DH24 400V 10A 12Pin Male Plug IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal

Name: DH24 400V 10A 12Pin Male Plug IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 1083.0 INR
Availability: InStock

1083.0 INR/Piece

Get a Price/Quote

Product Details:

Input 12Pin male plug
Features Metal shell, waterproof, dustproof, corrosion resistant, vibration-proof
Output Panel or cable socket (not included)
Power Supply AC/DC
Power Source Electric, wired connection
IP Rating IP67
Operating Temperature -40C to +85C
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

DH24 400V 10A 12Pin Male Plug IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 1083.0 INR/Piece

DH24 400V 10A 12Pin Male Plug IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal Product Specifications

Rated Voltage 400V
Features Metal shell, waterproof, dustproof, corrosion resistant, vibration-proof
Current Rating 10A per pin
Capacity 10A max per contact
Application Machinery, LED lighting, Automation, Heavy equipment
Weight Approx. 210g
Size DH24 size standard
Input 12Pin male plug
IP Rating IP67
Dimension (L*W*H) Approx. 79mm (L) x 37mm (Diameter)
Frequency 50/60Hz
Operating Temperature -40C to +85C
Product Type Waterproof Power Connector
Supply Voltage 400V AC/DC
Interface Solder terminal, circular 12Pin male
Components 1 x 12Pin male plug, solder terminals
Output Panel or cable socket (not included)
Usage Outdoor and industrial power connections
Function Power and signal transmission connector
Power Source Electric, wired connection
Thickness Metal shell thickness approx. 1.3mm
Color Silver (Metallic)
Power Supply AC/DC

Mounting Type Inline cable mount male plug
Flame Retardant Level UL94 V-0
Contact Resistance 5m
Environmental Protection UV and chemical resistant
Contact Material Copper alloy, gold plated
Dielectric Withstanding Voltage 1500V AC, 1 minute
Locking Mechanism Threaded coupling
Shell Material Zinc alloy with nickel plating
Cable Diameter Range 8mm to 12mm
Contact Plating Gold over nickel
Insulation Resistance 1000M @ 500V DC

DH24 400V 10A 12Pin Male Plug IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:400V
Temperature and humidity:-4080C; 40C, 85%RH
Wire Gauge:1.01.5mm/18 -16AWG
Withstand voltage(AC.V)1min:2500V
Mating Cycle:1700 Times

Superior Durability in Demanding Environments

Constructed with a sturdy zinc alloy shell and nickel plating, the DH24 12Pin Male Plug is designed to withstand harsh industrial and outdoor conditions. Its IP67 rating ensures waterproof and dustproof performance, while its UV and chemical resistance make it ideal for long-term applications in challenging settings.

Versatile Power and Signal Connectivity

Supporting both AC and DC power up to 400V and 10A per contact, this connector is built for high-capacity power and signal transmission. Its 12-pin circular design and gold-plated contacts ensure low contact resistance, reliability, and efficient connectivity for various equipment and automation systems.

Safe and Secure Installation

The connector features a threaded coupling mechanism for vibration-proof locking and easy mating. Flame retardancy to UL94 V-0, a wide operating temperature range from -40C to +85C, and a thick metal shell provide added safety and reliability during operation. Solder terminals make installation straightforward for engineers and technicians.

FAQ's of DH24 400V 10A 12Pin Male Plug IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal:

Q: How do I install the DH24 400V 10A 12Pin Male Plug?

A: To install, solder your wires onto the corresponding terminals, then secure the cable (8mm to 12mm diameter) into the plug. Tighten the threaded coupling for a vibration-proof and waterproof connection. The inline cable mount design makes it suitable for field assembly without panel mounting.

Q: What applications is this power connector suitable for?

A: The DH24 connector is ideal for outdoor and industrial power connections, including machinery, LED lighting, automation systems, heavy equipment, and more. It supports reliable power and signal transmission in harsh environments.

Q: When should I use this connector over plastic or unshielded options?

A: Choose the DH24 metal-shell connector when you need superior durability, waterproofing (IP67), resistance to chemicals, UV, and mechanical stresses, or when flame retardancy (UL94 V-0) is essential. It outperforms basic connectors in industrial and outdoor applications.

Q: Where does the DH24 connector provide environmental protection?

A: This plug offers complete protection against water, dust, UV rays, and chemicals, making it suitable for outdoor exposure or demanding industrial environments where such factors are common.

Q: What are the benefits of the gold over nickel contact plating?

A: Gold over nickel plating ensures extremely low contact resistance (as low as 5m), improved corrosion resistance, and long-lasting stable connections, even in aggressive environmental conditions.

Q: Can the DH24 plug be used with both AC and DC power supplies?

A: Yes, it supports both AC and DC currents up to 400V, 10A per contact, making it highly versatile for various power and signal transmission requirements.
