LP12 125V 5A 3Pin Female Socket IP67 Waterproof Power Connector

187.0 INR/Piece

Get a Price/Quote

Product Details:

Operating Temperature -25C to +85C
Power Source Hardwired
Features Dust Proof, Waterproof, Vibration Resistant, Corrosion Resistant
Power Supply AC
Input 3 Pin Socket
IP Rating IP67
Usage Industrial, Outdoor, Power Distribution
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP12 125V 5A 3Pin Female Socket IP67 Waterproof Power Connector Price And Quantity

Minimum Order Quantity 100 Piece
Price 187.0 INR/Piece

Max Wire Size 18 AWG (1.0 mm2)
Sealing Gasket Included
Cable Diameter 5mm - 8mm compatible
Number of Pins 3 Pin Female
Shell Material Nylon PA66 (Flame Retardant)
Mounting Type Panel Mount
Connector Series LP12
Contact Material Brass, Gold Plated
Mating Cycle >500 cycles

LP12 125V 5A 3Pin Female Socket IP67 Waterproof Power Connector Product Specifications

Features Dust Proof, Waterproof, Vibration Resistant, Corrosion Resistant
Color Black
Weight Approx. 18g
Components Socket housing, sealing ring, locking nut
Thickness Approx. 27mm
Power Supply AC
Frequency 50/60Hz
Usage Industrial, Outdoor, Power Distribution
Product Type Female Socket Connector
Operating Temperature -25C to +85C
Function Waterproof electrical power socket connection
Power Source Hardwired
Rated Voltage 125V AC
Application Power Supply, Lighting, Outdoor Equipment
Interface Panel Mount, Solder Contacts
Input 3 Pin Socket
Dimension (L*W*H) Approx. 54mm x 27mm x 22mm
IP Rating IP67
Output 3 Pin Plug (Not Included)
Current Rating 5A
Supply Voltage 125V
Capacity 5A Max
Size LP12 standard, 12mm mounting hole

Max Wire Size 18 AWG (1.0 mm2)
Sealing Gasket Included
Cable Diameter 5mm - 8mm compatible
Number of Pins 3 Pin Female
Shell Material Nylon PA66 (Flame Retardant)
Mounting Type Panel Mount
Connector Series LP12
Contact Material Brass, Gold Plated
Mating Cycle >500 cycles

LP12 125V 5A 3Pin Female Socket IP67 Waterproof Power Connector Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Connecting mode:Easy locking type
Insertion and extraction force:0.9N Max
Wire specification:UL246424AWG*2C
Rated Current:5A
Contact dimension:Phi 1.0x3
Temperature and humidity:-4080C, 40C, 85%RH
Mating cycle:1700 times

Versatile and Reliable Power Connectivity

Built for demanding environments, the LP12 3Pin Female Socket delivers consistent performance for industrial, outdoor, and power distribution setups. Its IP67 waterproof and dustproof rating protects internal components, ensuring stable operation even in challenging weather conditions and locations prone to moisture, dust, or vibration.

Superior Material and Safety Features

Utilizing flame-retardant nylon PA66 and gold-plated brass contacts, this socket guarantees both longevity and electrical safety. The included sealing gasket and locking nut further bolster protection, while the vibration and corrosion-resistant design extends the lifespan of your installation.

FAQ's of LP12 125V 5A 3Pin Female Socket IP67 Waterproof Power Connector :

Q: How is the LP12 3Pin Female Socket installed in a panel?

A: Installation requires a 12mm mounting hole on your panel. The socket is inserted, secured with the provided locking nut, and the wires are soldered to the contacts. Its panel mount design ensures a stable and waterproof fit suitable for hardwired power connections.

Q: What are the main advantages of using this connector in outdoor environments?

A: The LP12 socket's IP67 rating ensures protection against water and dust ingress, making it ideal for outdoor lighting, power supply, and equipment connections. Its sturdy nylon shell and gold-plated contacts further enhance corrosion resistance and durability.

Q: When should I consider using this connector over standard power sockets?

A: Opt for the LP12 connector when you require a secure, weatherproof connection-for example, in industrial machinery, outdoor lighting, or applications exposed to moisture and vibration. Its robust design and flame-retardant materials provide safety and reliability in harsh settings.

Q: What cable sizes and wire types are compatible with this socket?

A: It accommodates cables with diameters from 5mm to 8mm and supports wire sizes up to 18 AWG (1.0 mm2). Ensure your cables meet these specifications for optimal sealing and secure electrical connections.

Q: Where is this connector typically used?

A: This socket is compatible with industrial, outdoor, and power distribution systems. Common applications include outdoor lighting, power supply for equipment, and any context requiring a waterproof, vibration-resistant connector in India and worldwide.

Q: What is the expected lifespan or durability of the LP12 connector?

A: Designed for longevity, this connector supports over 500 mating cycles and operates reliably within a temperature range of -25C to +85C, ensuring extended service life in both indoor and outdoor environments.
