: How does the connector ensure electrical safety and durability?

A: The YM20 features silver or gold-plated copper contacts for low resistance and high conductivity, a UL94 V-0 rated plastic shell for flame resistance, and sealing gaskets for protection against moisture. It's rated for 500 mating cycles, ensuring long service life.

Q: Where can the YM20 5Pin Male Socket be used in industrial settings?

A: It can be utilized on industrial control panels, automation systems, power distribution boxes, or any location requiring a robust, waterproof multi-pin connector for reliable power transmission.

Q: What is the process for wiring this connector?

A: To wire the YM20, strip the insulation off your cables (5mm-10mm diameter), solder each wire to the corresponding terminal, assemble the connector body with the gasket in place, and mount the socket securely onto your equipment panel.
