LP16 5A 9Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal

Name: LP16 5A 9Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 383.0 INR
Availability: InStock

383.0 INR/Piece

Get a Price/Quote

Product Details:

IP Rating IP67
Operating Temperature -20C to +85C
Components Metal shell, solder contacts, rubber gasket, flange mount
Features Waterproof, dustproof, corrosion resistant, robust metal shell, easy flange mount
Interface 9 Pin Female Socket, Solder Terminal
Power Supply Through cable; solder terminal connection
Usage Industrial, outdoor or harsh environments
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP16 5A 9Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 383.0 INR/Piece

Vibration Resistance Accord with IEC60068-2-6
Mounting Type Flange mount with 2 mounting holes
Flammability Standard UL94-V0
Material Zinc alloy (shell), gold-plated copper (contacts)
Wire Gauge Supported AWG 22~16
Contact Plating Gold-plated contacts
Sealing Method Silicone gasket
Contact Resistance 5m
Cable Diameter Range 3.5mm to 7mm
Insulation Resistance >=2000M@500V DC
Mating Cycle Durability >=500 cycles

LP16 5A 9Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal Product Specifications

Output 9-pin female socket interface
Size Flange mount - 16mm panel cutout; compact body
Dimension (L*W*H) Approx. 27mm x 21mm x 29mm (with flange)
Capacity 9 contacts, Max 5A per contact
Supply Voltage Up to 250V AC
Interface 9 Pin Female Socket, Solder Terminal
Input Solder terminal
Features Waterproof, dustproof, corrosion resistant, robust metal shell, easy flange mount
Power Source External electrical supply
Product Type Power Connector
Operating Temperature -20C to +85C
Components Metal shell, solder contacts, rubber gasket, flange mount
Usage Industrial, outdoor or harsh environments
Thickness Metal shell, approx. 1.5mm
Weight Approx. 26g
Function Waterproof power connection for electrical devices
Application Industrial machinery, power equipment, automation, outdoor electronics
Current Rating 5A per pin
Rated Voltage 250V AC
Frequency 50/60Hz supported
IP Rating IP67
Color Silver/Grey (Metal Shell)
Power Supply Through cable; solder terminal connection

Vibration Resistance Accord with IEC60068-2-6
Mounting Type Flange mount with 2 mounting holes
Flammability Standard UL94-V0
Material Zinc alloy (shell), gold-plated copper (contacts)
Wire Gauge Supported AWG 22~16
Contact Plating Gold-plated contacts
Sealing Method Silicone gasket
Contact Resistance 5m
Cable Diameter Range 3.5mm to 7mm
Insulation Resistance >=2000M@500V DC
Mating Cycle Durability >=500 cycles

LP16 5A 9Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:250V
Withstanding Voltage:2500V
Temperature Rise:10A 30C ,12A 40C ,15A 50C
Contact Resistance:< 2.5m Ohm
Insertion and Extraction Force:1.2N Max
Mating Cycle:> 1700 times
Working Temperature:-4080C

Reliable Power Connection in Tough Conditions

Engineered for industrial, outdoor, or harsh environments, the LP16 5A 9Pin Female Socket delivers consistent and safe power connectivity. Its waterproof, dustproof, and corrosion-resistant design provides protection against challenging weather and mechanical stress, making it suitable for machinery and outdoor electronic systems where reliability is paramount.

Premium Build and Secure Installation

The connector's solid zinc alloy shell and gold-plated copper contacts ensure long-lasting performance. The easy-to-use flange mount requires just two screws, allowing for stable and secure placement on panels. The silicone gasket further enhances sealing, blocking moisture and contaminants for dependable operation.

Versatile Application and Simple Wiring

Supporting wire gauges from AWG 22 to 16 and cable diameters of 3.5mm to 7mm, this socket is adaptable to various setups. The solder terminal facilitates straightforward assembly for installers and technicians, making it perfect for distributors, manufacturers, and maintenance teams in diverse sectors.

FAQ's of LP16 5A 9Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal:

Q: How is the LP16 5A 9Pin Female Socket installed onto a panel?

A: The connector is designed for easy flange mounting with two mounting holes, ensuring a secure fit on panels with a 16mm cutout. Simply position the socket, align it with the mounting holes, and fasten it with screws. The included silicone gasket provides IP67 sealing, further safeguarding against moisture ingress.

Q: What types of environments is this power connector suitable for?

A: Thanks to its IP67 rating, robust zinc alloy housing, and silicone sealing, the connector is ideal for industrial, outdoor, and harsh environments. It withstands dust, water, vibration, and temperature ranges from -20C to +85C, making it a reliable choice for machinery, automation, and outdoor electronics.

Q: What is the maximum current and voltage rating of this connector?

A: Each pin supports up to 5A at a maximum voltage of 250V AC, accommodating most industrial and power equipment requirements. The gold-plated copper contacts ensure low resistance and reliable performance even under continuous operation.

Q: Which wire gauges and cable sizes does this connector support?

A: The LP16 9-pin female socket accommodates wires sized AWG 22 to 16 and cable diameters from 3.5mm to 7mm. This range allows flexibility for various industrial and electronic applications, ensuring secure and efficient connections.

Q: How does the connector maintain waterproof and dustproof properties?

A: The device achieves IP67 protection through a combination of a tightly fitted metal shell and a silicone gasket sealing method. This construction keeps out dust, water, and contaminants, ensuring safe operation in challenging environments.

Q: What benefits do the gold-plated contacts and zinc alloy shell provide?

A: Gold-plated contacts enhance electrical conductivity and resist corrosion, while the zinc alloy shell offers mechanical strength and shields the connector from impact and environmental hazards. Together, these features deliver long service life and consistent reliability.

Q: What is the recommended usage process for connecting wires to the solder terminals?

A: To connect wires, select the appropriate gauge (AWG 22~16), strip the insulation, and securely solder the wire ends onto the connector's terminals. Confirm each solder joint is solid to guarantee optimal electrical contact, then mount the connector and ensure the gasket is properly seated for waterproof sealing.
