LP28 50A 2Pin Female Plug IP67 Waterproof Power Connector Plastic+Metal Shell Screw Terminal

Name: LP28 50A 2Pin Female Plug IP67 Waterproof Power Connector Plastic+Metal Shell Screw Terminal
Brand: CONNECTOR DEVICES
Price: 1021.0 INR
Availability: InStock

1021.0 INR/Piece

Get a Price/Quote

Product Details:

IP Rating IP67
Output 2 Pin Output
Input 2 Pin Input
Usage Industrial Equipment, Power Distribution
Power Source Electric Power
Components Plug Shell, Contact Pins, Screw Terminals, Gasket
Power Supply Electrical
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP28 50A 2Pin Female Plug IP67 Waterproof Power Connector Plastic+Metal Shell Screw Terminal Price And Quantity

Price 1021.0 INR/Piece
Minimum Order Quantity 100 Piece

Contact Resistance 2.5m
Mounting Type Cable Mount
Connector Series LP28
Shell Material Plastic + Metal Alloy
Flame Retardant Grade UL94-V0
Environmental Protection Salt spray proof, UV resistant
Withstand Voltage 2000V AC/1min
Seal Material Silicone Rubber
Mating Cycle Durability 500 cycles
Contact Material Copper Alloy with Silver Plating
Number of Contacts 2
Terminal Type Screw Terminal
Insulation Resistance 5000M (at 500V DC)
Cable Outer Diameter Range 10-16mm
Wire Gauge Supported Up to 10mm2
Connector Gender Female

LP28 50A 2Pin Female Plug IP67 Waterproof Power Connector Plastic+Metal Shell Screw Terminal Product Specifications

Application Outdoor/Indoor Power Connections
Dimension (L*W*H) 48.5mm x 28mm x 28mm
Operating Temperature -40C to +85C
Features Waterproof, Dustproof, Corrosion Resistance, Quick Lock
Product Type 2-Pin Female Plug Connector
Size LP28 (28mm series)
Interface Screw Terminal
Frequency 50/60Hz
Function Power Connection
Weight Approx. 215g
IP Rating IP67
Output 2 Pin Output
Input 2 Pin Input
Color Black and Silver
Current Rating 50A
Supply Voltage 500V
Usage Industrial Equipment, Power Distribution
Power Source Electric Power
Components Plug Shell, Contact Pins, Screw Terminals, Gasket
Rated Voltage 500V AC/DC
Thickness Shell thickness approx. 2.5 mm
Capacity 50A
Power Supply Electrical

Contact Resistance 2.5m
Mounting Type Cable Mount
Connector Series LP28
Shell Material Plastic + Metal Alloy
Flame Retardant Grade UL94-V0
Environmental Protection Salt spray proof, UV resistant
Withstand Voltage 2000V AC/1min
Seal Material Silicone Rubber
Mating Cycle Durability 500 cycles
Contact Material Copper Alloy with Silver Plating
Number of Contacts 2
Terminal Type Screw Terminal
Insulation Resistance 5000M (at 500V DC)
Cable Outer Diameter Range 10-16mm
Wire Gauge Supported Up to 10mm2
Connector Gender Female

LP28 50A 2Pin Female Plug IP67 Waterproof Power Connector Plastic+Metal Shell Screw Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:500V
Wire Specification:2.5mm5mm/14-12AWG
Line Diameter Range:18mm20mm
Withstand Voltage (AC.V) 1 Minute:2500V
Working Temperature:-4080C
Connection Mode:Quick Plug Connection

Engineered for Reliable Power Connections

The LP28 50A 2Pin Female Plug combines advanced materials with a smart screw-terminal design. Its shell integrates plastic and metal alloy for durability, while silver-plated copper contacts ensure optimal conductivity. The IP67 rating and UL94-V0 flame retardancy make this connector suitable for environments where safety and reliability are paramount. Whether for insulation resistance or intense weather exposure, this connector stands the test.

Flexible and Secure Mounting Options

Designed for cable mounting, the LP28 connector accommodates cable diameters from 10mm to 16mm and supports wires up to 10mm2. Its robust screw terminals simplify both installation and maintenance. Quick lock features and a 2.5 mm thick shell structure enhance stability and protection, making it a top choice for diverse power distribution needs.

Versatile Application Across Industries

Ideal for both indoor and outdoor power connections, this connector is widely used in industrial equipment, power distribution boards, and heavy-duty electrical systems. Withstanding voltage up to 2000V AC and temperatures from -40C to +85C, it meets the demands of various application scenarios. Its corrosion-resistant and UV-stable build ensures long service life, even in challenging environments.

FAQ's of LP28 50A 2Pin Female Plug IP67 Waterproof Power Connector Plastic+Metal Shell Screw Terminal:

Q: How is the LP28 50A 2Pin Female Plug installed for power connections?

A: The LP28 50A 2Pin Female Plug features screw terminals for cable connection, allowing users to easily attach wires up to 10mm2 in size. Its cable mount design accommodates cables with an outer diameter of 10-16mm. The quick lock shell and silicone gasket ensure a secure, waterproof seal during assembly.

Q: What environments can this connector be safely used in?

A: Thanks to its IP67 waterproof rating, flame retardant shell (UL94-V0), and resistance to salt spray and UV exposure, the connector is suitable for both indoor and outdoor environments. It's ideal for industrial installations, power distribution, and applications exposed to moisture, dust, or harsh weather.

Q: When should I choose the LP28 50A connector over other types?

A: Choose this connector when you require a reliable, high-capacity electrical connection in environments that demand waterproofing, corrosion resistance, or robust mechanical strength. It's especially useful for industrial equipment, outdoor power distribution, and heavy machinery connections.

Q: Where can the LP28 50A 2Pin Female Plug be applied?

A: This connector is used extensively in industrial settings, power distribution panels, and equipment requiring secure, high-current connections. Its strong sealing and durability make it suitable for outdoor lighting, renewable energy systems, and marine or mobile power solutions.

Q: What process should I follow to maintain or replace this connector?

A: To maintain the connector, ensure that terminals remain tight and check the gasket for wear. Replacement involves disconnecting power, unscrewing terminals, and swapping out the connector as needed. Regular inspection helps sustain performance and longevity, especially in demanding conditions.

Q: How does the construction of this connector benefit users?

A: The combination of plastic and metal alloy for the shell, silver-plated copper contacts, and silicone rubber sealing offers excellent mechanical protection, low contact resistance, and superior electrical conductivity. These features ensure a longer lifespan and higher safety for power connections.
