LP28 35A 3Pin Male Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Screw Terminal

Name: LP28 35A 3Pin Male Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Screw Terminal
Brand: CONNECTOR DEVICES
Price: 935.0 INR
Availability: InStock

935.0 INR/Piece

Get a Price/Quote

Product Details:

Interface Screw terminal-type
Power Source External Electrical Supply
Usage Waterproof power connection for heavy-duty environments
Components Metal shell, 3 screw terminals, flange mount
Input AC Power
Features Flange mounting, waterproof, corrosion-resistant, robust metal shell, easy wiring, vibration-proof
Power Supply Electrical via cable install
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP28 35A 3Pin Male Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Screw Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 935.0 INR/Piece

Ingress Protection Completely protected against dust and temporary immersion
Material Metal Shell (Aluminum Alloy), PA66 Insulator
Impact Resistance High (suitable for rugged environment)
Connector Gender Male (Plug)
Terminal Type Screw Terminal
Pins 3-Pin Male
Contact Resistance 5m
Contact Material Copper alloy (plated)
Insulation Resistance >500M (500V DC)
Cable Diameter Supported 8mm - 12mm
Mounting Type Flange Mount with screw holes
Flame Retardancy UL94 V-0
Standards Complies with IEC/EN 60529
Shell Finish Nickel-plated

LP28 35A 3Pin Male Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Screw Terminal Product Specifications

Interface Screw terminal-type
Frequency 50/60Hz
Capacity 35A Max Current
Power Source External Electrical Supply
Thickness Shell thickness approx. 2mm
Current Rating 35A
Usage Waterproof power connection for heavy-duty environments
Size Flange diameter approx. 36mm
Supply Voltage 500V AC Max
Components Metal shell, 3 screw terminals, flange mount
Product Type 3-Pin Male Power Connector Socket
Dimension (L*W*H) Approx. 60mm x 36mm x 36mm
Features Flange mounting, waterproof, corrosion-resistant, robust metal shell, easy wiring, vibration-proof
Input AC Power
Application Industrial machinery, outdoor power distribution, marine, generator hookup
Output AC Power
Power Supply Electrical via cable install
Color Silver / Black
Function Power connection for industrial equipment
Rated Voltage 500V AC
IP Rating IP67
Operating Temperature -40C to +80C
Weight Approx. 150g

Ingress Protection Completely protected against dust and temporary immersion
Material Metal Shell (Aluminum Alloy), PA66 Insulator
Impact Resistance High (suitable for rugged environment)
Connector Gender Male (Plug)
Terminal Type Screw Terminal
Pins 3-Pin Male
Contact Resistance 5m
Contact Material Copper alloy (plated)
Insulation Resistance >500M (500V DC)
Cable Diameter Supported 8mm - 12mm
Mounting Type Flange Mount with screw holes
Flame Retardancy UL94 V-0
Standards Complies with IEC/EN 60529
Shell Finish Nickel-plated

LP28 35A 3Pin Male Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Screw Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:500V
Wire Specification:2.5mm5mm/14-12AWG
Line Diameter Range:18mm20mm
Withstand Voltage (AC.V) 1 Minute:2500 V
Mating Cycle:>500 times
Working Temperature:-4080C
Connection Mode:Quick Plug Connection

Rugged Construction for Heavy-Duty Environments

Built to endure tough conditions, this connector features a corrosion-resistant aluminum alloy shell and flame-retardant PA66 insulator. Its robust build and nickel-plated finish provide high impact resistance and reliable performance, even in harsh or outdoor settings. The advanced design ensures long-term durability for demanding applications.

Reliable Waterproof Protection-IP67 Certified

Engineered for industrial use, this power connector achieves an IP67 rating, shielding it from dust and temporary immersion in water. It is ideal for outdoor installations, marine locations, or any environment where exposure to moisture and debris is a concern. The weatherproof design ensures consistent, safe power delivery in unpredictable conditions.

Easy Installation and Secure Wiring

The flange mount with screw holes allows straightforward, stable installation on panels or equipment. The screw terminal interface accommodates cable diameters of 8mm to 12mm for convenient electrical connections. Designed for efficiency, it streamlines setup and maintenance, helping technicians deliver a secure and reliable power supply quickly.

FAQ's of LP28 35A 3Pin Male Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Screw Terminal:

Q: How is the LP28 35A 3Pin Male Socket typically installed?

A: This connector is secured using flange mounting with screw holes, allowing the socket to be easily attached to panels or enclosures. The process involves positioning the flange and fastening it with screws through designated holes, followed by wiring the cables via screw terminals for a stable connection.

Q: What are the primary applications for this waterproof power connector?

A: The LP28 35A 3Pin Male Socket is commonly used in industrial machinery, outdoor power distribution, marine equipment, and generator hookups. Its rugged design and waterproof properties make it suitable for environments where durability and reliable power delivery are essential.

Q: When should I consider using this connector instead of a standard power socket?

A: Opt for this connector in scenarios requiring high current (up to 35A), robust protection against dust and moisture (IP67), and reliability under vibration or impact. It is ideal when you need a secure, weatherproof connection in heavy-duty or outdoor applications.

Q: Where can this connector be safely used?

A: The connector is suitable for outdoor and indoor environments, particularly locations exposed to dust, moisture, vibrations, or temperature changes. Examples include factories, ship decks, construction sites, and outdoor power distribution panels.

Q: What is the benefit of the metal shell and nickel-plated finish?

A: The aluminum alloy metal shell with nickel-plating enhances durability, corrosion resistance, and impact protection. This ensures the connector can withstand harsh industrial and environmental conditions, thereby extending service life and maintaining electrical integrity.

Q: How does the screw terminal process work for cable installation?

A: To install the cable, strip the wire ends, insert them into the corresponding screw terminals on the connector, and tighten the screws to ensure a secure and stable electrical connection. This allows for straightforward wiring and easy maintenance.

Q: What certifications and safety ratings does this connector meet?

A: The connector complies with IEC/EN 60529 standards, offers IP67 ingress protection, and flame retardancy rated at UL94 V-0. These certifications confirm its suitability for critical and safety-conscious environments.
