LP12 5A 3Pin Female Socket IP67 Waterproof Power Connector Panel Mount

Name: LP12 5A 3Pin Female Socket IP67 Waterproof Power Connector Panel Mount
Brand: CONNECTOR DEVICES
Price: 247.0 INR
Availability: InStock

247.0 INR/Piece

Get a Price/Quote

Product Details:

Operating Temperature -20C to +85C
Input 3 Pin Socket Input
Power Source Connected to Main Power via Panel Mount
Output Electrical Output via 3 Pin Connection
Components Connector Shell, Sealing Gasket, Contacts
Interface Screw Terminal (Panel Mount)
IP Rating IP67 (Waterproof and Dustproof)
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP12 5A 3Pin Female Socket IP67 Waterproof Power Connector Panel Mount Price And Quantity

Price 247.0 INR/Piece
Minimum Order Quantity 100 Piece

LP12 5A 3Pin Female Socket IP67 Waterproof Power Connector Panel Mount Product Specifications

Product Type Panel Mount Power Connector Socket
Features Waterproof, Dustproof, Durable, Easy Panel Mounting
Function Power Connector for Electrical Connections
Rated Voltage 250V AC
Power Supply Panel Mounted Power Supply Connection
Interface Screw Terminal (Panel Mount)
IP Rating IP67 (Waterproof and Dustproof)
Size M12 Thread
Frequency 50/60Hz
Weight Approx. 18g
Usage Industrial and Outdoor Electrical Equipment
Current Rating 5A
Power Source Connected to Main Power via Panel Mount
Dimension (L*W*H) Approx. 37mm x 23mm x 23mm
Capacity 5A Continuous Current
Output Electrical Output via 3 Pin Connection
Components Connector Shell, Sealing Gasket, Contacts
Supply Voltage 250V Max
Application Indoor and Outdoor Power Connectivity
Operating Temperature -20C to +85C
Input 3 Pin Socket Input
Color Black

Dielectric Strength 1500V AC/minute
Contact Resistance 5m
Sealing Type Rubber Gasket Provided
Mounting Style Panel Mount (Through Hole with Nut)
Shell Material Nylon, Flame Retardant PA66
Insulation Resistance 2000M at 500V DC
Mating Cycle >500 Times
Wire Range 20-16 AWG
Contact Material Brass with Gold Plating
Connector Type 3 Pin Female Socket

LP12 5A 3Pin Female Socket IP67 Waterproof Power Connector Panel Mount Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Connecting mode:Easy locking type
Insertion and extraction force:0.6N Max
Wire specification:UL246424AWG*2C
Rated Current:5A
Contact dimension:Phi 1.0x2
Temperature and humidity:-4080C, 40C, 85%RH
Mating cycle:1700 times

Reliable Waterproof Panel Mount Connectivity

The LP12 5A 3Pin Female Socket stands out with its IP67 waterproof and dustproof rating, ensuring dependable operation even in challenging environments. Flame-retardant PA66 nylon and gold-plated brass contacts combine to deliver longevity, corrosion resistance, and stable electrical performance. This connector is engineered for indoor and outdoor installation, making it suitable for industrial automation, outdoor lighting, and heavy-duty power distribution.

Effortless Installation and Durable Design

Designed for easy panel mounting, the socket features a through-hole design with a locking nut and screw terminals for a quick electrical connection. The rubber gasket provides a robust seal between panel and connector, preventing moisture ingress. Rated for over 500 mating cycles and supporting wire sizes from 20 to 16 AWG, the connector provides lasting performance for repeated use in diverse applications.

FAQ's of LP12 5A 3Pin Female Socket IP67 Waterproof Power Connector Panel Mount :

Q: How does the LP12 5A 3Pin Female Socket ensure waterproof and dustproof performance?

A: The connector achieves IP67 protection through a high-quality nylon shell and a rubber sealing gasket, preventing water and dust ingress during both indoor and outdoor usage.

Q: What is the installation process for the LP12 3Pin Female Socket panel mount connector?

A: Installation involves inserting the connector into a pre-cut panel hole, securing it with the provided nut, and wiring using the screw terminals. The sealing gasket ensures a tight fit against the panel.

Q: Where can I use this power connector for optimal performance?

A: This connector is ideal for industrial, outdoor, or harsh environments where reliable, waterproof, and dustproof electrical connections are essential, such as in control panels, instrumentation, and outdoor lighting.

Q: What benefits does the gold-plated brass contact offer in this connector?

A: Gold-plated brass contacts minimize corrosion and ensure stable, low-resistance connections, resulting in improved electrical performance and longer connector lifespan.

Q: When is the LP12 connector recommended for use over conventional connectors?

A: Choose the LP12 connector whenever you require a robust, waterproof, and flame-retardant connection in demanding environments, providing secure power delivery and long-term reliability.

Q: How much current and voltage can the LP12 3Pin Socket handle?

A: It supports up to 5A continuous current and operates safely at supply voltages up to 250V AC, making it suitable for a wide range of power distribution applications.
