Ip68 Waterproof Connector SP13 Male Panel

00240027 INR/Piece

Get a Price/Quote

Product Details:

Overheating Protection NO
Connector Type SP13 Male Panel Connector
IP Rating IP68
Operating Temperature -20C to +80C
Humidity % 95% RH
Shape Circular
Surface Finish Matte
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Ip68 Waterproof Connector SP13 Male Panel Price And Quantity

Price 00240027 INR/Piece
Minimum Order Quantity 100 Piece

Ip68 Waterproof Connector SP13 Male Panel Product Specifications

Material Nylon PA66 + copper alloy contacts
Humidity % 95% RH
Application Outdoor LED lighting, electrical equipment, marine, automotive, industrial automation
Operating Temperature -20C to +80C
Rated Voltage 250V AC/DC
Surface Finish Matte
Shape Circular
Input Voltage 250V max
Connector Type SP13 Male Panel Connector
Overheating Protection NO
Weight 22g
Frequency (MHz) 50/60 Hz
Size 13mm diameter
IP Rating IP68
Connection Type Screw Terminal
Output Type Panel Mount (Male)
Color Black body with blue ring
Mounting Type Panel mount
No Of Poles 2, 3, 4, 5, 7, 9 poles available
Feature Waterproof, dustproof, quick connect/disconnect
Insulation Material High-performance engineering plastic
Protection Level IP68
Product Type Male Panel Waterproof Connector
Phase Single phase
Dimension (L*W*H) Panel mounting size M13

Cable Diameter Range 4-6.5mm
Contact Resistance 5m
Panel Cutout Diameter 13mm
Current Rating Up to 13A (depending on the number of poles)
Wire Gauge Support 24-18 AWG
Mechanical Life >500 mating cycles
Contact Plating Gold plated bronze
Sealing Gasket Included
Environmental Suitability Outdoor and Harsh Environments
Flame Resistance UL94V-0
Insulation Resistance >1000 M at 500V DC
Locking System Threaded Cap

Product Description

Jump on splendid instant savings with the IP68 Waterproof Connector SP13 Male Panel-your unassailable solution for challenging environments! Offering dominant performance, this connector is engineered for outdoor applications, with robust flame resistance (UL94V-0) and a mechanical life exceeding 500 cycles. The gold-plated bronze contacts and engineered nylon body ensure a splendid blend of conductivity and durability, while its IP68 rating guarantees protection against dust and water. Its ephemeral installation process, thanks to the secure threaded cap, promises quick connect/disconnect for versatile, reliable use.

Applications and Usage Areas of SP13 Male Panel Connector

The IP68 Waterproof Connector SP13 Male Panel excels in numerous application areas, including outdoor LED lighting, marine equipment, automotive electronics, and industrial automation. It is commonly used as a reliable junction for electrical connections where dustproof and waterproof features are paramount. The dominant matte-finished surface enables secure panel mounting, making it suitable for diverse and harsh outdoor surfaces. This connector ensures unassailable performance anywhere robust, protected, and quick electrical connections are essential.

Samples, Delivery, and Main Export Markets

Sample units for the IP68 Waterproof Connector SP13 Male Panel are available for proposal evaluations, enabling clients to assess product quality before committing actual expenditure. Typical delivery time is efficiently managed to meet market value expectations, providing swift supply for both domestic and international orders. This connector is widely exported to major markets across the globe, establishing dependable ties with distributors, importers, manufacturers, and traders, predominantly from India and high-value industrial regions.

FAQ's of Ip68 Waterproof Connector SP13 Male Panel:

Q: How can I install the SP13 Male Panel Connector for outdoor applications?

A: The SP13 Male Panel Connector is designed for panel mounting using a 13mm cutout. Installation is simplified with its threaded cap locking system, providing a secure fit for reliable connections outdoors.

Q: What makes the SP13 Male Panel Connector suitable for harsh environments?

A: Its unassailable IP68 rating, flame-resistant nylon construction, and gold-plated contacts enable the connector to withstand dust, water, high humidity, and a wide temperature range, making it ideal for harsh and outdoor settings.

Q: When should I consider using the SP13 Male Panel Connector?

A: Use this connector when your application demands a dominant, waterproof, and dustproof quick connection, particularly in outdoor lighting, marine, automotive, or industrial automation environments.

Q: Where is the SP13 Male Panel Connector commonly used?

A: You'll typically find it in outdoor LED lighting systems, electrical equipment, marine and automotive applications, and various industrial automation systems requiring effective sealing and long-term reliability.

Q: What are the main benefits of using gold-plated bronze contacts in this connector?

A: Gold plating ensures a low contact resistance (5m), providing excellent conductivity and corrosion resistance for reliable, long-lasting electrical connections even in demanding conditions.

Q: How do I obtain a sample of the SP13 Male Panel Connector?

A: You can request a sample through your distributor or supplier, allowing you to evaluate its features and fit for your proposal amount or project needs before making bulk expenditure decisions.
