YM20 20A 3Pin Female Plug IP68 Waterproof Power Connector Inline Solder Terminal

Name: YM20 20A 3Pin Female Plug IP68 Waterproof Power Connector Inline Solder Terminal
Brand: CONNECTOR DEVICES
Price: 417.0 INR
Availability: InStock

417.0 INR/Piece

Get a Price/Quote

Product Details:

Features Waterproof, Dustproof, Anti-corrosion, Easy Installation
Interface 3 Pin Solder Terminal
Operating Temperature -40C~+105C
Usage Industrial, Outdoor Power Connection
Input Cable Solder Terminal
Power Supply Cable/In-line
Components Nylon Body, Copper Alloy Contacts, Silicone Seal Rings
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

YM20 20A 3Pin Female Plug IP68 Waterproof Power Connector Inline Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 417.0 INR/Piece

Locking Mechanism Screw Coupling
Contact Material Copper Alloy Gold-Plated
Sealing Method Silicone O-Ring and Grommet
Mechanical Life 500 Mating Cycles
Connector Type Inline Female Plug
Body Material Nylon PA66
Cable Outer Diameter Supported 8mm - 12mm
Number of Pins 3 pin

YM20 20A 3Pin Female Plug IP68 Waterproof Power Connector Inline Solder Terminal Product Specifications

Power Source External Power via Cable
Function Power Connector for Electrical Equipment
Output Cable Solder Terminal
Supply Voltage 500V Max
Weight Approx. 105g
Power Supply Cable/In-line
Dimension (L*W*H) Approx. 90mm (L) x 29mm (W & H)
IP Rating IP68
Components Nylon Body, Copper Alloy Contacts, Silicone Seal Rings
Color Black
Application Waterproof Power Connections, Outdoor Lighting, Machinery, Automation Systems
Frequency 50/60Hz
Size YM20 Series
Usage Industrial, Outdoor Power Connection
Input Cable Solder Terminal
Rated Voltage 500V AC/DC
Capacity 20A Per Pin
Thickness Body 24mm
Features Waterproof, Dustproof, Anti-corrosion, Easy Installation
Current Rating 20A
Product Type Female Plug
Interface 3 Pin Solder Terminal
Operating Temperature -40C~+105C

Locking Mechanism Screw Coupling
Contact Material Copper Alloy Gold-Plated
Sealing Method Silicone O-Ring and Grommet
Mechanical Life 500 Mating Cycles
Connector Type Inline Female Plug
Body Material Nylon PA66
Cable Outer Diameter Supported 8mm - 12mm
Number of Pins 3 pin

YM20 20A 3Pin Female Plug IP68 Waterproof Power Connector Inline Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:500V
Withstanding voltage:2500V
Insertion and extraction force:4.0N Max
Screw torque:42-53 (N.m)
Temperature and humidity:-4080C; 40C, 85%RH
Contact dimension:Phi 2.7*2

Superior Waterproof and Dustproof Design

Designed for enhanced protection, the YM20 connector achieves IP68 ingress protection with its nylon PA66 body and durable silicone O-rings. This ensures reliable performance even in harsh outdoor or industrial conditions, safeguarding connections against water, dust, and corrosion. The connector is well-suited for challenging environments such as outdoor lighting and machinery.

High Capacity, Reliable Connectivity

With a rating of 20A per pin and support for voltages up to 500V AC/DC, the YM20 connector delivers consistent power for demanding applications. Gold-plated copper alloy contacts offer excellent conductivity, while the robust screw-coupling mechanism secures the connection, supporting up to 500 mating cycles for lasting reliability.

Flexible and Easy Installation

Installation is straightforward thanks to the inline solder terminals, supporting cable diameters between 8mm and 12mm. The connector is compatible with a wide range of power cables, making it ideal for use in industrial automation, machinery, and outdoor electrical equipment installation. Clear design features expedite the setup process, saving installation time.

FAQ's of YM20 20A 3Pin Female Plug IP68 Waterproof Power Connector Inline Solder Terminal:

Q: How do I install the YM20 20A 3Pin Female Plug for a waterproof connection?

A: To install the YM20 connector, strip your cable and solder the wires to the 3-pin solder terminals. Ensure cables are within the supported 8mm-12mm diameter range. Assemble the body, aligning the silicone O-ring and grommet for sealing, and secure with the screw coupling to achieve a reliable IP68 waterproof bond.

Q: What makes the YM20 connector suitable for outdoor or industrial use?

A: Its IP68 waterproof and dustproof rating, corrosion-resistant nickel-plated copper contacts, robust nylon PA66 body, and wide operating temperature range (-40C to +105C) make the YM20 ideal for outdoor lighting, machinery, automation, and other demanding environments.

Q: When should I consider using the YM20 3Pin connector in my project?

A: Use the YM20 connector whenever you need a secure, high-capacity power connection (up to 20A and 500V AC/DC), especially in applications where waterproofing, dust resistance, and durability are critical, such as outdoor installations, industrial machinery, or automation systems.

Q: Where can this connector be used most effectively?

A: The YM20 3Pin connector is most effective in applications requiring reliable waterproof power connections, such as outdoor lighting, industrial equipment, and areas exposed to moisture, dust, or mechanical stress.

Q: What are the benefits of the screw coupling mechanism and silicone O-ring in the YM20 connector?

A: The screw coupling ensures a stable, vibration-resistant connection, while the silicone O-ring and grommet provide exceptional sealing against water and dust. This increases reliability and longevity, even in harsh or outdoor environments.

Q: How long can I expect the mechanical life of the YM20 connector to last?

A: The YM20 connector is rated for up to 500 mating cycles, ensuring a long service life for repeated connections and disconnections in industrial and outdoor settings.
