LP16 USB-C 3.1 Female Socket IP68 Waterproof Connector Panel Mount Plastic Shell

348.0 INR/Piece

Get a Price/Quote

Product Details:

Power Supply USB powered
Charging Voltage 5-20V USB-C standards
Input USB-C 3.1 Female Socket
Operating Temperature -20C to +80C
Components Receptacle, mounting nut, sealing washer
Interface USB Type-C 3.1 Female, 16 pin
Power Source External USB power supply
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP16 USB-C 3.1 Female Socket IP68 Waterproof Connector Panel Mount Plastic Shell Price And Quantity

Minimum Order Quantity 100 Piece
Price 348.0 INR/Piece

Contact Material Gold plated copper alloy
Cable Diameter Supported 6-8mm
Insulation Resistance >500M
Standards Compliance USB 3.1 Gen 2, RoHS, CE
Mating Cycles >500
Sealing Gasket Silicone rubber
Number of Contacts 16 contacts
Shell Color Black with blue sealing ring
Mounting Type Front panel mounting (with threaded nut)
Flame Resistance UL94 V-0
Locking Mechanism Quick push-pull lock
Contact Resistance 30m
Housing Material High-strength PA66 thermoplastic
Dielectric Withstanding Voltage 1000V AC/min

LP16 USB-C 3.1 Female Socket IP68 Waterproof Connector Panel Mount Plastic Shell Product Specifications

Capacity Supports up to 5A current USB-C applications
Thickness Panel thickness 1-3mm supported
Usage Panel mount waterproof USB-C connection
Rated Voltage 60V DC
Power Source External USB power supply
Color Black
Supply Voltage 5V/9V/15V/20V (Standard USB-C Voltage)
Input USB-C 3.1 Female Socket
Weight 9g
Current Rating Up to 5A
Charging Voltage 5-20V USB-C standards
Output USB-C signal and power
Power Supply USB powered
Application Outdoor electronics, industrial equipment, marine and automotive applications
Interface USB Type-C 3.1 Female, 16 pin
IP Rating IP68 waterproof
Dimension (L*W*H) Approx. 28mm (mounting flange diameter) x 47mm (total length)
Function Data transmission and power delivery via USB-C 3.1 interface
Operating Temperature -20C to +80C
Product Type Circular waterproof USB-C connector
Components Receptacle, mounting nut, sealing washer
Features Panel mount, plastic shell, dustproof, waterproof, quick lock coupling
Size LP16 series circular flange

Contact Material Gold plated copper alloy
Cable Diameter Supported 6-8mm
Insulation Resistance >500M
Standards Compliance USB 3.1 Gen 2, RoHS, CE
Mating Cycles >500
Sealing Gasket Silicone rubber
Number of Contacts 16 contacts
Shell Color Black with blue sealing ring
Mounting Type Front panel mounting (with threaded nut)
Flame Resistance UL94 V-0
Locking Mechanism Quick push-pull lock
Contact Resistance 30m
Housing Material High-strength PA66 thermoplastic
Dielectric Withstanding Voltage 1000V AC/min

LP16 USB-C 3.1 Female Socket IP68 Waterproof Connector Panel Mount Plastic Shell Trade Information

Delivery Time 7 Days

Product Description

Spotlight your project with the LP16 USB-C 3.1 Female Socket IP68 Waterproof Connector Panel Mount-the acclaimed solution for demanding environments. This wondrous connector boasts a potent high-strength PA66 thermoplastic shell in glorious black with a blue sealing ring. Equipped with 16 gold-plated contacts and supporting power delivery up to 5A, it ensures reliable data and energy transfer. Its quick push-pull lock and IP68 waterproof rating make it ideal for outdoor, marine, industrial, or automotive panels. Embark on excellence with this deal, crafted for durability and longevity.

Versatility and Machine Features

The LP16 USB-C 3.1 Female Socket IP68 Waterproof Connector excels in outdoor electronics, marine, automotive, and industrial equipment applications. Its unique combination of a high-strength PA66 thermoplastic shell and gold-plated copper alloy contacts delivers both enduring performance and remarkable safety. Glorious features like the quick push-pull locking mechanism, silicone sealing gasket, and 16-pin configuration offer reliable, dustproof, and waterproof connectivity, making this panel mount connector perfectly suited for challenging environments where durability and efficiency are key.

Sample Availability, Policy, and Market Reach

We offer a convenient sample policy for the LP16 USB-C 3.1 Female Socket Connector, enabling clients to assess the product's potent performance before larger commitments. Samples are readily available for swift delivery, minimizing your expenditure on initial evaluation. Our deal extends across India's main domestic market, with prompt distribution to traders, wholesalers, and manufacturers. Take advantage of our offer to experience firsthand this acclaimed connector, designed for a broad spectrum of high-performance applications.

FAQ's of LP16 USB-C 3.1 Female Socket IP68 Waterproof Connector Panel Mount Plastic Shell:

Q: How does the LP16 USB-C 3.1 Female Socket ensure waterproof performance?

A: The connector is engineered with an IP68-rated plastic shell, blue sealing ring, and silicone rubber gasket, making it both dustproof and waterproof for secure operation in harsh environments.

Q: What applications is this connector most suitable for?

A: It is ideal for outdoor electronics, marine, industrial and automotive panels, as well as any setting requiring a robust and water-resistant USB-C connection.

Q: When should I consider using this panel mount USB-C connector?

A: Use this connector when you need reliable data transmission and power delivery in environments exposed to moisture, dust, or extreme conditions.

Q: Where can I obtain a sample of the LP16 USB-C 3.1 Female Socket?

A: Samples are available for delivery across India, with a clear sample policy in place to facilitate quick and low-expenditure evaluation for customers.

Q: What are the material and durability features of this connector?

A: The shell is crafted from high-strength PA66 thermoplastic, equipped with gold-plated copper alloy contacts and a flame-resistant UL94 V-0 rating, ensuring durability and safety.

Q: How does the quick push-pull locking mechanism enhance usage?

A: This locking system allows for secure mating and unmating, simplifying installation and maintenance while guaranteeing stable connectivity in vibration-prone environments.
