LP16 400V 10A 2Pin Female Socket IP67 Waterproof Power Connector Plastic Shell Solder Terminal

247.0 INR/Piece

Get a Price/Quote

Product Details:

Features Waterproof, dustproof, corrosion resistant, easy installation
Components Plastic shell, 2-pin female terminal
Input Solder terminal input
IP Rating IP67
Power Source Electrical connection
Output Female 2-pin output
Usage Outdoor/Indoor Power Transmission
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP16 400V 10A 2Pin Female Socket IP67 Waterproof Power Connector Plastic Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 247.0 INR/Piece

Cable Diameter Range 5mm - 7mm
Environmental Protection Salt spray and UV resistant
Connection Type Solder terminal
Flame Retardant Level UL94-V0
Mounting Type Panel mount
Contact Material Copper alloy with nickel plating
Mating Cycles >500 times
Sealing Method Silicone gasket
Shell Material High-quality plastic
Locking System Threaded coupling
Number of Pins 2

LP16 400V 10A 2Pin Female Socket IP67 Waterproof Power Connector Plastic Shell Solder Terminal Product Specifications

Usage Outdoor/Indoor Power Transmission
Interface 2-pin Female Solder Terminal
Color Black
Power Supply Electrical
Operating Temperature -40C to +85C
Size LP16 standard size
Features Waterproof, dustproof, corrosion resistant, easy installation
Components Plastic shell, 2-pin female terminal
Capacity 10A current capacity
Supply Voltage 400V
Current Rating 10A
Application Industrial equipment, LED display, electrical equipment, machinery
Function Power connector
Input Solder terminal input
Product Type Waterproof Power Connector Socket
Weight 20g (approx.)
Output Female 2-pin output
Rated Voltage 400V AC
IP Rating IP67
Frequency 50/60Hz
Power Source Electrical connection

Cable Diameter Range 5mm - 7mm
Environmental Protection Salt spray and UV resistant
Connection Type Solder terminal
Flame Retardant Level UL94-V0
Mounting Type Panel mount
Contact Material Copper alloy with nickel plating
Mating Cycles >500 times
Sealing Method Silicone gasket
Shell Material High-quality plastic
Locking System Threaded coupling
Number of Pins 2

LP16 400V 10A 2Pin Female Socket IP67 Waterproof Power Connector Plastic Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Withstanding Voltage:2500V
Temperature Rise:10A 30C ,12A 40C,15A 50C
Contact Resistance:< 2.5m Ohm
Insertion and Extraction Force:1.2N Max
Mating Cycle:> 1700 times
Working Temperature:-40i80C
Connection Mode:Quick plug connection

Rugged and Reliable Power Connection

Engineered for robust power distribution, the LP16 2-pin female socket delivers secure and stable connections, even under challenging environmental conditions. Its IP67 waterproof rating, corrosion-resistant materials, and flame-retardant shell ensure safety and longevity for both indoor and outdoor installations, providing peace of mind for industrial operators and equipment manufacturers alike.

Easy Panel Mounting and Installation

Featuring a user-friendly panel mount design, the LP16 connector allows for straightforward installation, minimizing downtime and maintenance efforts. The solder terminal connection and threaded coupling lock make the process swift and dependable, while the silicone gasket guarantees an environmental seal. Designed for versatility, it accommodates cable diameters between 5mm and 7mm.

Versatile Applications and Top Performance

Ideal for powering industrial equipment, LED displays, and electrical machinery, this connector offers flexibility across various industries. Its high current-carrying capacity (10A at 400V AC) and excellent resistance to UV, salt spray, and fluctuating temperatures provide consistent and reliable performance-making it an asset for distributors, importers, and manufacturers in India and beyond.

FAQ's of LP16 400V 10A 2Pin Female Socket IP67 Waterproof Power Connector Plastic Shell Solder Terminal:

Q: How do I install the LP16 2-pin female socket for panel mounting?

A: To install the LP16 socket, fit it into the required panel cutout, secure it using the threaded coupling, and solder the wires to the terminals. The cable diameter should be between 5mm and 7mm for optimal sealing.

Q: What environmental conditions can this power connector withstand?

A: The LP16 connector is designed for harsh environments, with an IP67 waterproof rating, flame-retardant plastic shell (UL94-V0), salt spray and UV resistance, and an operating temperature range from -40C to +85C.

Q: When should I consider using this 2-pin female socket over other connectors?

A: Choose the LP16 2-pin socket when you require a waterproof, dustproof, and corrosion-resistant connector suitable for outdoor or industrial power applications up to 400V AC and 10A, with high mechanical durability.

Q: Where can the LP16 power connector be used?

A: This connector is ideal for use in industrial equipment, outdoor and indoor LED displays, power transmission for electrical equipment, and machinery where reliable waterproof and dustproof connections are necessary.

Q: What process ensures the connector's waterproof and dustproof qualities?

A: A silicone gasket and threaded coupling provide a secure seal, and the robust plastic shell with nickel-plated copper alloy contacts further enhances its IP67-rated waterproof and dustproof protection.

Q: What benefits does the LP16 connector offer for industrial applications?

A: It provides long-lasting performance (over 500 mating cycles), stable power transmission, easy installation, and excellent protection against moisture, dust, and environmental contaminants, ensuring equipment safety and reliability.
